TRENDnet TEG-S2620I Specifications

TECHNICAL FEATURES
TEW-503PI (07-28-2005)
26-Port 10/100Mbps Layer 2 Switch w/
Gigabit Ethernet ports and Mini-GBIC Slots
TEG-S2620i (V1.0R)
The 26-Port 10/100Mbps Layer 2 Switch w/ Gigabit Ethernet ports and
Mini-GBIC Slots provides a reliable foundation for a highly scalable
managed department or workgroup.
Powerful layer 2 performance and advanced security management is
provided with an 8.8Gbps switch fabric, SNMP Version 3 support, a 256
entry Access Control List and Multiple Spanning Tree (802.11s)
technology.
Built-in Gigabit Ethernet ports and Mini-GBIC slots provide high speed
uplinks to backbone switching or servers. Configure the switch using
your choice of Telnet, HyperTerminal or a Browser. Additional
management features such as Port Trunking, IGMP snooping, VLAN,
RMON, Jumbo Frame support, RSTP and MSTP allow administrators to
effectively manage departmental work groups.
• 24 x 10/100Mbps Auto-Negotiation and Auto-MDIX RJ-45 ports
• 2 Pairs of 1x 10/100/1000Mbps RJ-45 port and 1x 1000Base Mini-GBIC slot
• 8K MAC, 220 ACL, 4K VLAN and 1K Multicast entries
• Spanning Tree Protocol (RSTP and MSTP) supported
• Static MAC and port based MAC table with 255 display entries
• IEEE 802.3x Flow Control for both half/full duplex support
• Jumbo frame support up to 9K
• Broadcast Storm Filtering protection against constant Broadcast or Multicast traffic
• Access Control List (ACL) with support up to 256 entries
• Port-Based VLAN (256 Groups), IEEE 802.1q Tag-Based VLAN (PVID 1~255)
• 802.1x authentication and authorization with MD5, EAP and TLS
• IP Multicast, Internet Group Management Protocol (IGMP) snooping and Generic VLAN Registration Protocol
(GVRP)
• 4-Level priority queuing for multiple levels of Quality of Service (QoS)
• RMON Group 1, 2, 3, 9 and PING function from the Switch's diagnostic utilities
• Port Mirroring monitors network traffic such as intrusion detection
• Switch management with Simple Network Management Protocol (SNMP V1.0-V3.0, MIB II), Telnet and Web Browser
• In-band control allows for administration from any Ethernet port on the switch
• Console port management over high speed for out-of-band control (115,200 baud rate)
• Upgradeable firmware via Web browser and TFTP program
• LED display for individual port status: link, activity and speed
• Standard 19" (1U) rack mount size (mounting kit included)
gigabit
TEG-S2620i
rev:07. 1 8.2008
