- Page 1 Point of Use Water Dispenser Setup Manual Model No.: CLPOU720UVF3BLK...
-
Page 2: Table Of Contents
Table of Contents Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 Intended Use . -
Page 3: Safety Information
Safety Information WARNING: To reduce risk of injury and property damage, you must read this entire guide before assembling, installing and operating the dispenser. WARNING: This product dispenses water at very high temperatures. Failure to use properly can cause personal injury. -
Page 4: Intended Use
Intended Use This appliance is intended to be used in household and similar applications such as: Staff kitchen areas, offices, and other working environments • • Farm houses • Clients in hotels, motels and other residential type environments Bed and breakfast type environments •... -
Page 5: Touch Panel Description
Touch Panel Description Up arrow button – Press to set the time on the clock and increase temperature settings. Clock/Temperature display – Displays the time and water temperature setting for hot and cold water and also indicates when filters must be replaced. Down arrow button –... -
Page 6: Package Contents
Package Contents Part Description Quantity Part Description Quantity Filter flushing tube Pre-carbon filter Shut-off valve tube (7 ft.) Post carbon filter Filter housing Feed water adapter (for filter flushing) (with extra nut) Sediment filter Plumber’s tape Materials Needed Wrench Installation 1 . -
Page 7: Connect To The Cold Water Supply
2 . Connect to the Cold Water Supply CAUTION: DO NOT CONNECT THIS WATER LINE TO A HOT WATER SUPPLY LINE. The water supply to the unit MUST be from the COLD WATER LINE. Using HOT WATER will severely damage your filters. Turn off and then disconnect the current cold water supply line. -
Page 8: Flush The Filters
3 . Flush the Filters IMPORTANT: Follow this procedure every time you replace your filters. IMPORTANT: Ensure the water supply is off before you begin. Connect a filter (D) to the filter housing (C) by twisting the filter (D) clockwise. Connect the tip of the shut-off valve tube (B) to the left side of the filter housing (C). -
Page 9: Install The Filters And Complete The Installation
4 . Install the Filters and Complete the Installation After flushing, twist each filter (D‑F) clockwise into the filter housings located inside the dispenser cabinet. The sediment filter goes on the left, followed by the pre‑carbon filter and the post carbon filter (F). Remove the safety plug from the water inlet hole on the back of the dispenser by pushing in the inlet hole... -
Page 10: Operation
Operation IMPORTANT: This unit has been tested and sanitized prior to packing and shipping. During transit, dust and odors can accumulate in the tank and lines. Dispense and dispose at least one quart of water prior to drinking any water. Turn the Dispenser On/Off IMPORTANT: Before you activate the hot and cold switches, ensure water has filled the tanks inside the... -
Page 11: Dispense Hot Water And Activate Child Safety Lock
Dispense Hot Water and Activate Child Safety Lock CAUTION: This unit dispenses water at temperatures that can cause severe burns. Avoid direct contact with hot water. Keep children and pets away from the unit while dispensing. Never allow children to dispense hot water without proper and direct supervision. -
Page 12: Cleaning And Maintenance
Cleaning and Maintenance This dispenser runs on a continuous UV cleaning cycle. It works for 40 minutes (UV icon on the display is on), turns off for 140 minutes, and then cycles back on again as long as the dispenser is plugged in and on. -
Page 13: Filter Specifications
Filter Specifications Sediment Filter Pre-Carbon Filter (Sediment, Dirt, and Rust Removal) (Taste and Impurity Removal) Filter Capacity Filter Capacity 950 Gallons 950 Gallons Flow Rate Flow Rate 0.8 GPM 0.8 GPM Suggested PSI Suggested PSI 14.5 - 58 psi 14.5 - 58 psi Temperature Temperature 33 - 100 °F... -
Page 14: Warranty
Warranty Brio (“Vendor”) warrants to the original purchaser of the Brio Water Coolers (the “Product”), and to no other person, that if the Product is assembled and operated in accordance with the printed instructions accompanying it, then for a period of one (1) year from the date of purchase, all parts in the Product shall be free from defects in material and workmanship. - Page 16 Contact Us Call: +1 844-257-4103 ©2020 DTWUSA...
