- Page 1 Point-of-Use Water Cooler & Ice Dispenser User’s Manual Model: CLPOU720UVF3IC...
-
Page 2: Table Of Contents
Table of Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 Intended Use . -
Page 3: Safety Information
Safety Information WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling, installing, and operating dispenser� WARNING: This product dispenses water at very high temperatures� Failure to use properly can cause personal injury� When operating this dispenser, always exercise basic safety precautions, including the following: Prior to use, this dispenser must be properly assembled and installed in accordance with this manual�... -
Page 4: Intended Use
Intended Use This dispenser is intended to be used in household and similar applications such as: • Staff kitchen areas in shops, offices, and other working environments • Farmhouses • Hotels, motels, and bed-and-breakfast-type environments • Catering and other similar non-retail applications The dispenser is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety�... -
Page 5: Touch Panel Description
Touch Panel Description No . Description Up arrow button LED display Filter indicator icon Self-cleaning UV icon Down arrow button Ice button Lock button Hot water button Cold water button Operational and Technical Specifications Model: CLPOU720UVF3IC Rated Voltage / Frequency 115 V / 60 Hz Hot Water Flow Rate ≥1�2 L/min Rated Power... -
Page 6: Package Contents
Package Contents Part Description Quantity Part Description Quantity Filter flushing tube Carbon block filter Feedwater adapter Shut-off valve tube (7 ft�) (with extra nut) Filter housing Plumber’s tape (for filter flushing) Sediment filter Tube cutter Pre carbon filter Materials Needed Wrench Installation 1 . -
Page 7: Connect To The Cold Water Supply
3 . Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE� The water supply to the unit MUST be from the COLD WATER LINE� Using HOT WATER will severely damage your filters� Turn off the cold water supply, then disconnect the cold water pipe from the cold water supply line�... -
Page 8: Install The Filters And Complete The Installation
Connect the tip of the shut-off valve tube (B) to the left side of the filter housing (C)� Connect the filter flushing tube (A) to the right side of the filter housing (C) and lay the open end of the filter flushing tube (A) over a sink or receptacle to collect water�... -
Page 9: Using The Dispenser
Remove the safety plug from the water inlet hole on the back of the dispenser by pushing in the inlet hole collar and then gently pulling out the plug� Connect the tip of the shut-off valve tube (B) into the water inlet hole on the back of the dispenser�... -
Page 10: Dispense Ice
Dispense Ice NOTE: It takes approximately 1 hour after plugging in dispenser and turning on the ice-making switch to create enough ice to be dispensed� It takes approximately 4 hours for the ice storage chamber to completely fill� Place a drinking glass or container under the ice dispense point and press the ice button to dispense ice� Release the button when your container is full�... - Page 11 • Screwdriver • Clean towel IMPORTANT: BEFORE beginning the cleaning process, dispense ALL ice from the bin by pressing the ice button� Ice bin MUST BE empty before cleaning reservoirs� On the back of the dispenser, switch the red heating, green cooling, black ice making, and blue night light switches to the OFF position, then unplug the dispenser�...
-
Page 12: Filter Replacement Schedule
After all the cleaning solution has been poured in, snap the cover of the ice bin back into place� Replace the top of the dispenser, then secure it by screwing the 2 screws back into place� Turn the valve on the shut-off valve tube to the ON position� Plug in the dispenser� Wait 5 minutes for the filtered water to fill both water reservoirs�... -
Page 13: Filter Specifications
Filter Specifications Sediment Filter Pre Carbon Filter (Sediment, Dirt, and Rust Removal) (Chlorine, Taste, and Odor Reduction) Filter Capacity 950 Gallons Filter Capacity 950 Gallons Flow Rate Flow Rate 0�8 GPM 0�8 GPM Suggested PSI Suggested PSI 14�5 - 58 psi 14�5 - 58 psi Temperature Temperature... -
Page 14: Troubleshooting
Troubleshooting Problem Solution • It takes approximately one hour after setup to dispense cold water� • Make sure the power cord is properly connected to a working outlet� The cold water is not cold • Ensure your dispenser’s back and non-fan-outlet sides are 12 in� (30 cm) from walls, and the fan-outlet side is 19�5 in�... -
Page 15: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Brio Water Cooler (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship�... - Page 16 ©2024 Brio Water Technology, Inc. ©2024 Brio Water Technology, Inc.
