ICP DAS USA WF-2060 Quick Start Manual

Hide thumbs Also See for WF-2060:
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

「 WF-2060」Package Checklist
The package includes the following items:
One WF-2060 module
One Quick Start
One software utility CD
One screw driver
One RS-232 cable (CA-0910)
One Antenna 2.4GHz - 5 dBi (ANT-124-05)
Note:
1.
If any of these items are missed or damaged, contact the local distributors
for more information. Save the shipping materials and cartons in case you
want to ship in the future.
2.
This document supports the RevB version for the WF-2060 module. For
the previous version, please refer the v1.x version quick start on the CD.
Appearance and pin assignments
(Front View)
Figure 1: Appearance of the WF-2060
WF-2060 Quick Start RevB1.0 2016/10
Quick Start
(TOP View)
1/8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF-2060 and is the answer not in the manual?

Questions and answers

Related Manuals for ICP DAS USA WF-2060

Summary of Contents for ICP DAS USA WF-2060

  • Page 1 Save the shipping materials and cartons in case you want to ship in the future. This document supports the RevB version for the WF-2060 module. For the previous version, please refer the v1.x version quick start on the CD.

  • Page 2: Hardware Connection

    WF-2060 Quick Start RevB1.0 2016/10 Table 1: I/O Connector - WF-2060 I/O Connector - WF-2060 Terminal No. Pin Assignment Terminal No. Pin Assignment RL5 COM RL4 COM RL5 NO RL4 NO DI.COM RL3 COM RL3 NO RL2 COM RL2 NO...
  • Page 3 WF-2060 Quick Start RevB1.0 2016/10 Figure 2: Power and Serial port wire connection I/O connection Figure 3: DI / DO wire connection...

  • Page 4: Installation

    WF-2060 Quick Start RevB1.0 2016/10 Installation Before use, associated hardware configuration, the steps described as follows： Step 1: Checking the WF-2000 series firmware operation mode It needs to set the DIP switch to the "OP" position (operation mode), as resetting the power, WF-2000 series will be in the operation mode.
  • Page 5 1 and 254 except 1, Subnet mask as "255.255.255.0". Finally, press "OK" button. 02、Wireless network connection : a. View available wireless networks and you can see the "WF-2060" wireless network in the list. b. Select the "WF-2060" and press the "Connect" button.
  • Page 6 WF-2060 Quick Start RevB1.0 2016/10 Access I/O data 01、Connection with Modbus TCP utility a. Open Modbus TCP utility and key in the IP address as "192.168.255.1", Port as "502". Finally, press the "Connect" button. Figure7: Modbus TCP utility Connection interface b.
  • Page 7 WF-2060 Quick Start RevB1.0 2016/10 e. Use the function code "0x04", and set the reference number as "0x32" to get the Counter monitor data. Figure 11: Counter monitor interface Table 4: (0xxxx) DO address Begin Address Points Descriptions Range Access Type...

  • Page 8: Troubleshooting

    WF-2060 Quick Start RevB1.0 2016/10 Troubleshooting Item Problem Solution Description Power Failure 1. Please return to the ICP DAS for inspection and repair (PWR LED Off) 1. Make sure that the service set identifier device (SSID) settings are the same.
