  • Page 1 201DC HF PULSE TIG OWNER’S MANUAL www.duralloy.net.au | 1300 369 456...
  • Page 2 Industrial Maintenance & Repairs For industrial welding solutions, check out the DURALLOY at www.duralloy.net.au DURALLOY is a market leading provider of innovative power equipment solutions to a wide range of industries across Australia. Key product categories are; welding equipment, power generators and cleaning equipment.

  • Page 3: Table Of Contents

    201DC HF PULSE TIG OWNER’S MANUAL CONTENTS Know Your Machine Quick Start Guide Wireless Remote Control Configuration Wiring Diagram Care & Maintenance Electrodes Effects of MMA Welding Various Metals Safety Warranty www.duralloy.net.au | 1300 369 456...
  • Page 4 201DC HF PULSE TIG OWNER’S MANUAL 201DC HF PULSE TIG DC Inverter DC HF TIG Welding Machine PART NO: DA201DC STICK 3 YEAR EN60974-1.2012 WARRANTY SPECIFICATIONS HIGH PERFORMANCE DC PULSE Power Supply 240 V High performance pulse TIG welding on...

  • Page 5: Know Your Machine

    201DC HF PULSE TIG OWNER’S MANUAL KNOW YOUR MACHINE More detailed explanations of function on following pages. 1. Positive terminal (+) welding power output connection socket. 2. TIG torch gas connector. 3. Negative terminal (-) welding power output connection socket.
  • Page 6 The DURALLOY 201DC HF PULSE TIG also has more advanced current (28). current controls that can be used in 4T mode.
  • Page 7 This is very useful for precision work. The DURALLOY Hot Start (34) 201DC HF PULSE TIG can also be used with the Duralloy Wireless Hot start provides extra power when the weld starts to counteract remote control system. Refer to the accessories section further on the high resistance of the electrode and workpiece as the arc is in this manual for the options available.

  • Page 8: Quick Start Guide

    Please note, the DURALLOY 201DC HF PULSE TIG is a DC (Direct Current) output welder only. This means that it is unable to TIG weld reactive metals such as 1.2 Insert an electrode into the electrode holder and connect the...

  • Page 9: Wireless Remote Control Configuration

    201DC HF PULSE TIG OWNER’S MANUAL REMOTE 12-Pin Remote Plug Connection Spin Common Socket Wire Foot Welding Remote Up-Down Shell Pedal Torch Control Torch Torch Short Circuit Potentiometer + Potentiometer + Potentiometer Potentiometer Centre Tap Centre Tap Potentiometer Potentiometer Down...

  • Page 10: Wiring Diagram

    201DC HF PULSE TIG OWNER’S MANUAL WIRING DIAGRAM www.duralloy.net.au | 1300 369 456...

  • Page 11: Care & Maintenance

    Keep your welding machine in top condition Size of Electrodes The DURALLOY 201DC HF PULSE TIG does not require any The electrode size is determined by the thickness of metals special maintenance, however the user should take care of the...

  • Page 12: Effects Of Mma Welding Various Metals

    201DC HF PULSE TIG OWNER’S MANUAL EFFECTS OF MMA WELDING VARIOUS MATERIALS High Tensile and Alloy Steels The two most prominent effects of welding these steels are the formation of a hardened zone in the weld area, and, if suitable precautions are not taken, the occurrence in this zone of under- bead cracks.

  • Page 13: Safety

    201DC HF PULSE TIG OWNER’S MANUAL SAFETY Store and Retain this Manual 4. Never leave the welder unattended while energised. Turn Retain this manual for the safety warnings and precautions, power off before leaving the welder unattended. assembly, operating, inspection, maintenance and cleaning 5.
  • Page 14 201DC HF PULSE TIG OWNER’S MANUAL Welding Safety Instructions & Warnings Personal Safety WARNING! CAUTION Protect yourself and others from possible serious injury or Keep the work area well lit. Make sure there is adequate death. Keep children away. Read the operating/Instruction space surrounding the work area.
  • Page 15 201DC HF PULSE TIG OWNER’S MANUAL Work Environment Safety Electricity Can Kill CAUTION DANGER! Used with the safety alert symbol, indicates a hazardous Touching live electrical parts can cause fatal shocks or situation which, if not avoided, could result in minor or severe burns.
  • Page 16 201DC HF PULSE TIG OWNER’S MANUAL Fumes And Gases 5. Work in a confined space only if it is well ventilated, or while wearing an air-supplied respirator. Shielding ga es used for WARNING! welding can displace air causing injury or death. Be sure the Welding produces fumes and gases.
  • Page 17 201DC HF PULSE TIG OWNER’S MANUAL Fire & Explosive Risks Cylinders WARNING! WARNING! Sparks and spatter fly off from the welding arc. The flying Gas cylinders contain gas under high pressure. If sparks and hot metal, weld spatter, work piece, and hot damaged, a cylinder can explode.

  • Page 18: Warranty

    WARRANTY Duralloy Welding Equipment / Plasma Cutting Range 3 year Warranty* The Obligation of Duralloy Industrial Supply under this warranty is limited to the circumstance set out above and is subject to: Duralloy Industrial Supply warrants the original retail purchaser •...
  • Page 19 201DC HF PULSE TIG OWNER’S MANUAL www.duralloy.net.au | 1300 369 456...
  • Page 20 | 1300 369 456...
