Crestron Lighting Design Design Manual page 26

Control System
CT-1000
TPS-2000L
22 • Lighting Control System Design
Touchpanel Selection
Crestron touchpanels are graphical user interfaces that provide the user with visual
control and feedback.
Touchpanels are an elegant, efficient and practical solution to room control. A
touchpanel can control lighting, audio and video, HVAC, and security.
Touchpanel pages can provide convenient control of every individual light in the
residence from a single location. The integration of touchpanels and lighting control
is a primary feature of Crestron lighting systems. The designer can create a complex
control environment while presenting the user with easy and intuitive controls.
For example, a "Good Night" button can be programmed to dim the lights, gently
quiet the music, notify the alarm system, and set a nighttime temperature. All with
one touch.
Designed using VT-Pro-e software, these user interfaces can be customized to
provide complete control of the lighting control system and the entire home
automation system.
Consult lightingsolutions@crestron.com
Physical Views of Series 1000 Touchpanel
(12.34 cm)
4.76 in
(12.10 cm)
for additional information.
4.86 in
Crestron Lighting
1.59 in
(4.04 cm)
1.36 in
(3.47 cm)
Design Guide – DOC. 5999A
