Assa Abloy ACCENTRA 726 Installation Instructions

726
Strike
Installation Instructions
Strike Angle Must
Engage Strike
Strike Angle and Top Latch Mounting
Plate (2) Mounting Screws 1/4-20 x 3/4
PFHMS
WARNING
This product can expose you to lead which is known to the state of California to cause cancer and birth defects or other
reproductive harm. For more information go to www.P65warnings.ca.gov.
WARNING
Attention Installer: Any retrofit or other field modification to a fire rated opening can potentially impact the fire rating of the
opening, and ASSA ABLOY makes no representations or warranties concerning what such impact may be in any specific
situation. When retrofitting any portion of an existing fire-rated opening, or specifying and installing a new fire-rated opening,
please consult with a code specialist or local code official (Authority Having Jurisdiction) to ensure compliance with all
applicable codes and ratings.
1-855-557-5078 Ext. 2 • www.accentra-assaabloy.com
Copyright © 2013, 2024, ASSA ABLOY ACCENTRA™ Access and Egress Hardware Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Access and Egress Hardware Group, Inc. is prohibited.
ABBREVIATION FASTENER DESCRIPTION
PFHMS PHILLIPS FLAT HEAD MACHINE SCREW
PRHMS PHILLIPS ROUND HEAD MACHINE SCREW
All dimensions are in inches (mm) unless
726 Top
Strike
12-24
PRHMS
Top Latch Case
80-8470-0726-000 04/24
