GV-SRK1356 Card Reader
The content of this installation guide refers to GV-SRK1356.
Introduction
GV-SRK1356 is a dual-band OSDP keypad reader, capable of reading PIN codes and
access cards. Its dual-band capability offers great flexibility for integrators to solve card
management issues on the locations, installed with both 125 kHz and 13.56 MHz readers.
For outdoor use, GV-SRK1356 comes with a weather-sealed and IP66-compliant housing.
Specification
Power Source
DC 12 ~ 18 V
Power Consumption
50 mA (max)
RFID Frequency
125 kHz and 13.56 MHz
2 – 4 cm (0.78 – 1.57 in)
Reading Range
Wiegand 26 bits for 125 kHz,
26 / 34 bits for 13.56 MHz,
Wiegand Interface
distance 100 m (328.1 ft) via GV-AS1620 / 2120 /
4110 / 4111 / 8110 / 8111
Operating Temperature
-40
~ 60
(-40
)
°C
°C
°F ~ 140 °F
Operating Humidity
0% to 98% RH
Color
Black
Ingress Protection
IP66
Dimensions
120 x 50 x 20 mm (4.72" x 1.97" x 0.79")
(H x W x T)
Weight
150 g (0.33 lb)
April 9, 2024
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-SRK1356
Summary of Contents for GeoVision GV-SRK1356
- Page 1 The content of this installation guide refers to GV-SRK1356. Introduction GV-SRK1356 is a dual-band OSDP keypad reader, capable of reading PIN codes and access cards. Its dual-band capability offers great flexibility for integrators to solve card management issues on the locations, installed with both 125 kHz and 13.56 MHz readers.
-
Page 2: Installation
Installation Drill 2 holes (A, C) on the wall for the screws and one hole (B) for the cable. Knock the plastic screw anchors to the holes (A, C). Fix the back cover on the wall with 2 screws. Thread the cable through the cable hole (B). Attach the unit to the back cover. -
Page 3: Connection Diagram
Connection Diagram Connect with OSDP Controller Connect with Wiegand Controller Programming Set Master Code (4~6 digits) The master code is used to prevent unauthorized access to the system. We suggest you immediately update it and note down the new master code. The master code is set to 123456 by default. - Page 4 OSDP Address Setting The OSDP address is set to 1 by default. Follow the steps below to change it. Press for 5 seconds, and press the master code to enter the program mode. To change the OSDP address, press 7[the new OSDP address]#. For example, if you wish to change the OSDP address to 2, press 72#.
-
Page 5: Indicator Light Status
Note: The status details are based on the test results when the reader is connected to GV-AS1620 / GV-CS1320. Packing List GV-SRK1356 Self-Tapping Screw x 2 (4 x 25 mm) Rubber Plug x 2 Installation Guide April 9, 2024...
