Page 2 If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one of the following measures: Reorient or relocate the receiving antenna.
Page 3 EN 60950 Product Safety EN 300 328 Technical requirement for radio equipment EN 301 489-1/-17 General EMC requirements for radio equipment Trademark recognition All product names used in this manual are the properties of their respective owners and are acknowledged.
Page 4: Table Of Contents
Rear Panel ......................7 Desktop Installation ....................7 Rack-mounted Installation ..................8 3. NETWORK APPLICATION 4. CONSOLE MANAGEMENT Login in the Console Interface ................14 Main Menu ......................15 Function Description ................... 17 Status and Counters Port Status Port Counters...
Page 5 System Reboot TFTP Configuration X-modem Upgrade 5. WEB-BASED MANAGEMENT About Web-based Management ................. 66 Preparing for Web Management ................. 66 Online Help ......................67 System Login ...................... 67 Port status ......................67 View the Port Information Port Statistics ...................... 69 Administrator .......................
Page 6 TFTP Backup Configuration Factory Default ....................104 System Reboot ....................105 Panel List ......................105 IP Stacking ......................106 6. TROUBLESHOOTING 7. TECHNICAL SPECIFICATION APPENDIX Console Port Pin Assignments ................. 113 Cables ....................... 114 100BASE-TX/10BASE-T Pin Assignments ............114 LIMITED WARRANTY...
Page 7: Introduction
MDI (Medium Dependent Interface) Port is also called an "uplink port". The MDI port does not cross the transmit and receive lines, which is done by the regular ports (MDI-X ports) that connect to end stations. In general, MDI means connecting to another Hub or Switch while MDIX means connecting to a workstation or PC.
Page 8: Features
Features Confirms to IEEE802.3 10BASE-T, 802.3u 100BASE-TX, 802.3ab 1000BASE-T, 802.3z Gigabit fiber 24 10/100 TX plus 2 Gigabit copper/Mini GBIC slot stackable intelligent switch High back-plane bandwidth 8.8Gbps 8K-entry MAC address table Management via single IP address IGMP support for Multi Media application...
Page 9: Ethernet Switching Technology
User Guide (CD-ROM) Figure 1-2. Package Contents Compare the contents of your TEG-S2620is package with the standard checklist above. If any item is missing or damaged, please contact your local dealer for service. Ethernet Switching Technology Ethernet Switching Technology dramatically boosted the total bandwidth of a...
Page 10 10Mbps node without loss of data. Auto-negotiation and flow-control may require disablement for some networking operations involves legacy equipment. Disabling the auto-negotiation is accomplished by fixing the speed or duplex of a port. Ethernet Switching Technology supplied higher performance at costs lower than other solutions.
Page 11: Hardware Description
Module Switch. physical and functional overview of this Module Switch. Physical Dimension TEG-S2620is’s physical dimensions is 440mm x 161mm x 44mm (L x W x H). Front Panel The Front Panel of the TEG-S2620is consists of 24x 10/100Base-TX RJ-45 ports (Auto MDI/MDIX) and 2 auto detect Giga port which could be Copper Gigabit port or Mini Gigabit Fiber module (optional).
Page 12: Led Indicators
2 auto-detect Gigabit ports—UTP or fiber. Gigabit fiber is the 2 Gigabit ports: mini GBIC module that is optional. When you are using the Gigabit copper port or Mini GBIC port, only one of [Note] them will work, ex: when Gigabit copper port is connecting, then Mini GBIC is disabling.
Page 13: Rear Panel
Table 2-1. The Description of LED Indicators Rear Panel The 3-pronged power plug is located at the rear Panel of the TEG-S2620is as shown in Figure 2-3. The Switch will work with AC in the range 100-240V AC, 50-60Hz. 100~240V AC, 50/60Hz Figure 2-3.
Page 14: Rack-Mounted Installation
Remove adhesive backing from your Rubber Feet. C. Apply the Rubber Feet to each corner on the bottom of the Switch. These footpads can prevent the Switch from shock/vibration. Figure 2-4. Attaching Rubber Feet to each corner on the bottom of the Switch...
Page 15 Figure 2-5. Mount the Switch in 19” Rack Note: For proper ventilation, allow about at least 4 inches (10 cm) of clearance on the front and 3.4 inches (8 cm) on the back of the Switch. This is especially important for enclosed rack installation.
Page 16 Switch works with voltage range of AC in the 100-240VAC, frequency 50~60Hz. Check the power indicator on the front panel to see if power is properly supplied.
Page 17: Network Application
Meanwhile, you can also use fiber ports to connect switches. The distance between two switches via fiber cable can be up to 550 m (multi-mode fiber) or 10 between two switches via fiber cable can be up to 550 m (multi-mode fiber) or 10 kilometer (single-mode fiber).
Page 18: Segment Bridge
Segment Bridge For enterprise networks where large data broadcasts are constantly processed, this switch is an ideal solution for department users to connect to the corporate backbone. In the illustration below, two Ethernet switches with PCs, print server, and local server attached, are both connect to the Switch.
Page 19 Figure 3-2 Department Bridge Applications...
Page 20: Console Management
4. Console Management Login in the Console Interface When the connection between Switch and PC is ready, turn on the PC and run a terminal emulation program or Hyper Terminal and configure its communication parameters to match the following default characteristics of the console port:...
Page 21: Main Menu
There are five selections as follow. Status and Counters: Show the status of the switch. Switch Configuration: Configure the switch. Protocol Related Configuration: Configure the protocol function. System Reset Configuration: Restart the system or reset switch to default configuration. Logout: Exit the menu line program.
Page 22 The control keys provided in all menus: Tab: Move the vernier to next item. Backspace: Move the vernier to previous item. Enter: Select item. Space: Toggle selected item to next configure or change the value. Esc: Exit the current action mode.
Page 23: Function Description
Link: Display port link status. When the port is connecting with the device and work normally, the link status is “UP”. Opposite is “Down”. State: The port current status. “Enable” – it means this port working status is normal. “Disable” – it means this port is not function event the device is...
Page 24: Port Counters
Priority: display the port priority status. Security: display the port security status. Port status interface Port Counters It displays the current port counter information. Select the <Refresh>action to get newest port counter information. Select <Clear> action to set the port counter information back to 0.
Page 25: System Information
Firmware Version: the switch’s firmware version. Hardware Version: the switch’s Hardware version. Kernel Version: the system kernel software version. MAC Address: The unique hardware address assigned by manufacturer. Module Information: display the Module type that you have installed in switch.
Page 26 System Information interface...
Page 27: Switch Static Configuration
Switch Static Configuration In Switch Static Configuration, it has 8 main functions – Administration, Port, Trunk, Port Mirroring, VLAN, Priority, MAC Address, and Misc Configuration. Under each function, there are more sub-functions. We will describe in following paragraph. Switch Configuration interface...
Page 28 Administration Configuration main interface Device Information You can configure the device information. Select <Edit> action to configure. Name: assign the name for the switch. Description: a short description for the switch. Location: the switch location, ex: Taipei. Contact: the contact person or information.
Page 29 Device Information interface IP Configuration You can configure the IP for this switch. The system has the default IP address. You can re-configure or use the default value. 1. Select the <Edit> 2. DHCP: disable or enable the DHCP client function.
Page 30 IP Configuration interface User Name Configuration You can change the console and web management login user name. 1. Select the <Edit> 2. Enter the new user name 3. Select the <Save> User Name Configuration interface...
Page 31: Port Configuration
Select <Edit> Use “Tab” key to move between items. State: Current port status. The port can be set to disable or enable mode. If the port setting is disable then will not receive or transmit any packet. Negotiation: set auto negotiation status of port.
Page 32: Trunk Configuration
2. Using “Tab” key move to the port that want to be added into trunk group. 3. Using “Space” key to mark the port. 4. Using Tab key move to “Trunk #” (ex. Trunk 1, Trunk 2…) to change the Trunk...
Page 33: Port Mirroring Configuration
Port Mirroring Configuration The port mirroring is a method for monitor traffic of switched networks. The specific port can monitor traffic through the mirror ports. The monitored ports in or out traffic will be duplicated into monitoring port. 1. Select the <Edit>...
Page 34 Port Mirroring interface 3. Analysis port: Set the destination port of mirroring packet. All of the packets of mirroring port will be duplicated and sent to Analysis port. 4. Use “Space” key to mark the mirroring port. 5. Select the <Save>.
Page 35: Vlan Configuration
Configure function. Otherwise, user cannot create any new VLAN. 1. Select the <Edit>. 2. Select the VLAN mode by using “Space” key. There are two VLAN modes: PortBase mode and 802.1Q mode. 802.1Q VLAN mode: configuration VLAN ID, Ingress Filter, and Acceptable Frame Type.
Page 36 Select <Edit>. VLAN Name: Type a name for the new VLAN, ex: VLAN01. Group ID: Type the VLAN group ID. The group ID rang is from 1 to 4094. Member: Press ”Space” key to change the member value. There are two types to selected: a.
Page 37 Select <Save> to save the configuration. NOTE: If you had configured the trunk groups, you can see it (ex: Trunk 1, Trunk 2…) in the port list. You also can configure the trunk group as the VLAN member. Create VLAN Group: PortBase interface Create 802.1Q VLAN...
Page 38 Select <Edit>. VLAN Name: Type a name for the new VLAN, ex: VLAN01. VLAN ID: Type a VID (between 1~4094). The default is 1. There are 256 VLAN groups to provided configure. Protocol VLAN: Press “Space” key to choose protocols type.
Page 39 User can edit or delete a VLAN group. Select <Edit> or <Delete> action. Select the VLAN group that you want to edit or delete, then press enter. In <Edit> action, user can modify the member port and remove member ports from this VLAN group.
Page 40 Edit/Delete a VLAN Group interface Group Sorted Mode You can select VLAN groups sorted mode: (1) Name (2) VLAN ID. In the Edit/Delete a VLAN group page will display the result. Select <Edit> Use “Space” key to select the sort mode.
Page 41: Priority Configuration
Priority Configuration You can configure port priority level. There are 0~7-priority level can map to high or low queue. Select <Edit>. Set the Level 0~7 priority, use “Space” key to change the value.. Press “Space” key to select the priority level mapping to high or low queue.
Page 42: Mac Address Configuration
This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again. You can add / modify / delete a static MAC address.
Page 43 Port No.: press “Space” key to select the port number. VLAN ID: enter the Mac address’ s VLAD ID, if the Mac address belongs to any VLAN group. Press “ESC” to go back action menu line.
Page 44 Select <Save> to save all configure value. Delete static MAC address Select <Delete> key. Choose the MAC address that you want to delete and then press “Enter”. When pressing “Enter” will complete deletion. Filtering MAC Address You can add, delete, and edit filtering MAC address.
Page 45: Misc Configuration
After delete Filtering MAC address, you have to select <Save> to complete the deleting operation. Misc Configuration You can configure the switch parameters and stacking function. The stacking function provides you can centralize the control of the switch in the network. For...
Page 46 If enable, the packets queued exceed will be drop. Press Space key to set the time. This valid value are 1sec, 2sec, 4sec and off. Default is off. Low Queue Delay Bound: Limit the low priority packets queuing time in switch.
Page 47 Web GUI configuration interface. Disable: The stacking function is not working. Master: There must have a leader switch to control all other switches in stacking group. You can only assign one switch to be the master switch in one stacking group.
Page 48: Protocol Related Configuration
Protocol Related Configuration You can configure Spanning Tree Protocol, SNMP, LACP, IGMP/GVRP, and 802.1x in Protocol Relate Configuration section. Protocol Relate Configuration interface Spanning tree is a link management protocol that provides path redundancy while preventing undesirable loops in the network.
Page 49 STP Configuration interface STP Setup You must enable Spanning Tree function before configure STP function. Select <Edit>. Use “Space” key to select the option. Select <Save>. STP Setup interface...
Page 50 Select <Edit>. Path Cost: specifies the path cost of the port that switch uses to determine which port are the forwarding ports. Priority: This is mean port priority; you can make it more or less likely to become the root port.
Page 51: Snmp
Press “ESC” goes back action menu line. Select <Save> to save all configure value. On the action menu line you can press <Next Page> to configure port9 ~ port26, press <Previous Page> return to previous page. Per Port Setting interface...
Page 52 SNMP System Options Press <Edit>. System Name: assign a name for the switch. System Contact: Type the name of contact person or organization. System Location: Type the location of the switch. Press “ESC” goes back action menu line. Press <Save> to save configure value.
Page 53 Community Name: type the name of community strings. Write Access: enable the rights is read only or read/write. Read only: Read only, enables requests accompanied by this string to display MIB-object information. Read/Write: Read write, enables requests accompanied by this string to...
Page 54 Add Community Strings interface Edit Community Name Select <Edit> . Choose the item that you want to modify and then press “Enter”. Community Name: type the new name. Write Access: Press “Space” key to change the right. Select <Save>. Edit Community Strings interface...
Page 55 A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps will issue. Create a trap manager by entering the IP address of the station and a community string.
Page 56: Lacp
Add Trap Manager interface Delete Trap Manager Select <Delete> Choose the trap manager that you want to delete and then press “Enter”. LACP The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems on a link to allow their Link...
Page 57 Working Port Num: The max number of ports can be aggregated at the same time. If LACP static trunk group, the exceed ports is standby and able to aggregate if work ports fail. If it is local static trunk group, the number must be the same as group ports.
Page 58 Use “Space” key to select the Port State Activity. Active: The port automatically sends LACP protocol packets. Passive: The port does not automatically send LACP protocol packets, and responds only if it receives LACP protocol packets from the opposite device. Select <Save>.
Page 59 LACP State Activity configuration interface Group Status When you are setting trunk group, you can see the relation information in here. LACP Group State interface...
Page 60: Igmp/Gvrp
IGMP/GVRP You can enable or disable the IGMP/GVRP (GARP VLAN Registration Protocol). Select <Edit> Use “Space” key to change the value Select <Save> IGMP/GVRP Configuration interface...
Page 61: 802.1X Configuration
802.1x Configuration 802.1x Configuration interface 802.1x Setup Select <Edit> Use “Space” key to Enable or Disable the 802.1x. Select <Save>...
Page 62 802.1x Setup interface System Configuration After enabling the IEEE 802.1X function, you can configure the parameters of this function. Select <Edit>. Radius Server IP: set the Radius Server IP address. Shared Key: set an encryption key for using during authentication sessions with the specified radius server.
Page 63 802.1x System Configuration interface Per Port Configuration You can configure 802.1x authentication state for each port. The State provides Disable, Accept, Reject and Authorize. Use “Space” key change the state value. 802.1x Per Port Setting interface...
Page 64 Misc Configuration Select <Edit> Quiet Period: set the period during which the port doesn’t try to acquire a supplicant. TX Period: set the period the port wait for retransmit next EAPOL PDU during an authentication session. Supplicant Timeout: set the period of time the switch waits for a supplicant response to an EAP request.
Page 65: System Reset Configuration
System Reset Configuration You can reset the system back to default value, reboot the system and update the system firmware. System Reset Configuration interface Factory Default Reset switch to default configuration. Press “Y”, switch will load default setting. After finished load default setting, switch...
Page 66: System Reboot
Factory Default interface System Reboot Reboot the switch in software reset. TFTP Configuration It provides user to update firmware or restore EEPROM value or upload current EEPROM value.
Page 67 TFTP Update Firmware interface Update Firmware It provides the TFTP updating firmware. 1. Start the TFTP server, and copy new firmware version image file to the TFTP server. 2. Select <Edit>. 3. TFTP Server IP: type the IP of TFTP server.
Page 68 Update Firmware interface TFTP Restore Configuration You can restore EEPROM value, which saved in TFTP server, from TFTP server. Start the TFTP server. Select <Edit>. TFTP Server IP: type the IP of TFTP server. Restore File Name: type the image file name.
Page 69 TFTP Restore Configuration interface TFTP Backup Configuration You can save current EEPROM value to TFTP server as backup. The backup file can be restore from TFTP server when you need. 1. Start the TFTP server. 2. Select <Edit>. 3. TFTP Server IP: type the IP of TFTP server.
Page 70: X-Modem Upgrade
TFTP Backup Configuration interface X-modem Upgrade Before using X-modem upgrade, disconnect terminal and modify baud rate to 57600bps, then connect again. Press “X” key to start upgrading from X-modem. You will see the following screen displays. Select “send file" under Transfer menu from menu bar.
Page 71 After successfully upgraded the new firmware, please modify baud rate to 9600bps.
Page 72: Web-Based Management
Before to use web management, you can use console to login the Switch checking the default IP of the Switch. Please refer to Console Management Chapter for console login. If you need change IP address in first time, you can use console mode to modify it. The default value is as below: IP Address: 192.168.0.1...
Page 73: Online Help
Key in the user name and password. The default user name and password is “ admin ”. Click “Enter” or ”OK”, then the home screen of the Web-based management appears. TEG-S2620is Port status In Port status, you can view every port status that depended on user setting and...
Page 74 Speed Duplex: display port connection speed. “Config” means the value that user configured. “Actual” means the current value of the port. Flow Control: display the flow control status is “enable” or “disable” in full duplex mode. “Config” means the value that user configured. “Actual” means the current value of the port.
Page 75: View The Port Information
View the Port Information You can direct click the port on the Switch figure on the top of web page. Then, you will see the port information. Port information interface Port Statistics The following information provides a view of the current port statistic information.
Page 76: Administrator
Port Statistics Administrator In Administrator function, it provides the following functions: IP Configuration, Switch Settings, Console Port Information, Port Controls, Trunking, Forwarding and Filtering, VLAN Configuration, Spanning Tree, Port Mirroring, SNMP Management, Security Manager, and 802.1x Configuration.
Page 77: Ip Address
Administrator interface IP Address User can configure the IP Settings and DHCP client function, than clicks Apply button. After reset the IP address, you must reboot the switch. DHCP: disable or enable the DHCP client function. IP Address: assign the switch IP address. The default IP is 192.168.0.1.
Page 78: Switch Setting
Switch Setting In Switch setting, it has three parts of setting – Basic, Advance, and Misc Config. We will describe the configure detail in following. Basic Switch Settings In Basic Switch Setting, it displays the switch basic information. System Name: the name of switch.
Page 79: Advanced Setting
Advanced Setting In Advanced setting, it has two sections – MAC Table Address Entry and Priority Queue Service. After the configuration, click button to complete the Apply configuration. Enable MAC address Aging Out: to enable the MAC address age out function.
Page 80: Misc Config
These options represent the number of high priority packets sent before one low priority packet is sent. For example, 5 High: 1 Low means that the switch sends 5 high priority packets before sending 1 low priority packet.
Page 81 48 times and then drop frame. Enable is in half duplex. If happen collision will retry forever. Hash Algorithm: CRC Hash or Direct Map for MAC address learning algorithm IFG Compensation: Internal Packet Gap time compensation configure. Select to “Enable” or “Disable”.
Page 82 Auto mode needs to be enabled when the router’s IP address is smaller than other switches in the subnet. 2. IGMP needs to be enabled when the router’s IP address is not smaller than other switches in the subnet. This...
Page 83 IGMP client report if it is in Auto mode. All switches must be in disable mode when the VOD server is configured for IGMP Querier. Note: It is suggested that the VOD server switch have the smallest IP address.
Page 84: Console Port Information
Speed: set the speed of each port. Duplex: set full-duplex or half-duplex mode of the port. Flows control: set flow control function is ON or OFF in Full Duplex mode. Back Pressure: set Back Pressure is ON or OFF in Half Duplex mode.
Page 85 Back Pressure to confine the ingress rate to meet the specified rate. In: fill in the port effective ingress rate. The valid range is 0 ~ 999. The unit is 100K. 0: disable rate control. 1 ~ 999: valid rate value.
Page 86: Trunking
Work ports: allow max four ports can be aggregated at the same time. If LACP static trunk group, the exceed ports are standby and able to aggregate if work ports fail. If it is local static trunk group, the number must be as same as the group member ports.
Page 87: Aggregator Information
State Activity page. Click Apply button to delete Trunk Group. Select the Group ID and click Delete button. Delete Trunking—Aggregator Setting interface Aggregator Information When you had setup the LACP aggregator, you will see relation information in here.
Page 88: State Activity
LACP protocol packets from the opposite device. Note: 1. A link having either two active LACP ports or one active port can perform dynamic LACP trunking. 2. A link has two passive LACP ports will not perform dynamic LACP trunking because both ports are waiting for and LACP protocol packet from the opposite device.
Page 89 Trunking – State Activity interface...
Page 90: Forwarding And Filtering
A message sent by a host to the querier to indicate that the host wants to be or is a member of a given group indicated in the report Report message.
Page 91: Static Mac Address
IGMP Snooping interface Static MAC Address When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
Page 92: Mac Filtering
In MAC Address box, enter the MAC address that wants to filter. VLAN ID: If tag-based (802.1Q) VLAN are set up on the switch, in the VLAN ID box, type the VID to associate with the MAC address.
Page 93: Vlan Configuration
A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
Page 94: Port-Based Vlan
VLAN. If the port-based VLAN enabled, the VLAN-tagging is ignored. In order for an end station to send packets to different VLANs, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a...
Page 95 VLAN – PortBase interface Click to create a new VLAN group. Enter the Group name, VLAN ID and select the members of VLAN group. Click Apply VLAN—PortBase Add interface...
Page 96: 802.1Q Vlan
256 VLAN groups to provide configure. Enable 802.1Q VLAN, the all ports on the switch belong to default VLAN, VID is 1. The default VLAN can’t be deleting. GVRP allows automatic VLAN configuration between the switch and nodes. If the switch is connected to a device with GVRP enabled, you can send a GVRP request using the VID of a VLAN defined on the switch;...
Page 97 From the Available ports box, select ports to add to the switch and click button. If the trunk groups exist, you can see it in here (ex: TRK1, TRK2…), and you can configure it is the member of the VLAN or not.
Page 98 802.1q VLAN –Add interface Click . Then you will see the page as follow. Next...
Page 99 ALL: Acceptable all Packet VLAN ID Range: select a range of VLAN ID. There are 16 VLAN ID range. The ports are assigned to the same VLAN ID will be in the same VLAN group. Click Apply To reset back to default value, click button.
Page 100: Spanning Tree
When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. We are recommended that you enable STP on all switches ensures a single active path on the network.
Page 101: System Configuration
You can configure path cost and priority of every port. Select the port in Port column. Assign the Path Cost. The value range is from 1 to 65535. Assign the port priority value. The value range is from 0 to 255. The lowest value has higher priority. Click button.
Page 102: Port Mirroring
Port Mirroring The Port mirroring is a method for monitor traffic in switched networks. Traffic through ports can be monitored by one specific port. That is, traffic goes in or out monitored ports will be duplicated into mirror port. Port Mirroring State: set mirror mode: Disable, RX, TX, and Both.
Page 103: Snmp Management
Note: If you want to disable the function, you must select monitor port to none. Prot Mirroring interface SNMP Management The SNMP is a Protocol that governs the transfer of information between management and agent.
Page 104 You also can define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the changes. System Options Name: enter a name for the switch. Location: enter the switch physical location.
Page 105: Security Manager
A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps will issue. Create a trap manager by entering the IP address of the station and a community string.
Page 106: 100
Radius Server. Shared Key: set an encryption key for use during authentication sessions with the specified radius server. This key must match the encryption key used on the Radius Server. NAS, Identifier: set the identifier for the radius client.
Page 107: Per Port Configuration
Select the port in Port column. Select the state of port. There are four states: Reject: the specified port is required to be held in the Unauthorized state. Accept: the specified port is required to be held in the Authorized state.
Page 108: Misc Configuration
Misc Configuration Quiet period: Set the period during which the port doesn’t try to acquire a supplicant. TX period: Set the period the port waits to retransmit next EAPOL PDU during an authentication session. Supplicant timeout: Set the period of time the switch waits for a supplicant response to an EAP request.
Page 109: Configuration Backup
Also, you can backup the configuration to TFTP server. TFTP Restore Configuration You can restore EEPROM value from TFTP server, but you must put back image in TFTP server, switch will download back flash image. TFTP Server IP Address: fill in the TFTP server IP.
Page 110: Tftp Backup Configuration
TFTP Restore Configuration interface TFTP Backup Configuration You can save current EEPROM value from the switch to TFTP server, then go to the TFTP restore configuration page to restore the EEPROM value. TFTP Server IP Address: fill in the TFTP server IP...
Page 111: System Reboot
System Reboot interface Panel List Display the switch panel GUI. When the switch is in stacking status, it display the slaves panel GUI. When the switch is stand-alone status, it display itself panel GUI. You can click the port on the panel GUI to check port current information.
Page 112: Ip Stacking
IP Stacking This function allows switch to stack up to 8 stackable switches as a unit group. When configuring the stacking function, beware the following points. Any port on the switch can be used to stack. Before configuring the stacking function, make sure all stack switches are in the same network.
Page 113 IP Stacking interface Apply Click button to apply the configuration. When the master switch has configured, you will see the following screen. IP Stacking master switch configure finished interface After you have configured the stacking function, use Cat. 5 cable to connect...
Page 114 IP and the switch name. IP Stacking Finished configuring interface If you want to configure one of switch in stacking group, click the hyper link on the top of screen and login to the switch that you want to configure. You will see the screen of the switch that you have selected.
Page 115: Troubleshooting
STP cable, 10/100Mbps port use 2 pairs twisted cable and Gigabit 1000T port use 4 pairs twisted cable. If the RJ-45 connector is not correct pin on right position then the link will fail. For fiber connection, please notice that fiber cable mode and fiber module should be match.
Page 116: Diagnosing Led Indicators
If the power indicator does turn on when the power cord is plugged in, you may have a problem with power outlet, or power cord. However, if the Switch powers off after running for a while check for loose power connections, power losses or surges at power outlet.
Page 117: Technical Specification
7. Technical Specification 7. Technical Specification This section provides the specifications of TEG-S2620is, and the following table This section provides the specifications of TEG-S2620is, and the following table lists these specifications. lists these specifications. IEEE802.3 10BASE-T IEEE802.3u 100BASE-TX/100BASE-FX IEEE802.3z Gigabit SX/LX IEE802.3ab Gigabit 1000T...
Page 118 8K Mac with Auto Learning MAC address 3Mbits Memory 34Watts(Maximum) Power Consumption 440mm x 161mm x 44mm (L x W x H) Dimensions FCC Class A, CE, UL, cUL, CE/EN60590 EMI & Safety...
Page 119: Appendix
Console Port Pin Assignments Console Port Pin Assignments The DB-9 serial port on the Switch is used to connect to the switch for out-of-band The DB-9 serial port on the Switch is used to connect to the switch for out-of-band console configuration.
Page 120: Cables
-----------SGND ---------- 5 SGND Cables The RJ-45 ports on the switch support automatic MDI/MDI-X operation, so you can use standard straight-through twisted-pair cables to connect to any other network device (PCs, servers, switches, routers, or hubs). Please refer to the following table for cable specifications.
Page 121 In straight-through cable, pins 1, 2, 3, and 6, at one end of the cable, are connected straight through to pins 1, 2, 3 and 6 at the other end of the cable. The table below shows the 10BASE-T/ 100BASE-TX MDI and MDI-X port pin outs.
Page 122: Limited Warranty
Limited Warranty TRENDnet warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. TEG-S2620is 5 years If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or deliver to customer an equivalent product to replace the defective item.
Page 123 FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE. Governing Law: This Limited Warranty shall be governed by the laws of the state of California. Note: AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry 1-Year Warranty Some TRENDnet products include software code written by third party developers.
