GoldenDesigns GDI-8035-03 Owner's Manual

3 person sauna
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GDI-8035-03 FS
3 Person Sauna
OWNER'S MANUAL
FOR CARBON MODEL SAUNAS
INDOOR USE ONLY
120VAC 20AMP DEDICATED CIRCUIT REQUIRED
Carefully and thoroughly read this Owner's Manual before using/operating the
sauna. We recommend keeping this Owner's Manual for regular review and future
reference. Parts and accessories may vary and are subject to change.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDI-8035-03 and is the answer not in the manual?

Questions and answers

Related Manuals for GoldenDesigns GDI-8035-03

Summary of Contents for GoldenDesigns GDI-8035-03

  • Page 1 GDI-8035-03 FS 3 Person Sauna OWNER’S MANUAL FOR CARBON MODEL SAUNAS INDOOR USE ONLY 120VAC 20AMP DEDICATED CIRCUIT REQUIRED Carefully and thoroughly read this Owner’s Manual before using/operating the sauna. We recommend keeping this Owner’s Manual for regular review and future...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Packing List Visual Assembly Diagram Schematics Schematic Layout Dimensional Diagram Screw Identification and Location Chart Highlights Assembly Instructions Operating the Sauna Tips for Using Your Sauna Safety Instructions Safeguards for Your Sauna Troubleshooting Guide Maintenance Warranty Warranty Card WARNING: Visually inspect all heaters before assembly to make sure they are not damaged.
  • Page 3 What Are Infrared Rays? Infrared is the band of light we perceive as heat. We cannot see this band of light with the naked eye, but we can feel this type of light in the form of heat. Our sun produces most of its energy output in the infrared segment of the spectrum.
  • Page 4 EMF Levels from Common Homes Sources After many years and numerous studies on EMF exposure, no government body including the Occupational Safety and Health Administration (OSHA) have established permissible exposure limits (PEL). Currently, there is no consensus on the potential health hazard from any exposure to EMF.
  • Page 5 HOW IT WORKS Infrared Saunas differ from traditional saunas in that they use infrared radiant energy to directly penetrate into the body's tissue to produce perspiration. Traditional saunas use steam to heat the air inside the sauna, which then heats your body until you begin to perspire.
  • Page 6 READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-8035-03 FS (SJ-8363W) – Assembly Diagram *THE ABOVE ASSEMBLY DIAGRAM IS FOR A QUICK REFERENCE VISUAL GUIDE ONLY. ALL SAUNA MODELS MAY NOT BE SHOWN. PARTS AND ACCESSORIES DO VARY AND ARE SUBJECT TO...
  • Page 7 READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-8035-03 FS (SJ – 8363W) – Schematics *THE PICTURES AND DIAGRAMS SHOWN WITHIN THIS OWNER’S MANUAL ARE REPRESENTATIONS OF THIS MODEL. ACTUAL MODEL MAY VARY. DESIGN AND CONSTRUCTION ARE SUBJECT TO CHANGE. BACKRESTS NOT INCLUDED.
  • Page 8 READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-8035-03 FS (SJ – 8363W) – Schematic Layout *THE PICTURES AND DIAGRAMS SHOWN WITHIN THIS OWNER’S MANUAL ARE REPRESENTATIONS OF THIS MODEL. ACTUAL MODEL MAY VARY. DESIGN AND CONSTRUCTION ARE SUBJECT TO CHANGE. BACKRESTS NOT INCLUDED.
  • Page 9 READ ALL INSTRUCTIONS THOROUGHLY BEFORE ASSEMBLY GDI-8035-03 FS (SJ – 8363W) – Schematic Layout (cont’d) *THE PICTURES AND DIAGRAMS SHOWN WITHIN THIS OWNER’S MANUAL ARE REPRESENTATIONS OF THIS MODEL. ACTUAL MODEL MAY VARY. DESIGN AND CONSTRUCTION ARE SUBJECT TO CHANGE. BACKRESTS...
  • Page 10 GDI-8035-03 FS (SJ – 8363W) – DIMENSIONAL DIAGRAM...

  • Page 11: Screw Identification And Location Chart

    SCREW IDENTIFICATION AND LOCATION CHART...

  • Page 12: Highlights

    Highlights A. High quality craftsmanship B. Temperature control C. Timer D. Infrared carbon heat emitter panels E. Control Panel: F. Power supply and sub power supply: G. MP3 Jack: H. Buckles:...
  • Page 13 Guide and Guide Insert Brackets: Panel Descriptions For easier installation, please understand and distinguish the differences between each panel. 1. Floor Panel When the floor panel faces upward, you will find the trim guide moldings which the wall panels will sit up against. The front of the floor panel is indicated below.
  • Page 14 Figure 2 Understanding The Front Of The HIMALAYAN SALT BLOCK PANELS The finished side of the HIMALAYAN SALT BLOCK PANEL will face outward (toward the front of the sauna) and the light wire will be on the inside of the HIMALAYAN SALT BLOCK PANEL (this would be underneath the bench once the bench is installed).

  • Page 15: Assembly Instructions

    Assembly Instructions A. Choose a good location to assemble the sauna 1. The location must be dry, leveled, and away from any source of water. 2. MAIN POWER cord must be easily accessible. 3. Two adults are required for installation. 4.
  • Page 16 Figure 5 NOTE: If any of the wall panels do not slide all the way down, then follow this tip: 1. First, remove the side wall panel. 2. Locate the guide and guide insert brackets on the two wall panels (6 pieces total).
  • Page 17 Figure 6 2. To install the DOOR HANDLE, first locate the DOOR HANDLE. It will need to be dismantled in order to install. Next, place the long handle section horizontally and install it on the glass door from the inside. You will need to secure the side of the long horizontal handle closest to the hinge side of the glass door by screwing it to the glass door.
  • Page 18 E. Installing the ROOF PANEL 1. The side with the slight curve is the front of the ROOF PANEL. The power supply box faces upward on the ROOF PANEL. 2. The edge nearest the power supply is the front of the ROOF PANEL. Be careful of the wires coming from the SIDE and REAR PANELS when you set the ROOF PANEL down onto the panels.
  • Page 19 aligning the left side of the HIMALAYAN SALT BLOCK PANEL with vertical guides on the LEFT SIDE REAR PANEL and pulling the right side of the HIMALAYAN SALT BLOCK PANEL forward as seen in Figure 11. Do not pull the right side of the HIMALAYAN SALT BLOCK PANEL all the way forward as you still will need to install the shorter HIMALAYAN SLAT BLOCK PANEL.
  • Page 20 Figure 12 Figure 13 Figure 14 Figure 15 Figure 16 Figure 17 Figure 18 Figure 19...
  • Page 21 G. Installing the TEMPERATURE SENSOR and optional accessories (varies by model) 1. Enter the sauna and remove the protective covering (masking tape) from the TEMPERATURE SENSOR. Situate the TEMPERATURE SENSOR so that it is vertical and pointing downward. (see Figure 20) Figure 20 2.

  • Page 22: Operating The Sauna

    Operating the Sauna NOTE: Please check and confirm that the connections to the POWER SUPPLY, HEAT EMITTERS, and TEMPERATURE SENSOR are connected properly. The power supply voltage and frequency must match the requested voltage and frequency of the sauna (120VAC 15AMP Dedicated Circuit or 120VAC 20AMP Dedicated Circuit).
  • Page 23 sauna will turn OFF. B. Start Sauna: Press the “ “ button and the system will enter the heating mode. Press the “ “ to Start/Stop the sauna’s heating. If the icon is red, then the heating is stopped. If the icon is green, then the heating is activated.
  • Page 24 Either the Red Light Therapy or the Interior Lights can be ON at any given time. They cannot be operated simultaneously. 1. Press the “ “ button to turn ON/OFF the Exterior Lights (DC12V). 2. Press the “ “ button to turn ON/OFF the Red Light Therapy (DC12V). 3.
  • Page 25 H. You can press the “ “ to return back to the main interface mode. I. Drink water prior to, during, and after your sauna session to replenish body fluids. J. After 3 hours of continuous use, the sauna needs to be shut down for one hour.

  • Page 26: Tips For Using Your Sauna

    Use 2 towels during your sauna session. Fold the first towel several times and place it on the bench. As you sit on this towel, it will absorb a majority of your perspiration while adding comfort as you sit on the bench. Use the second towel to either constantly wipe the perspiration from your body to perspire faster and also to avoid having too much perspiration dripping onto the floor.

  • Page 27: Safety Instructions

    them close to one of the heat emitters to achieve a deep heating effect. 9. To utilize the sauna’s heat therapy effect, put oil and treatment into your hair and wrap it with a towel. After your sauna session is over, rinse your hair thoroughly. 10.
  • Page 28 10. Use care when exercising before and after sauna use. 11. Never sleep inside the sauna 12. Do not use any type of cleaning agents on the interior of the sauna. Only wipe down the sauna room with water and a damp cloth. Never use any chemical based cleaners.

  • Page 29: Safeguards For Your Sauna

    Safeguards For Your Sauna 1. Do not install the sauna near water, near a bathtub (if water will splash on the sauna), near a shower (if water will splash on the sauna), in a wet basement, or near a swimming pool (if water will splash on the sauna). 2.
  • Page 30 confirm if the heat emitters are generating heat. Remove the original temperature sensor from its hole and replace it with the spare one. 2. Control Panel Malfunctioning Solution: The control panel will turn on, but not off and the displayed numbers flash.

  • Page 31: Maintenance

    to confirm if the heat emitters are generating heat. Remove the original temperature sensor from its hole and replace it with the spare one. Solution: Check the wiring harnesses coming from the power supply located on the roof of the sauna. Make sure the wiring harness labeled “CTRL” is connected to the power supply at one end and connected to another wiring harness labeled “CTRL”...
  • Page 32 Limited Lifetime Warranty 7 Year Limited Warranty*: Golden Designs, Inc. under its brand names warranties the wood, structure, heating elements, and electronics against defects in material and workmanship for a period of 1 to 5 years from the original date of purchase. This sauna is for INDOOR use only.
  • Page 33 ▪ Outdoor applications ▪ Normal wear and tear or weathering ▪ Use of product not in accordance with instructions ▪ Worn out receptacle Surface cracks are not considered defects in material or workmanship, as they are normal characteristics of all woods. This includes minor cracks due to wood expansion and contraction.
  • Page 34 PAGE INTENTIONALLY LEFT BLANK...

  • Page 35: Warranty Card

    WARRANTY CARD Congratulations on your purchase of an Infrared Sauna from Golden Designs, Inc. Please take the time to complete the following Warranty Card and mail it back to: Golden Designs, Inc. 3550 Jurupa Street, Unit B Ontario, CA 91761 Please include a copy of your sales receipt showing date of purchase as this will serve as proof of purchase.
