OPERATING & MAINTENANCE MANUAL
WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT
PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF
YOUR WASCOMAT MACHINE.
PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S)
DATA PLATE(S).
MACHINE TYPE OR MODEL
MACHINE SERIAL NUMBER(S)
ELECTRICAL CHARACTERISTICS: ________ VOLTS, _______ PHASE, ______ HZ.
MAKE CERTAIN TO KEEP THIS MANUAL IN A SECURE PLACE FOR FUTURE
REFERENCE.
FL 125 HI-TEK
FL 185 HI-TEK
471 1562-56/01
95.32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FL 125 HI-TEK and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wascomat FL 125 HI-TEK

Summary of Contents for Wascomat FL 125 HI-TEK

  • Page 1 OPERATING & MAINTENANCE MANUAL FL 125 HI-TEK FL 185 HI-TEK 471 1562-56/01 95.32 WARNING: ALL OPERATING AND MAINTENANCE PROCEDURES SHOWN ON THE NEXT PAGE OF THIS MANUAL MUST BE FOLLOWED DAILY FOR PROPER OPERATION OF YOUR WASCOMAT MACHINE. PLEASE ENTER THE FOLLOWING INFORMATION AS IT APPEARS ON THE MACHINE(S) DATA PLATE(S).
