ENG
Double airduct
FIREBRICK
Installation manual
INSTALLATION
- The painted surface cannot be damaged.
- The airduct FIREBRICK needs to be install in accordance with the Residential.
- Ventilation Association Good Practice Recommendations and the Domestic Ventilation Compliance Guide (DVCG).
- Support the ducting during installation and ensure it slopes towards the outside.
- It is recommended to use the self-tapping screws suitable for a Ø3.5mm hole for connection of the metal air bricks to the
metal adaptors/sleeves.
- The elements must be fire sealed to the inner wall according to the instruction given below.
Brook House, Dunmurry Industrial Estate, Dunmurry, Belfast, Co. Antrim, BT17 9HU T: 028 9061 6505 M: hello@brookvent.co.uk brookvent.co.uk | M: hello@brookvent.ie brookvent.ie
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BrookVent Double airduct FIREBRICK
Summary of Contents for BrookVent Double airduct FIREBRICK
- Page 1 - The elements must be fire sealed to the inner wall according to the instruction given below. Brook House, Dunmurry Industrial Estate, Dunmurry, Belfast, Co. Antrim, BT17 9HU T: 028 9061 6505 M: hello@brookvent.co.uk brookvent.co.uk | M: hello@brookvent.ie brookvent.ie...
- Page 2 Installation manual Minimum 568 Minimum 240 Metal grille Metal transition Metal sleeve PVC flat channel PVC ducting connector Brook House, Dunmurry Industrial Estate, Dunmurry, Belfast, Co. Antrim, BT17 9HU T: 028 9061 6505 M: hello@brookvent.co.uk brookvent.co.uk | M: hello@brookvent.ie brookvent.ie...
