Welcome & Congratulations
Congratulations on your purchase of a new grill! We are very proud of our product and we are completely
committed to providing you with the best service possible. Your satisfaction is our #1 priority. Please read
this manual carefully to understand all the instructions about how to install, operate and maintain for
optimum performance and longevity. We know you'll enjoy your new grill and thank you for choosing our
product. We hope you consider us for future purchases.
How to Obtain Service
Before you call
Is there Gas supplied to the Grill?
Is the battery inserted into igniter box?
Have you recently refilled the LP Tank?
Please make sure you have the following information:
Model Number | Date of Purchase | Serial Number. (The serial number can be located on the rating
plate, which is located on the right under side of grill, above gas manifold pipe.)
For warranty service, contact SUNSTONE Customer Service Department at (888)-934-9449 or email
service@texasbbqwholesalers.com, we will response back within 24 hours.
.
YOUR NAME_________________________________
ADDRESS_______________________________________________________________________________
MODEL NO_____________________________SERIAL NO_______________________________________
COMPANY THAT YOU PURCHASED FROM
Unpacking and Assembly
Your grill arrives nearly ready to use and requires little assembly. Carefully follow these steps, unpack
the grill, removing all packing material and protective film.
1. Cut black plastic straps and lift grill from pallet (WARNING: Grill is very heavy, you will need
help), and position grill near your island where the grill is being installed.
2. Remove the green straps from around the grill box carton.
3. Lift the cardboard box up and off, be sure to tilt it back then turn it upside down so the
Rotisserie Rod and any other packaging materials are retained in box. (It may require two
people). Or open top of box first and remove rotisserie rod, and other packaging material.
4. Remove the plastic wrap that protects the grill.
5. Raise hood and unpack all parts
6. Cut plastic ties that hold the warming rack, side shelves and spit rod.
7. Remove warming rack at the back of grill by lifting up and sliding out.
8. Remove rotisserie motor plus care and use manual
9. Reposition the warming rack at the back of the grill
Must keep copy of your sales slip for proof of purchase.
DATE OF PURCHASE _______________________
________________________________________________
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SUNSTONE SUN4B
Summary of Contents for SUNSTONE SUN4B
- Page 1 Model Number | Date of Purchase | Serial Number. (The serial number can be located on the rating plate, which is located on the right under side of grill, above gas manifold pipe.) For warranty service, contact SUNSTONE Customer Service Department at (888)-934-9449 or email service@texasbbqwholesalers.com, we will response back within 24 hours.
-
Page 2: Placement And Location
INSTALLATION AND ASSEMBLY - Island Safety ATTENTION: Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. Placement and Location Never locate this island in an enclosed room, under any sealed overhead structure, or any type of enclosed area such as a garage, shed, or breezeway, and keep clear of trees and shrubs. - Page 3 INSTALLATION AND ASSEMBLY - Island Safety ATTENTION: Upper and lower air vents (20 sq. in. minimum each) MUST BE PROVIDED on both sides of built-in construction. The height from upper air vent to top surface of island is 5", and the height from lower air vent to the bottom is 5”.
- Page 4 9 Windy Conditions Your Sunstone™ grill is specially designed to draw fresh air in through the front, and in direct to the bottom burners. When grilling the hot gases are then released through the back of grill through a venting system.
- Page 5 In FIG. B, Excess heat leaves through back of grill, but is blocked by Prevailing Wind, causing overheating of grill. 1. Slide Grill in Place Your Sunstone™ grill is specially designed with an internal built in hanger lip located at the Right, Left and Back sides. The grill lip allows it to hang by the three supported edges on the right, left and back.
- Page 6 INSTALLATION AND ASSEMBLY – Locating Grill NOTICE: Ensure grill is installed with proper air flow for correct combustion air and cooling airflow. Airflow MUST be maintained for the grill to perform as it was designed. If airflow is blocked, overheating will occur and poor combustion will result. DO NOT INSTALL PLATFORM DIRECTLY UNDER GRILL.
- Page 7 INSTALLATION AND ASSEMBLY – Locating Grill Page 7...
- Page 8 INSTALLATION AND ASSEMBLY –Cooking Zones ENTERTAINMENT ZONE: The best location for your entertainment zone is on one end of the island, far away from your cooking zone, but right next to your beverage zone. Make sure you have plenty of comfy chairs situated here. SERVING ZONE: The best location for your serving zone is in the center or heart of the island, adjacent from the entertainment zone, and easily accessible to all your many guests at once.
