IMPORTANT SAFETY
ADVICE
The shower heads and hoses supplied with
this product are a safety critical part of your
shower system. Failure to use genuine Triton
parts may cause injury and invalidate your
guarantee.
INSTALLATION AND
OPERATING INSTRUCTIONS
Please read this book thoroughly and
familiarise yourself with all instructions before
commencing installation.
Keep these instructions in a safe place for
future reference.
2181712A
-
September 2024
UNIQ
Overhead Kit
Advertisement
Related Manuals for Triton UNIQ Overhead Kit
Summary of Contents for Triton UNIQ Overhead Kit
- Page 1 Overhead Kit IMPORTANT SAFETY ADVICE The shower heads and hoses supplied with this product are a safety critical part of your shower system. Failure to use genuine Triton parts may cause injury and invalidate your guarantee. INSTALLATION AND OPERATING INSTRUCTIONS...
-
Page 2: Main Components
MAIN COMPONENTS Lower Arm H. Hose Adaptor Shower Head Shower Hose 1m Wall Bracket x2 Upper Extendable Arm D. Bracket Trim 1 Wall Fixing Screws & Plugs x4 Bracket Trim 2 Washer Collar M. 3.5x12mm Screws & Caps x2 G. Lower Arm Thread Adaptor... - Page 3 DIMENSIONS 380mm to 540mm extendable range 36mm wall to rail centre distance Ø20.5mm rail diameter All dimensions are in mm and are approximate...
- Page 4 POSITIONING THE KIT a) The threaded connection of the Bottom Bracket is to be located within 850mm radius of the threaded connection of the shower unit Outlet Pipe, to prevent strain and kinks on the connecting hose. 850mm MAXIMUM distance shower unit outlet to bottom bracket Bottom bracket must be located within circle...
-
Page 5: Installation
INSTALLATION (RH INSTALL SHOWN, REVERSE IMAGES FOR LH INSTALL) Step Step Step Step Referring to the 'Positioning the Assemble Bracket Trim and Kit' section, determine a suitable threaded adaptors to Bottom postion for the Bottom Wall Wall Bracket Bracket. Hose Using Bottom Wall Bracket as a template, Adapter mark, drill and plug fixing holes for the... - Page 6 INSTALLATION Step Step Ensure suitable wall fixings used. a) Ensuring arm Screws and plugs supplied are for solid assembly is vertical, wall fixing ONLY. slide top Wall Bracket upwards b) Move bracket out of the c) Rotate bracket back into against Collar.
- Page 7 INSTALLATION Step Step Step Step Assemble the Shower Head on Loosen adjustment nut and set to the Upper Shower Arm. Upper Shower Arm to desired position. See Dimensions page for adjustable range. Tigthten adjustment nut to lock Shower Arm in desired position.
- Page 8 E-mail: CXsupport@tritonshowers.co.uk Triton is a division of Norcros Group (Holdings) Limited E-mail: technical@tritonshowers.co.uk Please refer to shower installation and operating instructions for service details TRITON reserve the right to change product speci cation without prior notice. E&OE. © TRITON SHOWERS 2024...
