Crestron Lighting Control System
6, 8, and 12 button C2N-DB Series Wall Panels
Physical View of the C2N-DB Wall Panel
Side View Front View Back View
with buttons installed with buttons removed
1.53 in
1.67 in
(3.89 cm)
1.79 in
(4.24 cm)
(4.55 cm)
1.07 in
(2.72 cm)
4.16 in
2.70 in
(10.57 cm)
(6.86 cm)
Cresnet
Rubber
port
Membrane
