Summary of Contents for TRENDnet TEG-S2620IS
- Page 1 Quick Installation Guide TEG-S2620is H/W: V1...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English ... 1. Before You Start 2. Hardware Installation ... 3. Configure the Switch ... Troubleshooting ... Version 04.04.2009... -
Page 3: English
A RJ-45 network cable Optional Equipment EIA standard 19” rack Mini-GBIC module (e.g. TEG-MGBSX, TEG-MGBS10, TEG-MGBS40, TEG-MGBS80, TEG-MGBS10D35, TEG-MGBS40D35) for Mini-GBIC slots. Application 24-Port 10/100Mbps Layer 2 Stackable Switch with RS-232 Workstation Workstation with 10/100Mbps PCI Adapter (TE100-PCIWN) Workstation with... -
Page 4: Hardware Installation
When the Mini-GBIC slots are in use, port 25 and 26 Gigabit Ethernet ports are disabled. 1. Connect the Power Cord to the TEG-S2620is and then to a power outlet. 2. Connect a RJ-45 network cable from the computer to an available Ethernet port on the TEG-S2620is. -
Page 5: Configure The Switch
3. Configure the Switch Note: It is recommended that you configure the Switch from a wired computer. Before the Switch can be configured, a Static IP address must be assigned to your computer's network adapter in the subnet of 192.168.0.x. Since the Switch's default IP address is 192.168.0.1, make sure no other network... - Page 6 HyperTerminal 1. Connect the RS-232 cable from a serial port on your Windows PC to the console port on your computer. 2. Go to Start -> Programs -> Accessories -> Communications -> HyperTerminal. 3. Enter a name, choose an icon and then click OK.
- Page 7 Enter. By default: password: admin Your configuration is now complete. For detailed information regarding the TEG-S2620is’s configuration and advanced settings, please refer to the Troubleshooting section, User's Guide CD-ROM, or TRENDnet's website at http://www.trendnet.com. To ensure the highest level of customer service and support, please take a moment to...
-
Page 8: Troubleshooting
Connection icon and then click Properties. I typed http://192.168.0.1 in my Internet Browser's Address Bar, but an error message says “The page cannot be displayed.” How can I get into the TEG-S2620is's web configuration page? First, check your hardware settings again by following the instructions in section 2. - Page 9 HyperTerminal? Bits per Second: 9600; Data bits: 8; Parity: None; Stop bits: 1; Flow control: None. I changed the IP address of the switch, but I forgot it. How do I reset my TEG-S2620is? Follow the instructions below: 1) Connect the RS-232 cable from a serial port on your Windows PC to the console port on your computer.
- Page 10 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
- Page 11 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
- Page 12 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 13 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2009. All Rights Reserved. TRENDnet.
