Summary of Contents for SUNSTONE SUNCHSZ30
- Page 2 IMPORTANT! REFER TO PRODUCT MANUAL FOR A COMPLETE GRILL PLACMENT & INSTALL DESCRIPTION OF INSTALLATION, PLACEMENT AND CUT-OUT. 4. Slide Grill in Place 1. Mount Transformer The Grill is designed with an internal built in hanger Using metal screws and attach the transformer to the flange located at the Right, Left and Back sides.
- Page 3 IMPORTANT! REFER TO PRODUCT MANUAL FOR A COMPLETE BBQ GRILL CUT-OUT DESCRIPTION OF INSTALLATION, PLACEMENT AND CUT-OUT. GRILL IS FREE-HANGING FROM COUNTER TOP ONLY. NEVER BUILD SHELF OR ENCLOSURE BELOW THE GRILL. D. 4,45cm FOR COUNTER WITH ANY OVERHANG BE SURE TO MAKE 4,45cm CUT-OUT IN EACH CORNER A.
-
Page 4: Specifications
MINIMUM 2 VENTS IN "LOW" POSITION FOR PROPANE GAS INSTALLATION ISLAND STRUCTURE MUST BE NON-COMBUSTIBLE OTHERWISE YOU MUST USE GRILL JACKET UNDER ALL GAS APPLIANCES, WE RECOMMEND SUNSTONE'S DESIGNER SERIES CABINET ISLANDS IF COMBUSTIBLE MATERIAL IS LESS-THAN 60,96cm OF BBQ... - Page 5 Stainless Steel Sheet is recommended. ISLAND STRUCTURE MUST BE NON-COMBUSTIBLE NON-COMBUSTIBLE OTHERWISE YOU MUST USE GRILL JACKET UNDER ALL BARRIER SHIELDING GAS APPLIANCES, WE RECOMMEND SUNSTONE'S 2,4 METERS MINIMUM DESIGNER SERIES CABINET ISLANDS CLEARANCE FROM FLOOR TO OVERHEAD STRUCTURE BODILY INJURY: Failure to maintain required clearances creates a fire hazard that may result in property damage or serious personal injury.
- Page 6 IMPORTANT! REFER TO PRODUCT MANUAL FOR A COMPLETE BBQ GRILL IGNITION DESCRIPTION OF INSTALLATION, PLACEMENT AND CUT-OUT. OPEN THE HOOD! Keep Hood Open & ensure Grill Control Knobs are in the OFF position OPEN HOOD WHILE SHUT OFF BURNER OPEN THE DRAWER LIGHTING THE GRILL Stack charcoal briquettes or wood into To shut off the burner, rotate the...
