ICP DAS USA WISE-7 Series Quick Start

Advertisement

Quick Links

Packing List
In addition to this guide, the package includes the following items:
WISE-71xx
Screwdriver
(For WISE-71xx)
WISE-7118Z/S = WISE-7118Z + DB-1820
WISE-7118Z/S2 = WISE-7118Z + DN-1822 + CA-252518D-1
WISE-7519ZM/S = WISE-7519ZM + DB-1820
WISE-7519ZM/S2 = WISE-7519ZM+ DN-1822 + CA-252518D-1
Technical Support
service@icpdas.com
www.icpdas.com
 For Desktop Web
WISE-7255
WISE-75xx
DB-1820
Resources
How to search for drivers, manuals and
spec information on ICP DAS website.
 For Mobile Web
Model Name
WISE-7xxx Quick Start
(For WISE-71xx/7255)
DN-1822
Model Name
V2.0, September 2024
Plastic Rail
CA-252518D-1
P1

Advertisement

loading
Need help?

Need help?

Do you have a question about the WISE-7 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ICP DAS USA WISE-7 Series

  • Page 1 WISE-7xxx Quick Start V2.0, September 2024 Packing List In addition to this guide, the package includes the following items: Plastic Rail WISE-71xx WISE-7255 WISE-75xx (For WISE-71xx/7255) Screwdriver (For WISE-71xx) DB-1820 DN-1822 CA-252518D-1 WISE-7118Z/S = WISE-7118Z + DB-1820 WISE-7118Z/S2 = WISE-7118Z + DN-1822 + CA-252518D-1 WISE-7519ZM/S = WISE-7519ZM + DB-1820 WISE-7519ZM/S2 = WISE-7519ZM+ DN-1822 + CA-252518D-1 Resources...
  • Page 2 Connect to Network, PC and Power Non-PoE Ethernet Cable Ethernet Cable Vs+ GND Power 12 ~ 48 V 46 ~ 55 V Hub / Switch PoE Switch Power Supply Power Supply WISE-72xx / WISE-75xxM support POE only on E1 port. Check network settings Default Settings WISE-7xxx comes with the...
