Assa Abloy ROTRON RIXSON 7200 Series Installation Instructions Manual

7200 Series Overhead Concealed Door Closer
Models 7290 MPS & 7290 RFS
Selective Hold Open & Executive™ Door Release
Holder Releasing Device with Rigid Side Arm
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm. For more information go to:
www.P65warnings.ca.gov.
NOTES:
y For wood or metal doors, 1-3/4" to 2-1/4" (45mm to 57mm) thick, hung in hollow metal frame,
standard butt hinges.
y Removable frame stop required unless frame rabbet exceeds 2-3/16" (56mm). (Not shown)
Typical Installation:
‒ One (1) track & closer position for all door opening angles.
‒ Easy arm attachment.
Hinge or Pivot
Right Hand Door - RH
Left Hand Reverse - LHR
Copyright © 2002, 2014, 2024, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9379-1071-020 Rev 4 11/24
Approved 2024-12-20
CAUTION
An incorrectly installed or improperly adjusted door closer can
cause property damage or personal injury. These instructions
should be followed to avoid the possibility of misapplication or
misadjustment.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
Left Hand Door - LH
Right Hand Reverse - RHR
Hinge or Pivot
