- Page 1 Point-of-Use Water Dispenser & Co ee Maker User’s Manual Model: CLPOU730UVF3CF...
-
Page 2: Table Of Contents
Table of Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Intended Use . -
Page 3: Safety Information
Safety Information WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling, installing and operating the dispenser . WARNING: This product dispenses water at very high temperatures . Failure to use properly can cause personal injury . -
Page 4: Intended Use
Intended Use This appliance is intended to be used in household and similar applications such as: • Staff kitchen areas in shops, offices and other working environments Farm houses • Hotels, motels and other residential-type environments • Bed-and-breakfast environments • Catering and similar non-retail applications •... -
Page 5: Touch Panel Description
Touch Panel Description No . Description Up arrow button LED display Filter indicator icon Self-cleaning UV icon Down arrow button Lock button Hot water button Brew button Cold water button Operational Specifications Model No . CLPOU730UVF3CF Rated Voltage / Frequency 115 V / 60 Hz Heating Power 700 W... -
Page 6: Package Contents
Package Contents Part Description Quantity Part Description Quantity Feedwater adapter Filter flushing tube (with extra nut) Shut-off valve tube (7 ft .) Plumber’s tape Filter housing (for Tube cutter filter flushing) Filters Materials Needed Wrench Installation 1 . Determine Installation Location Place the dispenser upright . -
Page 7: Connect To The Cold Water Supply
3 . Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE . The water supply to the unit MUST be from the COLD WATER LINE . Using HOT WATER will severely damage your filters . Turn off the cold water supply, then disconnect the cold water pipe from the cold water supply line . -
Page 8: Flush The Filters
4 . Flush the Filters Follow this procedure each time you replace your filters . IMPORTANT: Ensure water supply is off before you begin . Connect a filter (D) to the filter housing (C) by twisting the filter (D) clockwise . Connect the tip of the shut-off valve tube (B) to the left side of the filter housing (C) . -
Page 9: Install The Filters And Complete The Installation
5 . Install the Filters and Complete the Installation After flushing, twist each filter (D) clockwise into the filter housings located inside the dispenser cabinet . The sediment filter goes on the left, followed by the pre carbon and carbon block filters . Remove the safety plug from the water inlet hole on the back of the dispenser by pushing in the inlet hole... -
Page 10: Operation
Operation IMPORTANT: This unit has been tested and sanitized prior to packing and shipping . During transit, dust and odors can accumulate in the tank and lines . Dispense and dispose at least one liter of water prior to drinking any water . Turn the Dispenser On/Off IMPORTANT: Before activating heating and cooling switches, ensure water has filled the tanks inside the... -
Page 11: Dispense Cold Water
Dispense Cold Water NOTE: Water will take approximately 1 hour after plugging in and turning on to become completely chilled . Place a drinking glass or container under the tap and press the cold water button to dispense cold water . Release the button when your container is full . -
Page 12: Troubleshooting
Troubleshooting Problem Solution • It takes up to one hour after setup to dispense cold water . • Make sure the power cord is properly connected to a working outlet . • Make sure the back of the dispenser is at least 20 cm from a wall and there is The cold water is not cold . -
Page 13: Filter Replacement Schedule
Filter Replacement Schedule Filter Type Model No . Replacement Schedule Function Performs coarse filtration of inlet water, Sediment NFMPP5M 6-12 months or 950 gallons removing sand, rust, dirt, and other suspended solids . Removes chlorine, and other unpleasant Pre Carbon NFMGAC 6-12 months or 950 gallons tastes and odors . -
Page 14: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Brio Water Coolers (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship . - Page 16 Contact Us Call: +1 844-257-4103 ©2023 Brio Water Technology, Inc.
