1 Scope of delivery
For professional installation of the filter system the following parts are required:
Filter cartridge (1) with hygienic cap and male thread for screwing into the filter head (2).
Filter head (2) with female thread for mounting the filter cartridge (1), suitable for all filter
cartridge sizes with installation label. An Aquastop and two non return valves (inlet and outlet)
are installed in the filter head.
Bracket (3) for mounting the filter cartridge.
The filter cartridge has to be ordered separately from the filter head. The bracket is included in
the scope of delivery of the filter head.
2 Technical Data
2.1
Dimensions und weights
Total height withour bracket, max. A mm (inch)
Total height with bracket
B mm (inch)
Connection height
C mm (inch)
Distance from floor
D mm (inch)
Installation length
E mm (inch)
Filter cartridge Ø
F mm (inch)
Weight of dry filter cartridge, approx.
kg (lb)
Weight of wet filter cartridge, approx.
kg (lb)
2.2 Operating conditions
Connection thread (intake/outlet)
Nominal flow
Working pressure range
Intake water pressure
Pressure loss at 30 L/h (8 US gallons/h)¹
Pressure loss at 60 L/h (16 US gallons/h)¹
Pressure loss at 180 L/h (48 US gallons/h)¹
Water temperature, min.–max.
Ambient temperature, min.–max.
Ambient temperature during transportation/
storage, min.–max.
Bed volume
Operating position
Minimum flushing volume
¹Bypass setting "2", with a 1.5 m (59.06 inch) hose DN8 fitted to both the intake and outlet.
2.3 Typical capacities and chlorine reduction
Typical capacity at 6 – 12 °dGH²,*
Chlorine reduction according to 5.5.2 EN 14898:2006
Reduction (influent challenge concentration 2.0 mg/l)³
²The actual capacities in operation can be higher or lower than the capacities stated in the table. The capacities depend on the quality of the input water,
the flow rate, the intake water pressure and the flow continuity. The general hardness reduction is reached in accordance with Section 5.5.5 EN 14898:2006
for the stated capacities.
³The concentration of chlorine in water entering the system was reduced to a concentration less than or equal to the permissible limit for water laving the
system, as specified in NSF/ANSI 42. While testing was performed under standard laboratory conditions, actual perfomance of the system may vary.*
T1
Typical filter capacities and bypass settings are listed in Chapter 9.
12
Woda-Pure Mineralizer Mg + Zinc
475 (18
/
)
11
16
500 (19
/
)
11
16
421 (16
/
)
9
16
65 (2
/
)
9
16
125 (4
15
/
)
16
130 (5
1
/
)
8
2.4 (5.3)
4.2 (9.3)
Woda-Pure Mineralizer Mg + Zinc
3
/
" (BSP male)
8
L/h (US gal/h)
200 (53)
bar (psi)
2 – 8 (29 - 116)
bar (psi)
> 1.2 (> 17.4)
bar (psi)
0.05 (0.7)
bar (psi)
0.20 (2.9)
bar (psi)
0.50 (7.3)
°C (°F)
+4 to +30 (+39 to +86)
°C (°F)
+4 to +40 (+39 to +104)
°C (°F)
-20 to +40 (-4 to +104)
L (US gal)
2.00 (0.5)
horizontal or vertical
L (US gal)
5 (1.3)
Woda-Pure Mineralizer Mg + Zinc
L (US gal)
2,050 (542)
Category
1
%
> 50 %
3 Usage and design
3.1
Assigned use
This BWT filter cartridge ...
is only to be used for decarbonizing cold water fulfilling the legal requirements for drinking
water.
reduces total* hardness and thus protects appliances against lime scale deposits.
improves flavour of bevarages by removing substances responsible for taste and odor (eg.
chlorine).
minearalizes drinking water with zinc and magnesium.
filters particles* out of the water.
Any other use is deemed to be non-intended.
3.2 Design and function of the filter system
1 Pre-filtration: Removal of particles
2 Active carbon pre-filtration: Substances responsible for taste and odor (e.g. chlorine) are
removed
3 Ion exchanger: Reduction of total hardness and mineralisation with zinc and magnesium
4 Active carbon filtration: removal of chlorine, also from bypass water
1
5 Particle filter: removal of particles
NOTE!
f The bypass setting on the filter head does not have a function for this filter cartridge.
4 Operating and safety instructions
Despite complying with all safety precautions, risks remain especially in case of misuse or
inappropriate handling. Each technical device is to be maintained and serviced regularly to
function properly.
I
WARNING!
f Any use contrary to the intended use, e.g., if the filter system is fed with water that is not of
drinking water quality, results in a health hazard when the water is drunk:
2
- Microbiological hazard due to contamination with pathogenic germs
- Hazard from too high a concentration of heavy metals or organic contamination
f To protect the drinking water, maintanance and any other work on the filter system has to be
carried out considering national directives for drinking water installations (e.g. DIN 1988, EN
1717) and applicable state and local regulations.
f If the authorities or the operator of the water supply system release instructions to boil the
potable water due to microbial contamination it is necesary to boil the filtered water before
consumption. If the drinking water quality is restored the filter system must be replaced and
connections cleaned.
f Two type-tested non-return valves (in accordance with DIN EN 13959) are included in the
filter head.
f Separate the filter system from the water supply prior to maintenance work on the drinking
water supply. Rinse the water line before reconnecting the filter system.
f Disconnect the power supply of the appliance prior to installation.
EN
3
13
