- Page 1 DALMIERZ LASEROWY INSTRUKCJA PL LASER DISTANCE METER USER MANUAL EN DL-X40, DL-X60, DL-X80, DL-X100 DL-XG50, DL-XG70, DL-XG100...
- Page 2 DO NOT STARE INTO BEAM LASERSTRAHLUNG LASERSTRAHLUNG NICHT IN DEN STRAHL BLICKEN NICHT IN DEN STRAHL BLICKEN λ635nm,P < 1mW λ510-520nm, P < 1mW EN 60825-1:2007 EN 60825-1:2007 2014/30/EU 2014/30/EU 4 x 1,5V AAA 3 x 1,5V AAA WWW.FIRMA-PRO.PL WWW.FIRMA-PRO.PL...
- Page 8 lub DL-XG...
-
Page 9: Lcd Screen Description
EN 60825-1:2007 EN 60825-1:2007 2014/30/EU 2014/30/EU 4 x 1,5V AAA 3 x 1,5V AAA prohibitions will result in the loss of warranty. WWW.FIRMA-PRO.PL WWW.FIRMA-PRO.PL LCD SCREEN DESCRIPTION area, volume, and indirect measurement memory measurement function battery status indicator laser beam indicator... -
Page 10: Battery Replacement
BATTERY REPLACEMENT The rangefinder is powered by AAA 1.5V alkaline batteries. The battery status is displayed on the LCD screen. To replace the batteries, remove the cover located on the back of the rangefinder. Be careful about the battery polarity, insert new batteries, and close the cover. It is recommended to remove the batteries if the device will not be used for a long time. -
Page 11: Single Measurement
SINGLE MEASUREMENT Single Measurement Press to activate the laser beam. After pressing again, a distance measurement will be taken, and the result will be displayed on the screen. There is a possibility to measure both horizontal and vertical distances (see Indirect Measurement). CONTINUOUS MEASUREMENT Holding down in single measurement mode activates the continuous measurement function. - Page 12 INDIRECT MEASUREMENT Four Pythagorean modes are available in case the user has difficulties with direct measurements. 1. CALCULATE THE LENGTHS OF TWO SIDES BY MEASURING THE HYPOTENUSE AND ANGLE. Press four times, the hypotenuse icon will flash. Then press to measure the length of the hypotenuse (a) and the angle (Alpha) between the hypotenuse and the horizontal.
-
Page 13: Angle Measurement
ADDING AREAS (AND VOLUMES) To perform the first surface measurement (Fig. 1), press . Perform the second surface measurement (Fig. 2). In the lower left corner of the screen, a "+" icon will appear. Repeat the steps as needed. Then press to sum all the performed measurements (Fig. -
Page 14: Technical Specification
TECHNICAL SPECIFICATION TYPE DL-40X DL-60X DL-80X DL-100X DL-50XG DL-70XG DL-1000XG Measurement Range (from 0,05 m to) 40 m 60 m 80 m 100 m 50 m 70 m 1000 m Resolution 0,001 m Measurement Accuracy ±2 mm Measurement Time (6Hz) 0,5 s Laser Type 635 nm, Class 2, <... -
Page 15: Environmental Protection (Disposal)
Do not dispose of the rangefinder with household waste. For additional information, contact a representative of PRO Sp. z o.o. or local authorities responsible for waste management. SET INCLUDES: • Rangefinder series DL - X or DL - XG •... - Page 16 PRO sp. z o. o. www.firma-pro.com ul Strażacka 76, 43-382 Bielsko-Biała, POLAND...
