Curt Manufacturing 58944 Installation Manual

INSTALLATION MANUAL
Level of Difficulty
Moderate
Electrical Ratings
Signal circuits 7.5-amps per side
Tail / Running Circuits 7.5-amps total
Check vehicle owner's manual or contact
the vehicle manufacturer for more information.
Wiring Location(s)
P1 and P2
Wiring Location Guide*
for Passenger Cars (P)
P1 Behind driver side taillight
housing, outside of trunk
P2 Behind passenger side taillight
housing, outside of trunk
P3 Behind driver side taillight
housing, inside of trunk
P4 Behind passenger side taillight
housing, inside of trunk
P5 Behind driver side rear bumper
P6 Behind center of rear bumper
P7 Behind passenger side rear bumper
P1 P3 P4 P2
P5 P6 P7
* Representative vehicle shown
Tools Required
Fishwire Utility knife
Flathead screwdriver --
58944-INS-RA • PAGE 1
WARNING
Do not exceed product rating or tow vehicle lamp load rating, whichever is lower.
Product Photo
Included Parts
NOTICE
Before you begin installation, read all instructions thoroughly.
Proper tools will improve the quality of installation and reduce the time required.
All steps must be followed to ensure the product will function properly. Once installed,
test for proper function by using a test light or connecting a properly tow vehicle.
Maintenance
Periodic inspection of all wires and connections should be performed
to ensure there is no visible damage or loose connections.
Product Registration and Warranty
CURT Group stands behind our products with industry-leading warranties.
Provide feedback and help us to improve our products by registering your purchase at:
warranty.curtgroup.com/surveys
