- Page 1 Order-No. 9900.01.33GB02 Serial number Operating Instruction Seed Drill Front hopper, Toolbar...
- Page 3 This concept of intended use also covers the full observance of all operating, maintenance and servicing specifi- cations, along with the exclusive use of original spare parts. The use of non-original accessories, spares and/or consumables that do not carry specific approval from Rabe shall void all warranty liabilities.
- Page 4 We reserve the right to make technical changes. 12.2006...
-
Page 5: Table Of Contents
List of contents Configuration variants Use of the machine for its intended purpose Location of machine identification plate Technical specifications Tractor attachment points Connection of hoses Front-tank attachment Attachment of sowing rail Fitting of electronic control system Transport position / working position Changeover to transport position Changeover to working position: General precautions for transport by road... - Page 6 Attachment of heavy implements Important additional information on the combi- nation of tractor and attached implements The attachment of front and rear-end implements to the corresponding three-point linkage must not cause the maximum permitted total weight to be exceeded with respect to the axle loads of the tractor and/or weight-bearing capacity of its tyres.
-
Page 7: Machine Data
Machine data Front hopper T 01 F, T 1 F T 01 F, T 0 F, T 0 F, Basic type T 01 K T 1 K T 01 K T 0 K T 0 K Weight of front tank when empty, in kg (approx.) Weight of folding sowing rail when empty, in kg (approx.) 5000... -
Page 8: Tractor Attachment Points
Tractor attachment points Connection of hoses - Use the hoop clips (supplied) to attach the hoses to the Cutting hoses to length tractor. - Machine in lowered position (front and back) - The stays (A, B, C) used to attach the hose clip (D) to - Cut hoses to correct length the tractor are not supplied. - Page 9 Pipe installation at tractor end Hoop clips and stays are used to secure the pipe to the tractor. Attachment brackets must be adapted onsite according to the type of tractor. Example of attachment to Fendt Vario 916 Front-end attachment: Fit the stay (1/1) with clip to the tractor and turn the screw to adjust the pivoting range.
-
Page 10: Front-Tank Attachment
Front-tank attachment Attachment of sowing rail Attach tank to front three-point hydraulic connection Fitting the sowing rail - Cat. II or three-way coupling; - Attach the sowing rail, supported on stands (1) to a soil tillage implement. - Attach securely! - Attach securely! Fit front power take-off shaft for blower drive - 1000 rpm, rotates clockwise relative to direction... -
Page 11: Fitting Of Electronic Control System
Transport position / working position Fitting of electronic control system Changeover to transport position Connect the 7-pin electrical cable to the front tank (item S1) - Install the control panel in the tractor cab Actuate the hydraulic control valve on the tractor The lane markers are swung inwards - Secure lane marker with pin (14) The locking flaps (15) must engage in position... -
Page 12: Description Of A Dosing Unit
Description of a dosing unit General points The dosing-shaft monitoring system sends the driver a warning signal whenever the dosing shaft stops during operation (due to drive fault). Note that the two transmitter elements (0) run syn- chronously. - If the left-hand sensor detects a gap, its right-hand counterpart must also stop. - Page 13 Points to observe when adjusting the dosing units Note that the adjustments must be carried out on BOTH front-tank dosing units! 1. Selection of dosing wheels (I, II, III) - Remove the safety pin (39) - To secure the shaft in position, insert the safety pin (39) in the corresponding hole (I, II, Ill).
- Page 14 4. Fitting agitator fingers to the agitator shaft The agitator shaft with finger elements ensures that the seed is fed smoothly and uniformly to the dosing wheels. • The outermost agitator fingers (50) should be set to point inwards • Remove the agitator fingers when handling smooth-rolling peas and beans oleaginous seed-types (the grains might other...
-
Page 15: Lane Markers
Lane markers The disc lane markers are adjustable with respect to the Spuranreißer Fig.15 centre of the tractor (fig. 10). B = operating width A = half operating width Die Scheibenspuranreißer sind auf Schleppermitte einstellbar (Fig. R = space between rows 10). -
Page 16: Distributor
Distributor Making tramlines The dosed seed is evenly allocated by the distributor • Attach the grey connection elements (hoses) to the according to the number of coulters, and fed to the coul- corresponding drill levers (lane width). ters via the spiral hoses. •... -
Page 17: Tail Wheel And Pulse Generator
Tail wheel and pulse generator The tail wheel (31) drives a pulse generator. This sup- plies the electronic control unit with readings for a return Spornrad und Impulsgeber traverse during the drilling process. The electronic control unit constantly calculates the Das Spornrad (31) treibt einen Impulsgeber an. -
Page 18: Coulter-Changeover System
Coulter-changeover system With „front hopper“ operation, the trailing coulters and wide sowing coulters can be replaced without the use of tools. Scharwechselsystem - Unhook the spring (33/1) and pull on the spring reten- tion pin (33/2). Bei der "Fronttank" können Schleppschare und Breitsaatschare werkzeuglos gewechselt werden. -
Page 19: Types Of Rake
Types of rake Coulter rake (fig. 33): For use with trailing coulters only — Designed for sprung attachment to the coulters of the back row — For use on light to medium soil without crop residues. Abb.: 33 Weeder (fig. 38): two-part - Double-row, with trailing tines - For medium and heavy soils Tine pressure can be varied by pulling out and reinser-... -
Page 20: Usage Tips (Quick Startup Guide)
Usage tips (quick startup guide) Carry out checks a short time after sowing begins to Preparing the implement for work ensure - Rut loosener - that all coulters are performing their sowing func - Soil preparation tools tion - Tail wheel - the seed depth is correct - Lane markers - During operation... -
Page 21: Adjusting The Hydraulic Blower Drive
Drilling machines with hydraulic blower drive must be turer. set to the tractor-specific rated drive speed before initial (RABE service engineers are not responsible for the startup. installation on the tractor of the plug-in hydraulic cou The following speed ratings apply to drilling machines. - Page 22 HYDRAULIC BLOWER DRIVE II. 1 Adjustment process for coarse seed Speed measurement – pressure measurement 5. Gradually increase the oil volume to the tractor if the fan nominal speed is not reached. Pressure gauge Hand wheel If the required nominal speed is not reached in this way a further increase in the nominal speed can be reached only by removing individual adapter plates under the hand wheel of the control valve (Fig.
- Page 23 HYDRAULIC BLOWER DRIVE II.2 Adjustment process for fine seed For seed drills with hydraulic fan drives reduced air volume is not reached by regulating the butterfly valve, but by reducing the speed of the fan. Adjustment if carried out as follows: Feinsaat 1.
-
Page 24: Hydraulic Blower Drive With Load Sensing Control
How to adjust HYDRAULIC BLOWER DRIVE Note the following before starting up for the first time: - The adjustment screw on the regulating valve must be set to “0” on the scale (minimum feed quantity). Adjusting hints Hydraulic blower drive with Load Sensing control After initial startup: Before initial operation, ensure - Use this screw to adjust the turning speed. -
Page 25: Drive Shaft
DRIVESHAFT Supplement - B DRIVESHAFT 1) How a cam type cut out safety clutch works: This overload clutch switches Important! Only use the indi- the torque transmitted to zero if cated or accompanying drive overloaded. To revert to normal shaft, otherwise the right to operation, stop the p.t.o. -
Page 26: Safety Precautions
Safety precautions Do not allow anyone to stand between the tractor and the implement during coupling or uncoupling, even if this is to allow operation of the external hydraulic controls. Danger of injury: Always set the tractor’s hydraulic mechanism to “attitude control”... -
Page 27: Arrangement Of Warning Signs On The Device
Arrangement of warning signs on the device 12.2006 We reserve the right to make technical changes.
