Summary of Contents for TRENDnet TEG-S2600I

  • Page 1 - 1 -...
  • Page 2: Table Of Contents

    1.2 I ................................7 NSTALLATION 1.3 I ..........................9 NITIAL SET UP FOR MANAGEMENT 1.3.1 out-of-band Terminal-mode Management ......................9 1.3.2 In-band management through Ethernet......................10 1.3.3 Telnet management............................. 12 1.4 LED ..........................13 INDICATORS INFORMATION 2. WEB MANAGEMENT FUNCTION..........................14 2.1.
  • Page 3 ................................. 62 ESET YSTEM 2.9. R ..................................62 EBOOT 2.10. E ..............................63 VENT OGGING 3. CONSOLE – BOOT LOADER ............................. 64 3.1 1K X .......................... 65 MODEM IRMWARE UPDATE 3.2 T ............................66 IRMWARE UPDATE 3.3 S IP A ..............................
  • Page 4 4.3.2.2. Community Strings ..............................108 4.3.2.3. Trap Managers ................................111 4.3.3. GVRP................................113 4.3.4. IGMP................................114 4.3.5. LACP (Link Aggregation Control Protocol)....................115 4.3.5.1. Working Port Setting..............................115 4.3.5.2. State Activity................................116 4.3.5.3. LACP Status................................117 4.3.6. 802.1x Protocol ............................119 4.3.6.1.
  • Page 5 5.3. “S IP – A ” ..............134 INGLE GENT MODE APPLICATION USED WITH SWITCH 5.3.1 Typical setup of “Single IP-Agent mode” network: ..................135 5.4. “S IP - S ” ......138 INGLE TACKING MODE APPLICATION USED WITH SWITCH USED WITH SWITCH 5.4.1 A guide to build up “Stacking Switches”.......................
  • Page 6: Introduction

    A stacking mode is introduced here to enhance the ability of VLAN. An integrated UI not only displays the link status of the stacking sets, but also gives the easy way to set up their VLAN.
  • Page 7: Installation

    To install, attach the mounting brackets on the switch side panels (one on each side) and secure them with the screws provided. Then, use the screws provided with the equipment rack to mount the switch on the rack.
  • Page 8 The TEG-S2600i can be used with an AC power supply 100-240V AC, 50-60Hz. The AC power connector is located at the rear of the unit. The switch’s power supply will adjust to the local power source automatically and may be turned on without having any or all LAN segment cables connected.
  • Page 9: Initial Set Up For Management

    Flow Control = None Step 2: After setting the above on the PC, then connect your switch device with RS 232 cable, then type the “enter” key, then, the device will response the Main Menu to you and ask you answer the username and password.
  • Page 10: In-Band Management Through Ethernet

    Before you can access the switch, you have to know following things. First you have to know the IP Address and Subnet Mask of both your switch and your PC. The default value of the IP Address and Subnet Mask within the switch can be got through terminal mode operation described in chapter 4, while the IP Address and Subnet Mask of PC can be found in your PC system.
  • Page 11 Modify the IP configuration value within the switch to match the rule In the step 3, you must use the data that get from step 2 to modify the default value within the switch, to achieve this, use terminal mode operation mentioned in 1.3.1. After modifying the IP address, Subnet Mask, Default Gateway in the switch, then save the setting and execute the browser program with http:// IP_Address_ of_ switch, then you may access the switch with following dialogue below.
  • Page 12: Telnet Management

    Telnet program. Again, after proper setting to the switch, save the setting and connect your Ethernet cable from your PC to any port of the Ethernet Switch, then you can simply typing as following at the command line to access the switch: Telnet IP_Address_of_Switch The following dialogue below appears.
  • Page 13: Led Indicators Information

    1.4 LED indicators information There are many LEDs on the front panel of switch, after the power on, these LEDs will reflect the current status truly within the switch, we explain below: There is one power LED on the left side of front panel, whenever power is applied, it lights with green, below it, there is Diagnostic LED, it will go blinking during the power-on diagnostics.
  • Page 14: Web Management Function

    ASIC Version: Display the switch’s ASIC version. On the top of web page, there is a link status from image of front panel; every port will be with a connector icon if this port is really linked with others, you also may click the function that listed at left.
  • Page 15: Port Status

    2-8. Reset System 2-9. Reboot 2.2. Port status This page provides current status of every port that depends on user’s setting and the negotiation result. 1. State: Display port statuses: disable or enable. “Unlink” will be treated as “off”. 2. Link Status: Down means “No Link”, UP means “Link”.
  • Page 16: Single Port Counter And Status

    User can also click any port directly on the front panel of Home Page to get single port Status which is shown below. There is a flow rate historical chart on the right. User can track the flow rate of this port in the past 60 hours. Changing the scale will re-calculate the chart.
  • Page 17: Port Statistics

    2.3. Port Statistics There are three pages the switch provides for user to monitor the statistics of network traffic: Port Summary, RMON Statistics(1), RMON Statistics(1) Graph, RMON Statistics(2). The Above information provides a summary of the current switch’s status, including on/off state, link status, good or bad packets of transmitting and receiving, packets of transmitting abort, packets of collision and drop packets.
  • Page 18 - 18 -...
  • Page 19 - 19 -...
  • Page 20: Show Mac Table

    A sorting function is implemented here. Clicking header on the top of table will bring a new sorted list of current content in the order of its title. For instance, clicking the “MAC” on the top of table will refresh the table by the index of “MAC”.
  • Page 21: Administrator

    “Agent Master” means the "Single IP" is activated and the switch is treated as agent manager. ”Stacking slave” is used only when this switch is going to be a member of stacking set. This setting will force the switch to activate spanning tree protocol and some VLAN settings for preparation of stacking switches.
  • Page 22 IP. Different from original IP forwarding method, it uses a method like webpage link and won’t increase the loading of switch. ”Agent IP “setting and “Agent management” in the main menu will not show up if the agent mode is set as “Slave”.
  • Page 23: Switch Setting

    The valid range is 300~765 seconds. Default is 300 seconds. Max bridge transit delay bound control: Limit the packets queuing time in switch. If enable, the packets queued exceed will be drop. These valid values are 1sec, 2 sec, and 4 sec and off. Default is 1 seconds.
  • Page 24: Misc Config

    WRR: Weighted Round Robin. Select the preference given to packets in the switch's high-priority queue. These options represent the number of high priority packets sent before one low priority packet is sent. For example, 5 High : 2 Low means that the switch sends 5 high-priority packets before sending 2 low- priority packets.
  • Page 25: Console Port Information

    2.5.3 Console Port Information Console is a standard UART interface to communicate with Serial Port. User can use windows HyperTerminal program to link the switch. Connect To -> Configure: Bits per seconds: 57600 Data bits: 8 Parity: none Stop Bits: 1...
  • Page 26: Port Controls

    6. Rate Control: port1 ~ port 24, supports by-port ingress and egress rate control. For example, assume port 1 is 10Mbps, users can set its effective egress rate at 1Mbps and ingress rate at 500Kbps. Device will perform flow control or backpressure to confine the ingress rate to meet the specified rate.
  • Page 27 User can disable the port from learning any new MAC addresses, then use the static MAC addresses screen to define a list of MAC addresses that can use the secure port. Enter the settings, then click Apply button to change on this page.
  • Page 28: Trunking

    Partner Systems on a link to allow their Link Aggregation Control instances to reach agreement on the identity of the Link Aggregation Group to which the link belongs, move the link to that Link Aggregation Group, and enable its transmission and reception functions in an orderly manner. In conclusion, Link aggregation lets you group up to eight consecutive ports into a single dedicated connection.
  • Page 29: Aggregator Information

    5. Select the ports to join the trunking group. Allow max four ports can be aggregated at the same time. 6. If LACP enable, you can configure LACP Active/Passive status in each port on State Activity page.
  • Page 30: State Activity

    LACP protocol packets from the opposite device. 1. A link that has either two active LACP ports or one active port can perform dynamic LACP trunking. A link has two N/A LACP ports will not perform dynamic LACP trunking because both ports are waiting for and LACP protocol packet from the opposite device.
  • Page 31: Filter Database

    A message sent by a host to the queries to indicate that the host wants to be or is a member of a given group indicated in the report message. Leave Group A message sent by a host to the queries to indicate that the host has quit being a member of a specific multicast group.
  • Page 32: Static Mac Address

    2.5.6.2. Static MAC Address When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 33: Mac Filtering

    1. In the MAC Address box, enter the MAC address that wants to filter. 2. If tag-based (802.1Q) VLAN are set up on the switch, in the VLAN ID box, type the VID to associate with the MAC address.
  • Page 34: Vlan Configuration

    2.5.7. VLAN configuration A Virtual LAN (VLAN) is a logical network grouping that limits the broadcast domain. It allows you to isolate network traffic so only members of the VLAN receive traffic from the same VLAN members. Basically, creating a VLAN from a switch is logically equivalent of reconnecting a group of network devices to another Layer 2 switch.
  • Page 35 Support Protocol-based VLAN In order for an end station to send packets to different VLANs, it itself has to be either capable of tagging packets it sends with VLAN tags or attached to a VLAN-aware bridge that is capable of classifying and tagging the packet with different VLAN ID based on not only default PVID but also other information about the packet, such as the protocol.
  • Page 36: Port Based Vlan

    2. Enter the VLAN name, group ID and select the members for the new VLAN. 3. Click Apply. 4. If there are many groups that over the limit of one page, you can click the “Next Page” to view other VLAN groups.
  • Page 37: Q Vlan

    This page, user can create Tag-based VLAN, and enable or disable GVRP protocol. There are 256 VLAN groups to provide configure. Enable 802.1Q VLAN, the all ports on the switch belong to default VLAN, VID is 1. The default VLAN can’t be deleted.
  • Page 38 802.1v supporting: Port-based VLAN and Port-and-Protocol-based VLAN. We can support both Port-based VLAN and Port-and-Protocol-based VLAN with our product. User set the VID to mark the packet from untagged port. Then, the packet can be scheduled by the way of the IEEE 802.1q.
  • Page 39 5. From the Available ports box, select ports to add to the switch and click “Add >>”. If the trunk groups exist, you can see it in here (ex: TRK1, TRK2…), and you can configure it is the member of the VLAN or not.
  • Page 40 From the main Tag-based (IEEE 802.1Q) VLAN page, click Port VID Settings. Port VID (PVID) Set the port VLAN ID that will be assigned to untagged traffic on a given port. This feature is useful for accommodating devices that you want to participate in the VLAN but that don’t support tagging.
  • Page 41: Spanning Tree

    2.5.8. Spanning Tree The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. Enable STP to ensure that only one path at a time is active between any two nodes on the network. You can enable Spanning-Tree Protocol on web management’s switch setting advanced item, select enable Spanning-Tree protocol.
  • Page 42 Delay time before changing from its Spanning-Tree Protocol learning and listening states to the forwarding state. Enter a number 4 through 30. 4. The following parameter can be configured on each port , click set Apply button to modify Parameter Description...
  • Page 43: Port Mirror

    1. Roving Analysis Mode: Press Space key to set mirror mode: Disable \Rx \Tx \Both. 2. Analysis Port: It’ means this port can be used to see all monitors port traffic. You can connect analysis port to LAN analyzer or netxray.
  • Page 44: Snmp/Trap Manager

    SNMP community strings. User can also define a name, location, and contact person for the switch. Fill in the system options data, and then click Apply to update the changes on this page. Name: Enter a name to be used for the switch.
  • Page 45 - 45 -...
  • Page 46: Security Manager

    2.5.11 Security Manager On this page, user can change user name and password with following steps. 1. User name: Type the new user name. 2. Password: Type the new password. 3. Reconfirm password: Retype the new password. Click Apply. - 46 -...
  • Page 47: Configuration

    2.5.12 802.1x Configuration System Configuration 802.1x makes use of the physical access characteristics of IEEE802 LAN infrastructures in order to provide a means of authenticating and authorizing devices attached to a LAN port that has point-to-point connection characteristics, and of preventing access to that port in cases in which the authentication and authorization process fails.
  • Page 48 Misc Configuration In this page, you can change the default configuration for the 802.1x standard: Quiet Period: Used to define periods of time during which it will not attempt to acquire a supplicant (Default time is 60 seconds). Tx Period: Used to determine when an EAPOL PDU is to be transmitted (Default value is 30 seconds).
  • Page 49: Ping

    2.5.13 Ping This switch provides a simplified ping function for user to check whether a IP is on line or not. Input the IP Address and counts of ping packet to send. Press “Apply” to continue next page. This page will display the result of the pinging IP . It continues updating the “Reply Counts” when the ping packets are sending.
  • Page 50: Single Ip

    2.5.14 Single IP This switch provides a new management tool for user to manage a group of LAN switches by an IP agent method. “Single IP” is the name, meaning that the administrator can access other network devices through one single IP device. There are two management modes ,”Agent mode” and “Stacking mode”, to utility the function.
  • Page 51: Agent Management

    “Add/Edit”. The new member will be listed on the left. To edit a member’s host name, select the member in the list and the IP and name will be shown on the right. Edit the name and then press “Add/Edit”...
  • Page 52: Agent Manager

    Note: Commands from agent manager can not pass over current management level, meaning that, in case that a slave host is a single IP switch with its agent function enable, user launch the slave host’s agent manager and he will find the agent manager is replaced by the slave’s one. Much worst, commands to pick the slave hosts will case unexpected forwarding error here.
  • Page 53: Stacking Management

    Press “Find >>” and the found stackable switches will be gathered in “Auto Discover List”. Select these found members and press “ << Add” to add the selected hosts to the list. The searching range bases on Class C IP domain within Agent IP. Changing “Agent IP” in “Administrator/IP &...
  • Page 54 “Apply” to complete the addition of a new member. Editing an existing member is also easy thing to do. Select the host which needs to edit and the “IP address” and “Host Name” will appear what you choose. Modify the “Host Name” only for advice.
  • Page 55: Stacking Manager

    Link Status The first page shows the current link status of all stacking members. Link-up ports will glow in their port numbers. An off-line switch will dim to gray if it does not respond to the information request from the stacking master in a period of time.
  • Page 56 VLAN , and all port are added as untagged port; The other VLAN " 4091" , as so called " Stacking Tag VLAN" , is an unique setting for this type of stacking. And all of their Giga ports are set to tag members to form a VLAN connection channel.
  • Page 57 When finishing , press " Apply" to submit. It is always wise to remember that the Giga ports of each member switch are set to tagged port and keeping at least one member port in the master switch.
  • Page 58 VLAN" are undeletable! A error message will pop up to cancel the task. Stack VLAN also can't be edited. PVID SETUP The default PVID value of all ports of 802.1Q VLAN is 1. Hence only default VLAN ( PVID = 1 ) has all of ports as members in the beginning. - 58 -...
  • Page 59 1. Select the PVID to be modified and choose the ports for this PVID value. 2. Click “Apply” button to submit and a message ”Please wait” to notice user to wait patiently. 3. When message “Current setting is on …” shows up, the task is done.
  • Page 60: Tftp Update Firmware

    2.6. TFTP Update Firmware The following menu options provide some system control functions to allow a user to update firmware and remote boot switch system: * Install TFTP program (such as Turbo98, or Cisco TFTP) and then execute. * Copy updated firmware image.bin into TFTP server’s directory.
  • Page 61: Configuration Backup

    2.7.2. TFTP Backup Configuration Use this page to set tftp server ip address. You can save current EEPROM value from here, then go to the TFTP restore configuration page to restore the EEPROM value...
  • Page 62: Reset System

    2.8. Reset System Reset Switch to default configuration, default value as below 2.9. Reboot Reboot the Switch in software reset. - 62 -...
  • Page 63: Event Logging

    2.10. Event Logging A history log is provided here to give a track about events that the switch had happened. There are 100 loggings for maximum capacity of this switch. The latest event will overwrite the oldest one. All records will be kept in flash memory even after writing default, unless user clears the event log.
  • Page 64: Console - Boot Loader

    Each time the switch restarts, user can get some basic information from console (use Hyper terminate 57600 baud rate). After switch tests are done, a 5-seconds countdown timer will prompt user to press any key to enter “User Menu”. There are five functions in the menu: 1.
  • Page 65: Xmodem Firmware Update

    3.1 1K X modem Firmware update We provide the 1k X modem to update firmware from RS232 . 1K X modem only works in 57600bps mode. So you must change baud rate to 57600bps to download firmware. Select “2” to start 1K X modem firmware update.
  • Page 66: Tftp Firmware Update

    After firmware downloading already, the switch will update firmware automatically. After that, the switch will reboot. 3.2 TFTP Firmware update We provide the tftp client to update firmware from Ethernet. User has to install tftp sever in PC first and place the image in the downloading folder. - 66 -...
  • Page 67: Set Ip Address

    Then the tftp downloading begins and , after that, firmware updates. 3.3 Set IP Address We provide a shortcut to set switch IP address and gateway before switch system initialization. User can save his time to change switch IP without waiting system boot up and reconfiguration.
  • Page 68: Diagnose Sdram

    3.4 Diagnose Sdram We provide a basic diagnosis for SDram test. It is important to verify hardware fault or not when a switch becomes unstable. When test is done, it will display the status and prompt user to reset switch.
  • Page 69: Out-Of-Band Terminal Mode Management

    1. TEG-S2600i also provide a serial interface to manage and monitor the switch, user can follow the Console Port Information provide by web to use windows HyperTerminal program to link the switch. 2. You can type user name and password to login. The default user name is “admin”; the default password is “123 ”.
  • Page 70: Main Menu

    Protocol Related Configuration: Configure the protocol function. Status and Counters: Show the status of the switch. Reboot Switch: Restart the system or reset switch to default configuration. TFTP Update Firmware: Use TFTP to download image. Logout: Exit the menu line program.
  • Page 71: Switch Static Configuration

    4.2 Switch Static Configuration <Control Key> You can press the key of Tab or Backspace to choose item, and press Enter key to select item The action menu line as follow provided in later configure page. Actions-> <Quit>: Exit the page of port configuration and return to previous menu.
  • Page 72: Port Configuration

    This page can change every port status. Press Space key to change configures of per item. 1. InRate (100K/unit): User can set input rate control, per unit is 100K. The valid range is 0~1000. 0: disable rate control. 1~1000: valid rate value.
  • Page 73 NOTE: 1. Pressing <Save> only can save one page configuration. 2. If the static trunk groups exist, you can see it (ex: TRK1, TRK2…) after port 26, and you can configure all of the items as above. - 73 -...
  • Page 74: Trunk Configuration

    5. If the item of TRK1~TRK7 is set “Disable”, it’s mean the trunk group is deleted. 6. All ports in the same static trunk group will be treated as single port. So when you setting VLAN members and Port configuration they will be toggled on or off simultaneously.
  • Page 75: Vlan Configuration

    4.2.3. VLAN Configuration 4.2.3.1. VLAN Configure This page can set VLAN mode to port-based VLAN or 802.1Q VLAN or disable VLAN function. - 75 -...
  • Page 76 NOTE: Change the VLAN mode for every time, user have to restart the switch for valid value. If set 802.1Q VLAN, you can set PVID, ingress filtering 1 and ingress filtering 2 in this page too. Actions-> 1. PVID (Port VID: 1~255): Type the PVID.
  • Page 77: Create A Vlan Group

    10. Press Ctrl+A go back action menu line. 11. Select <Save> to save all configure value. NOTE: If the trunk groups exist, you can see it (ex: TRK1, TRK2…) after port26, and you can configure it is the member of the VLAN or not.
  • Page 78 6. Press Ctrl+A go back action menu line. 7. Select <Save> to save all configure value. NOTE: If the trunk groups exist, you can see it (ex: TRK1, TRK2…) after port 26, and you can configure it is the member of the VLAN or not.
  • Page 79: Edit / Delete A Vlan Group

    2. Choose the VLAN group that you want to edit or delete and then press enter. 3. User can modify the protocol VLAN item and the member ports are tagged or un-tagged and remove some member ports from this VLAN group.
  • Page 80: Groups Sorted Mode

    (2) Sorted by VID. The Edit/Delete a VLAN group page will display the result. In the Edit/Delete a VLAN Group page, the result of sorted by name. In the Edit/Delete a VLAN Group page, the result of sorted by VID.
  • Page 81: Misc Configuration

    4.2.4. Misc Configuration - 81 -...
  • Page 82: Ping

    4.2.4.1. Ping Type the Host IP and the counts for pinging, then back to action menu and press “Save”. “Reply Counts” will display the result of pinging. 4.2.4.2. MAC Age Interval Type the number of seconds that an inactive MAC address remains in the switch’s address table.
  • Page 83: Broadcast Storm Filtering

    This page is configuring broadcast storm control. 1. Press <Edit> to configure the broadcast storm filter mode. 2. Press Space key to choose the threshold value. The valid threshold value is 5%, 10%, 15%, 20%, 25% and NO. Default is 5%. - 83 -...
  • Page 84: Max Bridge Transmit Delay Bound

    1. Max bridge transmit delay bound: Limit the packets queuing time in switch. If enabled, the packets queued exceed will be drop. Press Space key to set the time. Those valid values are 1sec, 2sec, and 4sec and off. Default is off.
  • Page 85: Collisions Retry Forever

    2. Press Space key to choose enable / disable item. 3. Press Ctrl+A to go back action menu line. 4. Select <Save> to save all configure value. 5. You can press <Next Page> to configure port9 ~ port26, press <Previous Page> return to last page. 4.2.4.5. Collisions Retry Forever...
  • Page 86: Hash Algorithm

    4.2.4.6. Hash Algorithm Select CRC-Hash(default) or DirectMap for Hash algorithm. 4.2.4.7. IFG Compensation Enable or disable the inter-frame gap (IFG) compensation function. - 86 -...
  • Page 87 - 87 -...
  • Page 88: Administration Configuration

    4.2.5. Administration Configuration 4.2.5.1. Change Username Use this page; user can change web management user name. Type the new user name, and then press <Save> item. - 88 -...
  • Page 89: Change Password

    4.2.5.2. Change Password Use this page; user can change web management login password. 4.2.5.3. Device Information This page is provided to the user to configure the device information - 89 -...
  • Page 90: Ip Configuration

    4.2.5.4. IP Configuration User can configure the IP setting and fill in the new value. - 90 -...
  • Page 91: Port Mirror Configuration

    4. Monitored Port: The ports you want to monitor. All monitor port traffic will be copied to sniffer port. You can select max 25 monitor ports in the switch. User can choose which port to monitor in only one sniffer mode. Press Space key to choose member port, “V” – is the member, “—“ – not the member.
  • Page 92: Priority Configuration

    4.2.7. Priority Configuration 4.2.7.1. Port Static Priority This static priority based on port, if you set the port is high priority, income frame from this port always high priority frame. - 92 -...
  • Page 93: Priority Configuration

    1. Select <Edit>. 2. Press Space key to select the priority level mapping to high or low queue. 3. High/Low Queue Service Ration H:L: User can select the ratio of high priority packets and low priority packets. 4. Press Ctrl+A go back action menu line.
  • Page 94: Mac Address Configuration

    4.2.8. MAC Address Configuration 4.2.8.1. Static MAC Address When you add a static MAC address, it remains in the switch's address table, regardless of whether the device is physically connected to the switch. This saves the switch from having to re-learn a device's MAC address when the disconnected or powered-off device is active on the network again.
  • Page 95 3. Port num: press <Space> key to select the port number. 4. Vlan ID: If tag-based (802.1Q) VLAN are set up on the switch, static addresses are associated with individual VLANs. Type the VID to associate with the MAC address.
  • Page 96 3. Press <Edit> key to modify all the items. 4. Press Ctrl +A to go back action menu line, and then select <Save> to save all configure value. ● Delete static MAC address Actions-> 1. Press <Delete> key. 2. Choose the MAC address that you want to delete and then press enter.
  • Page 97 - 97 -...
  • Page 98: Filtering Mac Address

    1. Press <Add> --> <Edit> key to add a filter MAC address. 2. MAC Address: Type the MAC address to filter. 3. Vlan ID: If tag-based (802.1Q) VLAN are set up on the switch, type the VID to associate with the MAC address.
  • Page 99 2. Choose the MAC address that you want to modify and then press enter. 3. Press <Edit> key to modify all the items. 4. Press Ctrl+A to go back action menu line, and then select <Save> to save all configure value. - 99 -...
  • Page 100 - 100 -...
  • Page 101 Delete filter MAC address Actions-> 1. Press <Delete> key to delete a filter MAC address. 2. Choose the MAC address that you want to delete and then press enter. 3. When pressing <Enter> once will complete deletion on delete mode. - 101 -...
  • Page 102: Protocol Related Configuration

    4.3.1. STP The Spanning-Tree Protocol (STP) is a standardized method (IEEE 802.1D) for avoiding loops in switched networks. When STP enabled, to ensure that only one path at a time is active between any two nodes on the network. - 102 -...
  • Page 103: Enable/Disable Stp

    4.3.1.1. Enable/Disable STP This page is showing the users how to enable or disable Spanning Tree function. Press Space key to select enable or disable. 4.3.1.2. STP System Configuration - 103 -...
  • Page 104 Actions-> 1. You can view spanning tree information about the Root Bridge on the left. 2. On the right, user can set new value for STP parameter. NOTE: All about the parameter description please see the sections 2-4-8. - 104 -...
  • Page 105: Perport Configuration

    3. PathCost: Specifies the path cost of the port that switch uses to determine which port are the forwarding ports. 4. Priority: This means priority port, you can make it more or less likely to become the root port. 5. Press Ctrl +A back to action menu line.
  • Page 106: Snmp

    Any Network Management running the simple Network Management Protocol (SNMP) can be management the switch. Use this page to define management stations as trap managers and to enter SNMP community strings. User can also define a name, location, and contact person for the switch.
  • Page 107: System Options

    4.3.2.1. System Options Actions-> 1. Press <Edit>. 2. System Name: Type a name to be used for the switch. 3. System Contact: Type the name of contact person or organization. 4. System Location: Type the location of the switch. 5. System Description: Type the description about the switch.
  • Page 108: Community Strings

    1. Community Name: The name of current strings. 2. Write Access: Enable the rights is read only or read-write. Restricted: Read only, enables requests accompanied by this string to display MIB-object information. Unrestricted: Read write, enables requests accompanied by this string to display MIB-object information and to set MIB objects.
  • Page 109 3. Write Access: Press Space key to select the right is restricted or unrestricted. Edit Community Name 1. Press <Edit> key, choose the item that you want to modify and then press Enter. 2. Community Name: Type the new name.
  • Page 110 Delete Community Name 1. Press <Delete> key. 2. Choose the community name that you want to delete and then press enter. 3. When pressing <Enter> once will complete deletion on delete mode. - 110 -...
  • Page 111: Trap Managers

    A trap manager is a management station that receives traps, the system alerts generated by the switch. If no trap manager is defined, no traps are issued. Create a trap manager by entering the IP address of the station and a community string.
  • Page 112 1. Press <Edit> key, and then choose the item that you want to modify. 2. IP: Type the new IP address 3. Community Name: Type the community name. 4. Press Ctrl +A go to actions line, press <Save> key to save all configure. Delete trap manager 1. Press <Delete> key.
  • Page 113: Gvrp

    For example, if the switch is connected to a device with GVRP enabled, you can enable this setting to allow dynamic VLAN configuration information to be processed by the switch. If a device sends a GVRP request using the VID of a VLAN defined on the switch, the switch will automatically add that device to the existing VLAN.
  • Page 114: Igmp

    4.3.4. IGMP The Internet Group Management Protocol (IGMP) is an internal protocol of the Internet Protocol (IP) suite. This page you can enable / disable the IGMP support. Actions-> 1. Select <Edit>. 2. IGMP Protocol: Press Space key to choose Enable / Disable.
  • Page 115: Lacp (Link Aggregation Control Protocol)

    4.3.5. LACP (Link Aggregation Control Protocol) This page can configure and view all the LACP status. Note: All ports support LACP dynamic trunk group. If connecting to the device that also supports LACP, the LACP dynamic trunk group will be created automatically.
  • Page 116: State Activity

    3. Press Ctrl+A go back action menu line. 4. Select <Save> to save configure value. NOTE: If user set LACP mode in the trunk group, all of the member ports of this trunk group will set "Active" automatic. - 116 -...
  • Page 117: Lacp Status

    4.3.5.3. LACP Status When you’re setting trunk group, you can see the relational information here. Static trunk group LACP trunk group - 117 -...
  • Page 118 Actions-> <Quit>: Exit this page and return to previous menu. <Previous Page>: Return to previous page to view. <Next page>: Go to the next page to view. - 118 -...
  • Page 119: Protocol

    4.3.6. 802.1x Protocol This page can configure and view all the 802.1x status. 4.3.6.1. Enable/Disable 802.1x - 119 -...
  • Page 120 1.Select <Edit>. 2.Press Space key to choose Enabled / Disabled. 3.Press Ctrl+A go back action menu line. 4.Select <Save> to save configure value. - 120 -...
  • Page 121: System Configuration

    4.NAS, Identifier: A string used to identify this switch. 5.Server Port: The UDP port number used by the authentication server to authenticate. 6.Accounting Port: The UDP port number used by the authentication server to retrieve accounting information. 7.Press Ctrl+A go back action menu line.
  • Page 122: Perport Configuration

    In this page, set the authorization status to activate 802.1x function by port 1. Select <Edit>. 2. Status: Press <Space> key to choose Fu / Fa / Au / No authorization status. 3. Press Ctrl+A go back action menu line.
  • Page 123: Misc Configuration

    4.3.6.4. 802.1x Misc Configuration 1. Press <Edit>. 2. Quiet Period: Used to define periods of time during which it will not attempt to acquire a supplicant (Default time is 60 seconds). 3. Tx Period: Used to determine when an EAPOL PDU is to be transmitted (Default value is 30 seconds).
  • Page 124: Status And Counters

    4.4. Status and Counters You can press the key of Tab or Backspace to choose item, and press Enter key to select item. 4.4.1. Port Status This page display every port status Link Status: Display the port is link or no link.
  • Page 125: Port Counters

    Auto: Display the port is link on which Nway mode: Auto, Nway_Force, and Force. Spd/Dpx: Display the port speed and duplex. FlowCtrl: In auto / Nway force mode, display the flow control status is enable or not after negotiation. In force mode, display the flow control status is enabling or disable depending on user setting.
  • Page 126: System Information

    Firmware Version: Display the switch’s firmware version. ASIC Version: Display the switch’s Hardware version. Module 1 Type: Display the module 1 Type: 1000Tx or 100Fx ext. Depend on module card mode. Module 1 information: Display the information saved in EEPROM of module1.
  • Page 127: Reboot Switch

    4.5. Reboot Switch 4.5.1. Default Reset switch to default configuration, default value please section 2-4-14. 4.5.2. Restart Reboot the switch in software reset. - 127 -...
  • Page 128: Tftp Update Firmware

    4.6. TFTP Update Firmware This page provide user to update firmware or restore EEPROM value or upload current EEPROM value. 4.6.1. TFTP Update Firmware This page provides user use TFTP to update firmware. - 128 -...
  • Page 129: Restore Configure File

    Actions-> 1. Start the TFTP server, and copy firmware update version image file to TFTP server. 2. Press <Edit> on this page. 3. TFTP Server: Type the IP of TFTP server. 4. Remote File Name: Type the image file name.
  • Page 130: Backup Configure File

    4.6.3. Backup Configure File This page user can save current EEPROM value to image file. Then go to the update configure page to restore the EEPROM value. Actions-> 1. Start the TFTP server. 2. Press <Edit> on this page. 3. TFTP Server: Type the IP of TFTP server.
  • Page 131: Application Examples

    Internet access, that are used by all the stations connected to the different Segmented Ports. Virtual LAN, or VLAN, is generally defined as broadcast domain. It can be viewed as a group of end nodes, possibly on different physical network segments, which can communicate with each other.
  • Page 132: Benefits Of Vlans

    Below is a example that R&D, Manufacturing and Administration group can be partitioned into two different VLAN group, even members in different group can’t talk directly, but they still share the same server, such as MRP server, printer server in Adminstration group…etc.
  • Page 133: Trunking Application Used With Switch

    Trunking allows you to increase the available bandwidth between switches by grouping ports into a trunk. Trunk can also be used to connect server to switches for higher bandwidth service required. You can use trunking to improve the throughput between segments. Moreover, this...
  • Page 134: Single Ip - Agent Mode" Application Used With Switch

    Because of the rapid development of Ethernet, the scare of real IP shortage becomes a serious issue when an enterprise continues its IA growth. It is a resource waste and cost a large expense that every individual host has its own real IP inside the enterprise’s network. Privates IPs and...
  • Page 135: Typical Setup Of "Single Ip-Agent Mode" Network

    4. Totally remote control of network devices in private IP domain. It is not necessary for MIS to put all devices together in one place. Single IP function will operate normally no matter how far the distance is between the master and the slave hosts if their packets can reach each other in local area network.
  • Page 136 2. Master and slave switches in different LAN domain. In this example, master will manage 2 slave switches and 1 router in other IP domain. The differences from example1 are that administrator and master switch IP are in the other IP domain (192.168.1.0).
  • Page 137 Switch IP of master is 192.168.1.100. Set its management mode to “Agent Master”. According to the basic rule 1, agent IP should be set in the same domain of slaves, that is, 192.168.223.100. The other procedures are the same as example 1.
  • Page 138: Single Ip - Stacking Mode" Application Used With Switch Used With Switch

    “global view” showing all stacked devices to network administrator as long as he/she accessed to the master switch by using its IP (this IP should be public for remote access through the internet). This will easily let the network administrator know the group settings (e.g.
  • Page 139: A Guide To Build Up "Stacking Switches

    User, who wishes to access the stacking switches from remote IP, should fill up the switch IP with its real IP and the agent IP with the alternative LAN IP; In other hand, for a local area network access only, the switch IP and agent IP should be kept as the same as the LAN IP exactly.
  • Page 140: An Example Of Port-Base Stacking Vlan

    Slave4 (192.168.223.140) Port 23, 24 of Slave5 (192.168.223.150) Test case: 1. PC-0 ping or trace PC-01 and PC-02 ( The same VLAN ) 2. Remove port 9 of Slave4 from VLAN test, and process test1 again. - 140 -...
  • Page 141 Result: 1. PC-0 can access both PC-01 and PC-02. - 141 -...
  • Page 142 2. PC-0 can only access PC-02 only. PC-01 will not reply. - 142 -...
  • Page 143: Issue On Trunk And Stacking Mode

    The packet traffics between stacking members are transferred only through Giga module. Trunking between stacking members may cause the spanning tree protocol (STP) to alter the topology and change the routed ports. If it happens, Giga port traffic may break and the stacking mechanism will fail.
  • Page 144: Compatibility On Virtual Server And "Single Ip

    There are practical applications on combination of virtual server and single IP. Network administrator prefers a router as unique gateway to Internet while he likes to use the “Single IP” to manage his network hosts both from LAN and WAN. This example gives a guide how to setup virtual server with agent/stacking switch.
  • Page 145 According to the basic rule 2 of “Single IP”, administrator accesses the slaves from Internet and master’s Switch IP should differ from its Agent IP. In this case, change Agent IP to 192.168.223.91 to meet the rule, even thought Switch IP and Agent IP are still within the same IP domain.
  • Page 146 - 146 -...
  • Page 147: Limited Warranty

    Limited Warranty TRENDware warrants its products against defects in material and workmanship, under normal use and service, for the following lengths of time from the date of purchase. TEG-S2600i – 5 Years Warranty If a product does not operate as warranted above during the applicable warranty period,...
  • Page 148: Technical Support

    FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL, CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND, OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN CONNECTION WITH...

This manual is also suitable for:

Teg-s2400i

Table of Contents
