- Page 1 PRODUCT MANUAL EMERALD SERIES GAS HYBRID CHARCOAL GRILL Read all instructions before you operate your grill. SAVE THIS MANUAL!
-
Page 2: Table Of Contents
5 digits numeric number) Be sure to keep that for your records and any future warranty claims. For warranty service, contact SUNSTONE Customer Service Department at (888)-934- 9449 press option 1 or email service@sunstonemetalproducts.com,... -
Page 3: Grill Safety And Warnings
GRILL SAFTY AND WARNINGS ATTENTION: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. ATTENTION: Indicates a potentially BODILY INJURY: Indicates a potentially hazardous hazardous situation which, if not avoided, may situation which, if not avoided, may result in minor result in minor or moderate personal injury, or... -
Page 4: Clearances And Placement
CLEARANCES AND PLACEMENT ATTENTION: Do Not Build Enclosure around Firebox of Grill, Grill Free-Hangs from Counter Top, DO Not Build Shelf below Grill of any kind. Must have Minimum of Two Vents for this Grill, for Natural Gas place in High Position, and for Liquid Propane place in Low Position. Your grill is SELF-RIMMING, meaning the lip of grill rests on top of the counter edge around the cut-out with the front of grill which is Free-Hanging from counter top. -
Page 5: Grill Specification Guide
GRILL SPECIFICATION GUIDE COOKING SPECIFICATIONS PRODUCT DIMENSIONS Cooking Surface Size - 960 Sq. In. Product Size - 42"W x 27-1/8"D x 28"H Warming Rack Size - 220 Sq. In. Cut-Out Size -39-1/2"W x 22"D x 12-3/4"H Rotisserie Rod Supporting Weight – 35 Pounds Product Weight –... -
Page 6: Island And Gas Setup
ISLAND AND GAS SETUP NOTICE: All Gas Lines for either Liquid Propane or Natural Gas should be installed by a Licensed Professional ONLY! All Liquid Propane Installation with a Large Capacity Side Yard Tank, requires a Medium Pressure In-Line Regulator to be installed by Licensed Professional. Grill includes LP Regulator for 25 Pound Portable Tank only, if you require grill to use Natural Gas, please call our Technical Support Line and request NG-Conversion Kit for Item No. -
Page 7: Step By Step Guide
7. Allow for Ventilation Your Sunstone™ grill is engineered with special vents on the back of unit, which allow proper airflow out of the back of grill. Be sure you allow a minimum of 6-1/2" behind grill for proper air ventilation and to allow hood to open properly. -
Page 8: Lighting The Grill
LIGHTING THE GRILL WARNING: When Lighting the Grill, continue to rapidly press the Black Igniter Button In & Out while allowing the Gas to Flow, if you Do Not hear a Clicking Sound, immediately turn the gas OFF – otherwise gas will continue to flow. Lighting Time 3 to 5 minutes OPEN DRAWER 1. -
Page 9: Grill Parts Diagram
GRILL PARTS DIAGRAM ATTENTION: If you do not see the specific part you are needing replaced, please visit our website at www.sunstonemetalproducts.com, and navigate to “Parts & Accessories” and see either TAB or Menu Link for “Emerald Grill Parts”. For further assistance please call our Technical Support Office at 888-934-9449 press option #1. -
Page 10: Grill Parts Item List
GRILL PARTS ITEM LIST Item No. EMCHDZ42 Parts List NOTES Description Part No. Complete Hood Assembly EM-Hood Hood Mounting Bolt EM-HBolt Hood Louver Vent - Inside EM-LVI Hood Louver Vent - Outside EM-LVO Louver Vent Lever E-LOULEVER Louver Vent Lever Handle E-LOUHAND Hood Thermometer P-ETMeter... -
Page 11: Grill Warranty
User Manual, or the local codes. 4. SUNSTONE is not responsible for warping of component parts due to overheating or using in a way not in line with the product manual.
