SUNSTONE® SERIES
GRILL GAS GRILLS
USE & CARE GUIDE
Read all instructions before you operate your grill.
Conforms to
ANSI STD Z21.58b-2012
Certified to CSA STD 1.6b-2012
Outdoor Cooking Gas Appliance
3174816
To installer or person assembling grill:
Keep this manual for future reference.
To consumer:
www.sunstonemetalproducts.com
Save these instructions!
Leave this manual with grill for future reference.
Advertisement
Table of Contents
Related Manuals for SUNSTONE SUN3B–LP
Summary of Contents for SUNSTONE SUN3B–LP
-
Page 1: Save These Instructions
SUNSTONE® SERIES GRILL GAS GRILLS USE & CARE GUIDE Read all instructions before you operate your grill. Save these instructions! Conforms to ANSI STD Z21.58b-2012 Certified to CSA STD 1.6b-2012 Outdoor Cooking Gas Appliance 3174816 Leave this manual with grill for future reference. - Page 2 Welcome & Congratulations Congratulations on your purchase of a new Sunstone grill! We are very proud of our product and we are completely committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read this manual carefully to understand all the instructions about how to install, operate and maintain for optimum performance and longevity.
-
Page 3: Table Of Contents
Lighting the Grill ----------------- Rot-Rod Setup ----------------------- Knob Maintenance -------------- Sunstone Warranty ------------- BODILY INJURY:Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate personal injury, or property damage. - Page 4 START-UP CHECKLIST ATTENTION:Neveroperate thegrill unattended. ATTENTION:Neveroperate thegrill unattended. EXPLOSION:When Igniting the Grill – Always keep the Hood Open. “FIRST TIME STARTUP CHECKLIST” AA Battery is installed into Black Cap Igniter Box. Burner Mounting Bolts are “Removed” – see page 10 Transformer Electrical Plug is properly installed.
- Page 5 LP hose is clean and inspected for cuts, wear, abrasion, or leaks. Replace if necessarywith a suitable UL,ETLorCSAListed partwith internallythreadedconnection. ATTENTION:All Gas Grill Installations MUST HAVE MINIMUM TWO AIR-FLOW VENTS, either in ELEVATED POSITION for Natural Gas or LOWERED POSITION for Liquid Propane. Your Warranty may be VOID if island does not meet basic setup requirements.
-
Page 6: Sun3B/Sun3Bir
PAGE 1 GRILL SPEC. & PARTS LIST – SUN3B/SUN3BIR – LP/NG Hood Closed OverallWidth-------------------- 28" OverallHeight------------------- 26" Overall Depth-------------------- 25-1/4" ControlPanelHeight----------- 11-1/8" Hood Open Size Counter toTop------------------ 26-1/4" Overall Depth-------------------- 27" HoodOverhang----------------- 2” Cut out Size Width------------------------------ 25” Depth------------------------------- 21-3/4” Height------------------------------ 10-7/8”... - Page 7 GRILL SPEC. & PARTS LIST – SUN3B/SUN3BIR – LP/NG PAGE 2 Page 45...
-
Page 8: Sun3B/Sun3Bir
PAGE 3 GRILL SPEC. & PARTS LIST – SUN3B/SUN3BIR – LP/NG SUN3B/SUN3B-IR-LP/NGParts List SUNSTONE 3 BURNER GRILL Upper Hood Hood-3B & SUNSTONE 3 BURNER HoodHandle Hood-3B-H HoodThermometer P-TMeter W/IR GRILL ARE COMBINED WarmingRack P-WR IN THIS LIST GrillUpperBack Body P-GUBB... -
Page 9: Sun4B/Sun4Bir
PAGE 4 GRILL SPEC. & PARTS LIST – SUN4B/SUN4BIR – LP/NG Hood Closed OverallWidth-------------------- 34" OverallHeight------------------- 26" Overall Depth-------------------- 25-1/4" ControlPanelHeight----------- 11-1/8" Hood Open Size Counter toTop------------------ 26-1/4" Overall Depth-------------------- 27" HoodOverhang----------------- 2” Cut out Size Width------------------------------ 30-3/4” Depth------------------------------- 21-3/4” Height------------------------------ 10-7/8”... - Page 10 GRILL SPEC. & PARTS LIST – SUN4B/SUN4BIR – LP/NG PAGE 5...
-
Page 11: Sun4B/Sun4Bir
GRILL SPEC. & PARTS LIST – SUN4B/SUN4BIR – LP/NG PAGE 6 SUN4B-IR-LP/SUN4B-IR-NG Parts List Upper Hood Hood-4B SUNSTONE 4 BURNER GRILL HoodHandle Hood-4B-H & SUNSTONE 4 BURNER HoodThermometer P-TMeter W/IR GRILL ARE COMBINED WarmingRack P-WR IN THIS LIST GrillUpperBack Body... -
Page 12: Sun5Bir
PAGE 7 GRILL SPEC. & PARTS LIST – SUN5BIR – LP/NG Hood Closed OverallWidth-------------------- 42" OverallHeight------------------- 26" Overall Depth-------------------- 25-1/4" ControlPanelHeight----------- 11-1/8" Hood Open Size Counter toTop------------------ 26-1/4" Overall Depth-------------------- 27" HoodOverhang----------------- 2” Cut out Size Width------------------------------ 39-1/2” Depth------------------------------- 21-3/4” Height------------------------------ 10-7/8”... - Page 13 PAGE 8 GRILL SPEC. & PARTS LIST – SUN5BIR – LP/NG Page 54...
-
Page 14: Sun5Bir
GRILL SPEC. & PARTS LIST – SUN5BIR – LP/NG PAGE 9 SUN5B-IR-LP/SUN5B-IR-NG Parts List Upper Hood Hood-5B HoodHandle Hood-5B-H HoodThermometer P-TMeter WarmingRack P-WR GrillUpperBack Body P-GUBB LightCover P-Lcover IR Burner(Back Burner) P-IRburner ImpulseIgniterWire P-IIW GrillGrates P-GSet5B 10 Gas ManifoldPipe P-GMP 11 SafetyValve P-SAIvalve 12 Auto-Ignition Valve... -
Page 15: Grill Installation
PAGE 10 GRILL INSTALLATION – BURNER BOLT REMOVAL Why is this Important! The intensity of the Gas Burners will gradually erode layers of materials of the Stainless-Steel Burners causing them to eventually Burn-Through, thus causing Flare-Ups. When this happens, you will need to replace the Burners, and if the Burner Bolts are still attached, they may have Corroded and become difficult to later remove. -
Page 16: Gfci Transformer For Lights
PAGE 11 GRILL INSTALLATION – GFCI TRANSFORMER FOR LIGHTS LIVE CIRCUIT:Indicates a potentially hazard from Liveelectrical current that if extreme caution is notused, may result in minor or moderatepersonal injury, or property damage. 1.Locatethetransformer Removethetransformerfrom theplasticbaglocated intheinteriorofgrill.MakesuretheTransformeris complete,anddouble check thegrilllight plugcordis properlysecured to transformer,andall wiresare firmly fixedinto plastic clipplug. -
Page 17: Overview & Requirements
Rimming and is supported by the top counter surface on the Back and Sides, the front of grill is designed to Free-Hang. The bottom of Grill needs to be open to allow for proper ventilation. ” Sunstone Series Grill Island Cut-Out Dimensions ITEM NO. WIDTH... -
Page 18: Airflow & Prevailing Wind
PAGE 13 GRILL INSTALLATION – AIRFLOW & PREVAILING WIND InFIG.B,Excess heatleaves throughbackofgrill, butis blocked by PrevailingWind,causingoverheatingofgrill. 1.Slide GrillinPlace YourSunstone™ grillisspecially designed with aninternalbuiltinhangerlip locatedat the Right,Left andBacksides. Thegrilllipallows it tohangbythe threesupported edgeson the right,leftandback. The front controlpanel requiresnosupportingedge;itisdesigned to hangdownthefrontofyourcut-out. 2.Allow for Ventilation YourSunstone™... -
Page 19: Island Location Open Area Install
PAGE 14 ISLAND LOCATION – OPEN AREA INSTALL Windy Conditions Your grill is specially designed to draw fresh air in through the front, and direct it to the bottom burners. When grilling the hot gases are then released through the back of grill through a venting system. Using your grill in windy conditions may disrupt the front-to-back air flow. -
Page 20: Enclosed Area Install
PAGE 15 ISLAND LOCATION – ENCLOSED INSTALL Clearances to Non-Combustible Construction*: A minimum of 4” to 6” clearance from the back of the grill to non-combustible construction is required for the purpose of allowing the lid to open fully. It is desirable to allow at least 6” rear and side clearance to construction above the cooking surface for counter space. -
Page 21: Lp Gas Hook-Up
INSTALLATION – Gas Hook-Up PAGE 16 GAS SETUP – LP GAS HOOK-UP GAS REQUIREMENTS Verify the type of gas supply to be used, either NG or LP, and make sure the marking on the appliance rating sticker agrees with that of the supply. The rating sticker is located on the back of the Gas Manifold Pipe. -
Page 22: Ng Gas Installation
PAGE 17 GAS SETUP – NG GAS INSTALLATION NG Gas Hook-up NaturalGasgrills isdesigned tooperateonNaturalGasONLY,at apressureregulatedat 7”water column(W.C.) when equippedwiththe correct naturalgas orificesonthevalves andaNG regulatoron thesupply lineregulated at theresidentialmeter. NG Quick Connect Hose Operation For NG Gas Grills, it is shipped with a NG Medium Pressure Regulator &... -
Page 23: Grill Start-Up Lighting The Grill
PAGE 18 GRILL START-UP – LIGHTING THE GRILL EXPLOSION:When Lighting the Grill, Hold the Knob in until Burner Ignites. DO NOT RELEASE KNOB, GAS WILL CONTINUE TO FLOW. ALWAYS IGNITE GRILL WITH HOOD OPEN! WARNING:Neverstand withyour headdirectly overtheGrill when lighting theMain Bottom Burner or Rotisserie Back IR Burner, toprevent possibleinjury. - Page 24 PAGE 19 GRILL START-UP – ROTISSERIE ROD SETUP Rotisserieismostlyusedtocook largepiecesofmeatandpoultrytoassureslow, even cooking. The constant turningprovides aself-bastingaction,making foodcookedonarotisserieexceptionally moist andjuicy.Rotisseriecookinggenerally requires1 ½to4½hourstocookdependingon thesizeandtypeofmeat beingcooked.Youcanhaverotisseriecookingwithindirect heatwithinfraredrotisserieburner. Preferredby professionalchefsoverother methods, theintenseheatisidealforsearinginthenatural juicesandnutrientsfoundin qualitymeats.Forsuccessfulrotisserie,themeatshouldbecenteredand balancedasevenlyaspossibleonthespitrod toavoidoverworkingtherotisseriemotor. 1. Attach Motor BracketAssembly tothesideof thebarbecueframe(can bemounted oneitherleft ortheright sideoftheframe) usingtwoscrews andtwonuts.
-
Page 25: Knob Maintenance
PAGE 20 GRILL START-UP – ROTISSERIE ROD SETUP Rotisserieassemblycanbepurchased Qty. PartNo. Name individuallyeither byindividualitem, or ina 3BurnerRotisserieset P--RK-3B completeset,foryour sizeof grill.Therotisserie assemblycanalso beusedwith or withoutan 4BurnerRotisserieset P--RK-4B infra-red backburner. 5BurnerRotisserieset P--RK-5B ElectricalGroundingInstructions: Therotisseriemotorisequippedwithathree-pronggroundingplugforyourprotectionagainstelectric shock.Thisplugmustbeinserted directlyintoa properlygroundedthree-prongreceptacle.Do not cut orremovethegroundingprongfromthisplug. Therotisseriemotormust beelectrically groundedin accordancewithlocalcodesor,intheabsenceof... - Page 26 PAGE 21 MAINTANCE – GRILL START-UP – KNOB MAINTANCE Knob & Ring Adjustment Knob &RingAdjustment Whileturninganyof the knobsandyounoticeany onestickingorrubbing,Followthesesteps. 1. Turn each knobforany issues 2. Forknobthat rubs orsticks wheneither turned or pushedin,removeknobandunscrewthe fourscrews slightly,soringisloosened. (DONOTREMOVESCREWS COMPLETLEY) ReplaceKnobbackon,MoveKnobRingLeft,Right,Up, andDown, tillit isCenteredaroundKnob,thenremove knob,while holdingringinplace.
-
Page 27: Sunstone Warranty
7. No one has the authority to add to or vary SUNSTONE GRILL warranty, or to create for SUNSTONE METAL PRODUCTS LLC. any other obligation or liability in connection with the sale or use of its products.
