ASSA ABLOY
Multi-Point Electromechanical
Overhead Concealed Closer
Holder Releasing Device
with Rigid Slide Arm
For wood or metal doors 1- 3/4" to 2 -1/4" (45-57mm) thick
Hung in a hollow metal frame
Standard butt hinges
Typical Installation
• One track & closer position for all door opening angles
• Easy arm attachment
• Removable Frame Stop Required*-Not Shown
Hinge or
Pivot
Right Hand Door-RH
Left Hand Reverse-LHR
*Not required when frame rabbet exceeds 2-3/16" (56mm).
Copyright © 2002, 2014, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved.
Reproduction in whole or in part without the express written permission of ASSA ABLOY Accessories and
Door Controls Group, Inc. is prohibited.
Support Unit Models
7290 MPI
(Infinite Hold Open Range)
7290 MPS
(Selective Hold-Open Range)
An incorrectly installed or improperly
adjusted door closer can cause property
damage or personal injury. These instructions
should be followed to avoid the possibility
of misapplication or misadjustment.
Left Hand Door-LH
Right Hand Reverse-RHR
ASSA ABLOY
80-9372-1071-020 (01-14)
CAUTION
Hinge or
Pivot
