  • Page 2 This document was prepared and written by the Technical Documentation department at: Crestron Electronics, Inc. 15 Volvo Drive Rockleigh, NJ 07647 1-888-CRESTRON...

  • Page 3: Table Of Contents

    Integrated Dual Bus Control System: PRO2 & AV2 Description..........................1 Functional Description ....................1 Configuration Differences ................... 2 Physical Description....................3 2 Series Ports....................4 2 Series Indicators ..................6 2 Series Buttons.....................7 PRO2 LCD Display..................8 Leading Specifications......................10 Setup ............................12 Rack Mounting ......................12 Expandable Memory ....................
  • Page 4 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 Serial Communication Difficulties with Other Devices Connected to the Control System ........................41 Passthrough Mode..................41 COM Analyzer ....................41 Further Inquiries ......................43 Future Updates ......................43 Software License Agreement....................44 Return and Warranty Policies ....................

  • Page 5: Integrated Dual Bus Control System: Pro2 & Av2

    Crestron's unique dual bus system, with its high-speed I/O bus architecture, provides blazing fast throughput, system wide. This dual bus architecture also permits upgrade to new, second generation, higher performance expansion cards, while still using existing cards and software programs.

  • Page 6: Configuration Differences

    A total of 36MB is broken down as follows: 4MB flash, 32MB DRAM, and 256KB NVRAM. ** 40 Mb/s parallel communications and supports current and enhanced Crestron control cards. *** Optional Z-BUS Cards: Single port 10/100 Ethernet, Dual Port WAN-LAN-10/100 Ethernet, or...

  • Page 7: Physical Description

    Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Physical Description An asterisk (*) indicates that the The 2-Series integrated control system is housed in a black enclosure with silk- feature is not standard on the AV2 screened labels on the front and rear panels. On the front panel there is a single RS- configuration.

  • Page 8: Series Ports

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 2 Series Ports A number of ports are provided on the front and rear panels of the 2 Series integrated control systems. Refer to the description of each below. COMPUTER...
  • Page 9 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Non-Standard COM Pinout DIRECTION DESCRIPTION To AV2 or PRO2 (RXD-) RS-422 Receive Data (Idles low) To AV2 or PRO2 (RXD) RS-232 Received Data From AV2 or PRO2 (TXD) RS-232 Transmitted Data...

  • Page 10: Series Indicators

    On the rear panel there is an internal universal power supply connector. Use the supplied power cord to connect to an AC outlet. 2 Series Indicators A number of indicators are provided on the front panel of the 2 Series integrated control systems. Refer to the description of each below. PWR (Power) This LED illuminates when the unit is connected to and receives power from an AC outlet.

  • Page 11: Series Buttons

    These LEDs extinguish momentarily when data is sent to the card or received from the card. 2 Series Buttons Two buttons are provided on the front panel of the 2 Series integrated control systems. Refer to the description of each below. HW-R Depression of this button initiates physical reset of the system.

  • Page 12: Pro2 Lcd Display

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 PRO2 LCD Display The front panel of the PRO2 incorporates a reverse mode (yellow on black) LCD display, shown below. The screen contains two lines with 40 characters per line; it is used to extend features and gain access to the system including the SIMPL program.
  • Page 13 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Default Info Menu This button displays a list (error log) of the most recent errors. Error messages may be the result of hardware or software failure, hardware incompatibility with software definitions, or a programming error.

  • Page 14: Leading Specifications

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 The Date Set submenu, shown after this paragraph, permits alterations to the current system date, shown on the top line. Use the Dn (down) and Up selection buttons for month, day, and year decremental or incremental changes, respectively.
  • Page 15 The latest software versions can be obtained from the What's New page (SIMPL Windows and Crestron Database sections) or Downloads page (SIMPLWIN and CRESDB Libraries) of the Crestron website (www.crestron.com). New users are required to register in order to obtain access to the FTP site.

  • Page 16: Setup

    IBM Microdrive Y-BUS (3) open "card cage" slots provides 40 Mb/s parallel communications and supports current and enhanced Crestron control cards Z-BUS Single slot provides 300 Mb/s parallel commuincations and supports either the single port 10/100 Ethernet, dual port WAN-LAN-10/100 Ethernet, or dual port WAN-LAN-10/100 Ethernet-USB CAGE2, 3-card cage, installation required for AV2.

  • Page 17: Expandable Memory

    Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Complete the procedure below to attach ears to the unit. The only tool required is a #2 Phillips screwdriver. 1. There are 12 screws (#6-32 x 0.375" LG) that secure the sides of the 2-Series control system top cover.

  • Page 18: Memory Card Removal

    5. Securing a tie wrap around the bussing strip is a useful way to strain relieve the wires connected to the terminal block. Network Wiring The four-wire network cable is used to power Crestron devices. Before making any four-wire network connections, refer to the network interconnection after this paragraph and the cautions that follow.
  • Page 19 (reference: CRESNET) and it is available in plenum or non-plenum versions. NOTE: Each 2-Series integrated dual bus control system has one 4-pin network connector. Use the following Crestron products to interconnect to other devices within a network (some permit network testing):...

  • Page 20: Hardware Hookup

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 Resistance Equation 40,000 Where: R = Resistance (refer to table below). R < L x PF L = Length of run (or chain) in feet. PF = Power factor of entire run (or chain).

  • Page 21: Programming The Lcd Display (Available On Pro2 Only)

    SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use programming language that is completely integrated and compatible with all Crestron system hardware. The objects that are used in SIMPL are called symbols. ® SIMPL Windows offers drag and drop functionality in a familiar Windows environment.

  • Page 22: Creating A Page With Front Panel Editor

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 occur. These objects are initiated by pressing the function button that is associated with it. Default Front Panel Page Creating a Page with Front Panel Editor NOTE: The creation of a front panel page is discussed in this section. For more details, consult the SIMPL Windows help file.
  • Page 23 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System the VCR object. Simply click on the Add button and enter a new name for the new page. For this example, use “Menu2 – VCR Control” as the name. Return to the “Menu1 – Choose Device” and double click on the VCR object. The “Edit Panel Object”...

  • Page 24: Front Panel Symbol

    2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 NOTE: Pages on the Front Panel Editor can be assigned a join number to facilitate controlled page jumps. Use the "CNMSX-Pro/CNRACKX Front Panel Editor" window, as shown after this note, to assign the join number. In the Page Channel area of this window, a specific number can be assigned or with the appropriate button assign the next or highest available.

  • Page 25: Object Types

    The sample discussed in the previous sections utilizes only one of the object types available from the “Edit Panel Object” dialog box, shown below. These object types are not new to Crestron programmers; the same types are available in VisionTools™ Pro-e.

  • Page 26: Memory

    NOTE: If the intent is to load software developed by someone else, then install SIMPL Windows only. Install all three applications to program systems as well. NOTE: The latest version of these applications is available from the Crestron website (www.crestron.com). Crestron ControlCD also carries a version (which may not be as current as the website version).

  • Page 27: Volatile

    EXE file in case files need to be restored at any point.) From a ZIP file: If the downloaded job is from the Crestron website or email, all files may have been compressed into a single archive file with a ZIP extension.
  • Page 28 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 "Copy Program" Window After Begin Copy is selected, the selected files will be archived to the example file C:\CRESTRON\SIMPL\PROGRAMS\EXAMPLE.ZIP. For this ZIP file to be used by SIMPL Windows, select File | Import Archived Program.

  • Page 29: Obtaining Communications

    1. Make sure that no programs accessing the COM port of the PC are running. 2. Select Start | Programs | Crestron | SIMPL Windows to start SIMPL Windows. 3. SIMPL Windows responds with an opening splash screen and may display the “What do you want to do?”...
  • Page 30 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 5. From the Setup menu, verify that Auto Baud Search is checked; refer to illustration after this step. Verifying Auto Baud Search 6. While the Viewport is displayed, select Setup | Communications settings (alternatively, depress Alt+D) to open the “Port Settings”...

  • Page 31: Troubleshooting Communications

    Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System “Port Settings” Window 8. Select Diagnostics | Check Operating System Version (alternatively, depress the F5 key) from the Viewport. The Viewport may display a window as it scans various baud rates. Eventually, a message should appear within the Viewport window showing a version number.
  • Page 32 4. Check the ERR LED on the front of the 2-Series integrated dual bus control system. If the LED is illuminated, unplug the unit and reapply power after a few seconds. If the LED illuminates again, call Crestron customer service. Refer to "Further Inquiries" on page 43.
  • Page 33 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Viewport Message NOTE: If a computer is not hooked up, wait approximately three to four seconds. Release the SW-R button. 5d. If the 2-Series integrated dual bus control system responds, proceed to step 5e.

  • Page 34: Creating The System Program

    SIMPL (Symbol Intensive Master Programming Language) is an easy-to-use programming language that is completely integrated and compatible with all Crestron system hardware. The objects that are used in SIMPL are called symbols.  SIMPL Windows offers drag and drop functionality in a familiar Windows environment.
  • Page 35 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Configure AV2 and PRO2 DEVICE SYMBOL DROP ADDITIONAL LIBRARY REQUIRED WHERE SETUP System Configure the built-in slots. Control Systems Views AV2 With System Configure the available and built-in slots. Card Cage...
  • Page 36 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 Configure AV2 and PRO2 (Continued) DEVICE SYMBOL DROP ADDITIONAL LIBRARY REQUIRED WHERE SETUP Desired IR C2I-IR8 As devices are dropped onto slot 5, they Serial Drivers devices (Slot 5) are assigned to port A through port H, in...

  • Page 37: Converting An Existing System Program

    To convert an existing system program that is configured with a control system other than the AV2 or PRO2, one must verify that SIMPL Windows (v2.0 or later) is running and the Crestron database (v15.6.2 or later) is available. Complete the following steps to execute the conversion.

  • Page 38: Loading The System Program

    Viewport. To upload a SPZ file into the control system, complete the following steps in the order provided. 1. Select Tools | Viewport to open the Crestron Viewport, if it is not already opened.

  • Page 39: Testing The Program After Transfer

    “Cresnet Simpl Program” Window 5. If the "Failure" dialog box opens, repeat steps 3 and 4. If this does not remedy the problem, call Crestron customer service. Refer to "Further Inquiries" on page 43. NOTE: Use of the Make Permanent button is not required for a 2-Series integrated dual bus control system since all transfers are permanently stored.

  • Page 40: Loading Touchpanels

    ID. (This info should be available in the system connection sheets or directly from the programmer.) 2. Select Tools | Viewport to open the Crestron Viewport, if it is not already opened. 3. Select Diagnostics | Report Network Devices (alternatively, depress F4) and verify that the touchpanel to be loaded reports back and is at the expected network ID.
  • Page 41 1. Establish communications with the 2-Series integrated dual bus control system by following the steps listed in "Obtaining Communications" on page 25. 2. From the Crestron Viewport, select File Transfer | Update Control System as shown below. Accessing the "Update Control System" Window 3.

  • Page 42: Acceptable Commands

    Sources include serial communication (RS-232) with a PC via the COMPUTER port. Over Ethernet (via the installed Z-BUS card) the control system can receive commands by CTP (Crestron Terminal Protocol – reserved port number) or Telnet. It is also possible to incorporate a symbol (Console) into the loaded SIMPL Windows program that is capable of running console commands.
  • Page 43 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System List of Acceptable Commands for the 2-Series Integrated Dual Bus Control System COMMAND DESCRIPTION ADDMASTER Add an entry to IP table AUTONEGOT Set auto negotiation for Ethernet device BROADCAST Enable/disable the broadcasting of error messages...

  • Page 44: Problem Solving

    Possible Problems with the Control System Troubleshooting the Control System The table below and on the next page provides corrective action for possible trouble situations. If further assistance is required, please contact a Crestron customer service representative. 2-Series Integrated Dual Bus Control System Troubleshooting...

  • Page 45: Serial Communication Difficulties With Other Devices Connected To The Control System

    Devices Connected to the Control System Passthrough Mode Passthrough mode is accessed from the Crestron Viewport by selecting Functions|Enter Passthrough Mode (CNX / 2-Series only). The window, shown after this paragraph, is used to select the port configuration for passthrough mode.
  • Page 46 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 The listing follows the same order as the system tree in Configuration Manager. The top line of the LCD display provides the COM-type device or card and its port. In the sample shown below, the first active port in the system is the built-in card, port A.

  • Page 47: Further Inquiries

    Amber Technologies at +649-410-8382. Future Updates As Crestron improves functions, adds new features, and extends the capabilities of the 2-Series integrated dual bus control system, additional information may be made available as manual updates. These updates are solely electronic and serve as intermediary supplements prior to the release of a complete technical documentation revision.

  • Page 48: Software License Agreement

    This Agreement may only be modified by a writing signed by an authorized officer of Crestron. Updates may be licensed to You by Crestron with additional or different terms. This is the entire agreement between Crestron and You relating to the Software and it supersedes any prior representations, discussions, undertakings, communications or advertising relating to the Software.
  • Page 49 “applets” incorporated into the Software), the accompanying media and printed materials, and any copies of the Software are owned by Crestron or its suppliers. The Software is protected by copyright laws and international treaty provisions. Therefore, you must treat the Software like any other copyrighted material, subject to the provisions of this Agreement.

  • Page 50: Return And Warranty Policies

    CRESTRON shall not be liable to honor the terms of this warranty if the product has been used in any application other than that for which it was intended, or if it has been subjected to misuse, accidental damage, modification, or improper installation procedures.

  • Page 51: Appendix A: Command Details

    Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Appendix A: Command Details This appendix provides details about each of the acceptable commands that can be interpreted by the 2-Series Integrated Dual Bus Control System. Details include a description of the command, a list of help menus that contain the command, the proper syntax for entering the command, definitions of parameters that maybe included in the syntax, and a list of allowable sources for the command.
  • Page 52 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 Description: This command cancels a connection over the Ethernet, whether to the Telnet or CTP ports. If password protection is enabled, the password has to be re-entered before connection is re-established.
  • Page 53 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System CNETID Description: This command sets the ID number of the system as a slave on the Cresnet network. Help Menu(s): System Syntax: CNETid id Parameters: id - the ID of the panel in hexadecimal notation...
  • Page 54 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 EEPROM Description: This command displays the current parameters stored in EEPROM. Help Menu(s): Device Syntax: Eeprom Parameters: none Possible Source: RS-232, CTP, Telnet ERRLOG Description: This command prints a list of the most recent errors.
  • Page 55 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System FPPASSWORD Description: The front panel password is set with this command. Help Menu(s): Main, System Syntax: FPPWASSWORD password Parameters: password - four digit numerical string using digits 1 through 6.
  • Page 56 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 IPADDRESS Description: This command sets the IP address of the touch panel. The value is stored in permanent memory and requires a reboot before it is recognized. Help Menu(s): Ethernet...
  • Page 57 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System PROGRESET Description: This command reloads and restarts the program. Help Menu(s): System Syntax: PROGRESet Parameters: none Possible Source: RS-232, CTP, Telnet RAMFREE Description: This command displays the space remaining in the ram file system.
  • Page 58 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 RTSCTS Description: This command enables/disables the hardware handshaking on the RS-232 port. If no parameter is entered, the current state is displayed. Help Menu(s): System Syntax: RTScts [ON | OFF]...
  • Page 59 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System TIMEDATE Description: This command sets the time and date of the control system real-time clock. If no parameter is entered, the current time/date is displayed. Help Menu(s): Main, System Syntax:...
  • Page 60 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 WEBPORT Description: This command specifies the port number from which the web server listens. Changing the port (from the well know web server port 80) can protect the system from attacks.

  • Page 61: Appendix B: File System

    Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System Appendix B: File System The file system inside the 2-series control engine can be broken down into two parts. The first part resides on the on-board flash memory and the second resides on the external compact flash/microdrive card.
  • Page 62 2-Series Integrated Dual Bus Control System Crestron AV2 & PRO2 This page intentionally left blank. 58 • Integrated Dual Bus Control System: PRO2 & AV2 Operations Guide - DOC. 5957...
  • Page 63 Crestron AV2 & PRO2 2-Series Integrated Dual Bus Control System This page intentionally left blank. Integrated Dual Bus Control System: PRO2 & AV2 • 59 Operations Guide - DOC. 5957...
  • Page 64 Crestron Electronics, Inc. Operations Guide – DOC. 5957 15 Volvo Drive Rockleigh, NJ 07647 12.01 Tel: 888.CRESTRON Fax: 201.767.7576 Specifications subject to www.crestron.com change without notice.
