  • Page 1 201P AC/DC PULSE TIG OWNER’S MANUAL www.duralloy.net.au | 1300 369 456...
  • Page 2 Design emphasis is placed on simple, functional design and operation. All DURALLOY product are subject to stringent quality control and designed and manufactured to EN60974-1.2012 standards.

  • Page 3: Table Of Contents

    201P AC/DC PULSE TIG OWNER’S MANUAL CONTENTS Know Your Machine Basic Operation Wiring Diagram Care & Maintenance Electrodes Effects of MMA Welding Various Metals Safety Warranty www.duralloy.net.au | 1300 369 456...
  • Page 4 201P AC/DC PULSE TIG OWNER’S MANUAL 201P AC/DC PULSE TIG 240V AC/DC TIG Inverter Welding Machine PART NO: DA201PACDC STICK 3 YEAR EN60974-1.2012 WARRANTY SPECIFICATIONS DIGITAL DISPLAY Power Supply 1-220/230/240 ± 10% Variable amperage control with digital meters Frequency 50/60Hz...

  • Page 5: Know Your Machine

    201P AC/DC PULSE TIG OWNER’S MANUAL KNOW YOUR MACHINE More detailed explanations of function on following pages. 1. Positive terminal (+) welding power output connection socket. 2. TIG torch remote connection socket 3. Negative terminal (-) welding power output connection socket.
  • Page 6 This function is useful to longer welds as the trigger is not required to be held on continuously. The DURALLOY 201P AC/DC PULSE TIG also has more advanced current controls that can be used in 4T mode.
  • Page 7 50%, the time period of the peak current and base current pulse is equal. Higher pulse duty setting will give greater heat input, while The DURALLOY 201P AC/DC PULSE TIG can accept remote lower pulse duty will have the opposite effect.

  • Page 8: Basic Operation

    Ensure all connections are tight. Open gas cylinder valve The DURALLOY 201P AC/DC PULSE TIG has electrical and adjust regulator, flow should be between 5-10 l/min components and control circuit boards which may be damaged depending on application.

  • Page 9: Wiring Diagram

    201P AC/DC PULSE TIG OWNER’S MANUAL WIRING DIAGRAM www.duralloy.net.au | 1300 369 456...

  • Page 10: Care & Maintenance

    Keep your welding machine in top condition Size of Electrodes The DURALLOY 201P AC/DC PULSE TIG does not require any The electrode size is determined by the thickness of metals special maintenance, however the user should take care of the...

  • Page 11: Effects Of Mma Welding Various Metals

    201P AC/DC PULSE TIG OWNER’S MANUAL EFFECTS OF MMA WELDING VARIOUS MATERIALS High Tensile and Alloy Steels The two most prominent effects of welding these steels are the formation of a hardened zone in the weld area, and, if suitable precautions are not taken, the occurrence in this zone of under- bead cracks.

  • Page 12: Safety

    201P AC/DC PULSE TIG OWNER’S MANUAL SAFETY Store and Retain this Manual 4. Never leave the welder unattended while energised. Turn Retain this manual for the safety warnings and precautions, power off before leaving the welder unattended. assembly, operating, inspection, maintenance and cleaning 5.
  • Page 13 201P AC/DC PULSE TIG OWNER’S MANUAL Welding Safety Instructions & Warnings Personal Safety WARNING! CAUTION Protect yourself and others from possible serious injury or Keep the work area well lit. Make sure there is adequate death. Keep children away. Read the operating/Instruction space surrounding the work area.
  • Page 14 201P AC/DC PULSE TIG OWNER’S MANUAL Work Environment Safety Electricity Can Kill CAUTION DANGER! Used with the safety alert symbol, indicates a hazardous Touching live electrical parts can cause fatal shocks or situation which, if not avoided, could result in minor or severe burns.
  • Page 15 201P AC/DC PULSE TIG OWNER’S MANUAL Fumes And Gases 5. Work in a confined space only if it is well ventilated, or while wearing an air-supplied respirator. Shielding ga es used for WARNING! welding can displace air causing injury or death. Be sure the Welding produces fumes and gases.
  • Page 16 201P AC/DC PULSE TIG OWNER’S MANUAL Fire & Explosive Risks Cylinders WARNING! WARNING! Sparks and spatter fly off from the welding arc. The flying Gas cylinders contain gas under high pressure. If sparks and hot metal, weld spatter, work piece, and hot damaged, a cylinder can explode.

  • Page 17: Warranty

    WARRANTY Duralloy Welding Equipment / Plasma Cutting Range 3 year Warranty* The Obligation of Duralloy Industrial Supply under this warranty is limited to the circumstance set out above and is subject to: Duralloy Industrial Supply warrants the original retail purchaser •...
  • Page 18 201P AC/DC PULSE TIG OWNER’S MANUAL www.duralloy.net.au | 1300 369 456...
  • Page 19 201P AC/DC PULSE TIG OWNER’S MANUAL www.duralloy.net.au | 1300 369 456...
  • Page 20 | 1300 369 456...
