- Page 1 PM-100 S ERIES Power Meter Operation Guide V5.27.16...
-
Page 2: Table Of Contents
PM-100 Series Contents 1 Introduction ................................2 2 Warranty ................................2 3 Safety Information..............................3 4 Preparing for Operation ............................3 4.1 Unpacking the instrument ..........................3 4.2 Discharged batteries ............................3 4.3 AC operation ..............................4 5 Operation ................................4 5.1 Display and controls ............................4 5.1.1 Keypad ...............................4 5.1.3 LCD ................................4... -
Page 3: Introduction
Accident Returning Product To return product, you must contact PRO to obtain additional information if necessary. To serve you better, please specify the reasons for the return. All delivery and mails should be sent to the following address: 9999 Hamilton Blvd Suite 220 Breinigsville, PA 18031... -
Page 4: Safety Information
PM-100 Series 3 Safety Information Warning • Never look directly into optical outputs or a fiber while the equipment is on. Invisible and visible laser beam may damage your eyes. • Do not short-circuit the terminal of AC adapter I charger and the batteries. Excessive electrical current may cause personal injury due to fumes, electric shock or equipment damage. -
Page 5: Ac Operation
Make sure that the operating voltage is within the range of the local AC voltage. e.g. INPUT: AC1 00- 240V, 50-60Hz. 5 Operation 5.1 Display and controls 5.1.1 Keypad The PRO-100 Series keypad is used to access a wide range of instrument functions. Connector interchangeable FC/PC, FC/ST, FC/SC Function Switches instrument on/off. Long keypress over 2 seconds while powering on is to activate the instrument without Auto-off function. -
Page 6: Turning The Instrument On And Off
Press and hold the "REF" key over 2 seconds to store the presently measured value as the new reference level for the current wavelength. Once the new reference level is set, the LCD displays 0.00dB with the beeper of the buzzer and the PRO-100 Series switches to the dB measurement mode. Checking the reference level Press the "REF"... - Page 7 PM-100 Series Precision Rated Optics, Inc Corporate Office Billing & Processing PO Box 877 Trexlertown, PA 18087 Precision Rated Optics, Inc Product Distribution Center Manufacturing & Testing 9999 Hamilton Blvd Suite 220 Breinigsville, PA 18031 888-545-1254 | www.PrecisionRatedOptics.com...
