Triton TYNE Installation Instructions Manual
Monobasin tap
Hide thumbs
Also See for TYNE:
- Installation and operating instructions manual (20 pages) ,
- Installation and operating instructions manual (20 pages) ,
- Installation and operating instructions manual (21 pages)
Related Manuals for Triton TYNE
Summary of Contents for Triton TYNE
- Page 1 TYNE Monobasin tap Installation Instructions NSTALLERS PLEASE NOTE THESE INSTRUCTIONS ARE TO BE LEFT WITH THE USER 2180417B October 2005...
- Page 2 DO NOT choose a position where the tap could become frozen. Replacement parts can be ordered from Triton Customer Service (see back page). WATER PRESSURE This tap is suitable for all water pressures and should be fitted in accordance with Water Regulations.
- Page 3 Monobasin tap INSTALLATION Fig.2 WARNING! The tap must not be positioned Stud where it will be subject to freezing conditions. DO NOT use jointing compounds on any Braided hoses pipe fittings for the installation. Fitting the tap Screw the stud into the hole in the base of the tapunit and secure.
- Page 4 Monobasin tap fixing block onto the control lever. The fixing block is designed to move along the lever to Fig.5 allow for correct positioning (Fig.6). Upper waste outlet Slide the fixing block so that the control rod can Upper silicon fit through the block (Fig.7).
- Page 5 Monobasin tap OPERATION Fig.8 The tap has handwheel controls for both hot and cold. To close the waste gate pull the control rod at the rear of the unit upwards (Fig.9). This will drop the plunger into the outlet. To open the waste gate push the rod down.
- Page 6 Monobasin tap Monobasin mixer...
- Page 7 Monobasin tap...
- Page 8 Replacement Parts Policy To use your Triton Guarantee please contact Triton Customer Service on Availability: It is the policy of Triton to +44 (0) 87 0067 8678 (Scotland maintain availability of parts for the current +44 (0) 84 5762 6591). Please have...
