Assa Abloy Norton 7900H-B Series Installation Instructions Manual

ASSA ABLOY
CAUTION
An incorrectly installed or improperly
adjusted door closer can cause property
damage or personal injury. These instructions
should be followed to avoid the possibility
of misapplication or misadjustment.

Typical Installation

•One track & closer position for all door opening angles
•Easy arm attachment
•Removable Frame Stop Required*-Not Shown
Hinge or
Pivot
Right Hand Door-RH
Left Hand Reverse-LHR
*Not required when frame rabbet exceeds 2-3/16"
Copyright © 2001, 2014 Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
Installation Instructions
Series 7900H-B, 7900H-CP & 7900H-OP
For wood or metal doors 1- ¾" to 2 -1/4" (45-57mm) thick
standard butt hinges, center pivots or offset pivots
Overhead Concealed
Door Closers
Hold-Open Models
hung in a hollow metal frame
Left Hand Door-LH
Right Hand Reverse-RHR
Hinge or
Pivot
80-9379-1203-020 (05-14)
