GV-Card Reader
User's Manual
Before attempting to connect or operate this product, please
read these instructions carefully and save this manual for future use.
READER-G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GV-R1352 V2B and is the answer not in the manual?

Questions and answers

Related Manuals for GeoVision GV-R1352 V2B

Summary of Contents for GeoVision GV-R1352 V2B

  • Page 1 GV-Card Reader User’s Manual Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use. READER-G...
  • Page 2 GeoVision. Every effort has been made to ensure that the information in this manual is accurate. GeoVision, Inc. makes no expressed or implied warranty of any kind and assumes no responsibility for errors or omissions. No liability is assumed for incidental or consequential damages arising from the use of the information or products contained herein.

  • Page 3: Notice

    Notice Notice for GV-R1352 V2B and GV-R1352 V2C: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 4: Preface

    Preface Welcome to the GV-Card Reader User’s Manual. This Manual applies to the following GV-Card Readers: Reader Models GV-Reader1251 and 1352 V2 GV-SR1251 GV-RK1352 / R1352 GV-DFR1352 (Rev. B) GV-DFK1355 GV-RKD1352 GV-R1355 GV-RKR1355 GV-RKV1355 GV-R1354...

  • Page 5: Note For Waterproofing

    Note for Waterproofing To prevent water from penetrating the reader from the rear panel, use the following waterproofing measures when installing GV-DFK1355, GV-RKV1355, GV-RKR1355, or GV- RKD1352. 1. The rear panel of GV-DFK1355 or GV-RKV1355 has waterproofing rubber rings. Install the reader tightly against the wall to prevent water from entering along the wall.

  • Page 6: Table Of Contents

    Contents Notice ...................... i Preface ....................ii Note for Waterproofing ................ iii Contents ....................iv Chapter 1 GV-Reader1251 / 1352 V2 and GV-SR1251 ......1 1.1 Packing List ......................1 1.2 Installation ....................... 2 1.2.1 Electric Wire ....................2 1.2.2 Switch Settings of GV-Reader1251 / 1352 V2 ..........2 1.2.3 Define the ID of GV-SR1251 Using GV-Reader Config Utility ......
  • Page 7 2.3.2 Connect through RS-485 Interface ...............18 2.3.3 Define Readers on GV-AS Controller Web Interface ........19 2.4 Install GV-R/RK/DFR Config AP ................21 2.5 Overlay Card Numbers on GV-DVR/NVR Live View ..........22 2.5.1 Define the ID and Set the Reader to Slave ...........23 2.5.2 Add the Reader to GV-DVR/NVR ..............25 2.6 Control the Beeper and LED ...................26 2.6.1 Enable External Control on the Reader ............26...
  • Page 8 4.5 LED Status and Beeper ..................46 4.6 Firmware Upgrade ....................46 4.7 Specifications ......................46 Chapter 5 GV-RKR1355..............47 5.1 Packing List ......................47 5.2 Compatible Products ....................47 5.3 Physical Descriptions .....................48 5.4 Installation ......................50 5.5 Keypad ........................51 5.6 LED Status and Beeper ..................51 5.7 Firmware Upgrade ....................52 5.8 Specifications ......................52 Chapter 6 GV-RKV1355 ..............
  • Page 9 7.4 Installation ......................60 7.5 ID, Beeper and LED Settings ..................60 7.6 Firmware Upgrade ....................62 7.7 Specifications ......................63 Chapter 8 GV-DFK1355 ..............64 8.1 Packing List ......................64 8.2 Compatible Products ....................64 8.3 Physical Descriptions .....................65 8.4 Installation ......................67 8.5 Keypad ........................68 8.6 LED Status and Beeper ..................68 8.7 ID, DESFire and GID Settings ................68 8.8 GV-Cloud Access Control Integration ..............70...

  • Page 10: Chapter 1 Gv-Reader1251 / 1352 V2 And Gv-Sr1251

    GV-Reader1251 / 1352 V2 and GV-SR1251 Chapter 1 GV-Reader1251 / 1352 V2 and GV-SR1251 GV-Reader1251 / 1352 V2 / SR1251 includes transmit-receive antenna and electronics. It has both Wiegand and RS-485 outputs that can be connected to any standard access control panel.

  • Page 11: Installation

    1.2 Installation 1.2.1 Electric Wire Wire Color Function DC 7.5 ~ 12 V Black Green Wiegand Data 0 White Wiegand Data 1 Blue RS-485 + Light Blue RS-485 - Yellow Beeper Orange Green LED Light Red Red LED 1.2.2 Switch Settings of GV-Reader1251 / 1352 V2 Electric Wire Switch...
  • Page 12 GV-Reader1251 / 1352 V2 and GV-SR1251 ◼ SW2-SW3 Green/Red LED Control: The default mode for the Green/Red LED Control is the internal control. The LED is normally red. When a card is read, the LED flashes green. When the setting is “Off”, the Green/Red LED is controlled externally. The external control lines can then be used to operate the LEDs.

  • Page 13: Define The Id Of Gv-Sr1251 Using Gv-Reader Config Utility

    1.2.3 Define the ID of GV-SR1251 Up to 8 readers can be connected to GV-AS Controller via a single RS-485 interface. To create a daisy chain connection, use the Setup AP to define each reader's ID number. 1. Install and download the Setup AP. For details, see 2.4 Install GV-R/RK/DFR Setup AP. 2.

  • Page 14: Connect The Reader To Gv-As Controller

    GV-Reader1251 / 1352 V2 and GV-SR1251 1.3 Connect the Reader to GV-AS Controller GV-Reader1251 / 1352 V2 / SR1251 is compatible with any standard access controllers. The following diagrams illustrate how to connect GV-Reader1251 / 1352 V2 / SR1251 to GV-AS Controller through Wiegand or RS-485 interface, and how to connect GV-Reader1251 / 1352 V2 / SR1251 to third-party access controllers and GV-DVR/NVR.

  • Page 15: Connect Through Rs-485 Interface

    1.3.2 Connect through RS-485 Interface Multiple readers can be connected to GV-AS Controller through a single RS-485 interface. ⚫ Switch Settings for RS-485 Connection (GV-Reader1251 / 1352 V2 only) ⚫ Switch Settings for Multiple GV-Readers (RS-485) (GV-Reader1251 / 1352 V2 only) When connecting multiple readers to GV-AS Controller, turn SW8 on the last connected GV-Reader to ON.
  • Page 16 GV-Reader1251 / 1352 V2 and GV-SR1251 Defining Readers on GV-AS Controller Web Interface After configuring the switch settings of GV-Reader1251 / 1352 V2 or defining the ID number of GV-SR1251 using GV-R/RK/DFR Setup AP, you need to specify which door each reader controls on the Web interface of GV-AS Controller.

  • Page 17: Connect To Gv-Dvr/Nvr And Third-Party Access Controllers

    1.3.3 Connect to GV-DVR/NVR and Third-Party Controllers GV-Reader1251 / 1352 V2 / SR1251 is compatible with third-party access controllers. With its compatibility, you can also add a GV-DVR/NVR to this connection to empower your management. After connecting GV-Reader1251 / 1352 V2 / SR1251 to the access controller through the Wiegand interface, connect the reader to GV-DVR/NVR via GV-COM, GV-Hub or GV- NET/IO Card V3.1.

  • Page 18: Overlay Card Numbers On Gv-Dvr/Nvr Live View

    GV-Reader1251 / 1352 V2 and GV-SR1251 1.4 Overlay Card Numbers on GV-DVR/NVR Live View You can overlay card numbers recognized at GV-Reader1251 / 1352 V2 / SR1251 onto a camera channel on GV-DVR/NVR. To overlay card numbers on GV-DVR/NVR channels, connect the reader to GV-DVR/NVR through a RS-485 / USB converter (e.g.

  • Page 19: Change The Default Settings Of Beeper And Led

    1.5 Control the Beeper and LED You can configure GV-AS Controller (AS210 / 2110 / 2120 / 410 / 4110 / 810 / 8110) to control the reader's beeper or LED externally. Through the controller's Web interface, you can configure the controller to activate the reader's red LED, green LED, or beeper in response to a specific alert event.

  • Page 20: Specifications

    150 g / 0.33 lb 125 g / 0.27 Ib 150 g / 0.33 lb Ingress IP66 IP54 IP54 Protection Certification CE, FCC, RoHS For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 21: Chapter 2 Gv-Rk1352 / R1352 / Dfr1352

    Chapter 2 GV-RK1352 / R1352 / DFR1352 Card readers GV-RK1352 / R1352 / DFR1352 are able to recognize access cards. The keypad on GV-RK1352 allows it to recognize PIN codes. GV-DFR1352 is intended for installation on the door frame. Featured with the Wiegand and RS-485 outputs, the readers can be connected to any standard access control system.

  • Page 22: Packing List

    GV-RK1352 / R1352 / DFR1352 2.1 Packing List GV-RK1352 1. GV-RK1352 Card Reader 2. Screw x 2 3. Screw Anchor x 2 4. Front Cover Plate x 1 5. Software CD 6. Installation Guide 7. Warranty Card GV-R1352 1. GV-R1352 Card Reader 2.

  • Page 23: Physical Descriptions

    2.2 Physical Descriptions 2.2.1 Electric Wire GV-RK1352 Wire Color Function DC 7.5 ~ 12 V Black Yellow Beeper Orange Green LED Light Red Red LED Green Wiegand Data 0 White Wiegand Data 1 Blue RS-485 + Light Blue RS-485 - Rear View GV-R1352 Wire Color...
  • Page 24 GV-RK1352 / R1352 / DFR1352 GV-DFR1352 Wire Color Function DC 7.5 ~ 12V Black Yellow Beeper Orange Green LED Light Red Red LED Green Wiegand Data 0 White Wiegand Data 1 Blue RS-485 + Light Blue RS-485 - Gray Purple Rear View Brown Install the GV-DFR1352 to the door frame using the supplied screws and screw anchors.

  • Page 25: Keypad (Gv-Rk1352 Only)

    2.2.2 Keypad (GV-RK1352 Only) When using the reader, you can enter the door's Common Password or the card’s PIN code on the keypad to gain access. The access mode is set in GV-ASManager (software). 1. 0~9 Number Keys: Press the number keys to enter a PIN or password. 2.

  • Page 26: Connect The Reader To Gv-As Controller

    You can connect the readers to GV-AS Controllers through Wiegand or RS-485 interface. Note that the connection between the reader and GV-AS Controller varies among controller models. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 27: Connect Through Rs-485 Interface

    2.3.2 Connect through RS-485 Interface The following diagrams use GV-RK1352 and GV-AS810 Controller as an example. Up to eight readers can be connected together to the RS-485 interface on GV-AS810 Controller. ⚫ Connecting four or less readers to GV-AS810 Controller: Wire Color Function GV-RK1352 or GV-R1352...

  • Page 28: Define Readers On Gv-As Controller Web Interface

    Red LED White Wiegand Data 1 Brown Purple Blue RS-485+ © 2011 GeoVision, Inc. All rights reserved. L Blue RS-485- Gray All GeoVision Products are made in Taiwan. 3. Select a door/gate for the reader from the Function drop-down list.
  • Page 29 4. Next to Read Mode, select Read UID or Read GID to set the connected readers to read UID (Unique Identifier) or GID (GeoVision Identifier) on GV-AS ID Cards / Key Fobs. If you select Read GID, ensure there are two sets of digits on your card / fob as shown below.

  • Page 30: Install Gv-R/Rk/Dfr Config Ap

    GV-HUB / GV-COM / GV-RK1352 GV-NET/IO Card You can install the Config AP from the GeoVision website. To use a GV-COM, GV-Hub or GV-NET/IO Card V3.1, you also need to install GV-USB Device Driver to enable the device. Downloading from GeoVision Website 1.

  • Page 31: Overlay Card Numbers On Gv-Dvr/Nvr Live View

    2.5 Overlay Card Numbers on GV-DVR/NVR Live View You can overlay card numbers recognized at the reader onto a camera channel on GV- DVR/NVR. To overlay card numbers on GV-DVR/NVR channels, connect the reader to GV- DVR/NVR through a RS-485 / USB converter (e.g. GV-COM, GV-Hub or GV-NET/IO Card V3.1) as illustrated below.

  • Page 32: Define The Id And Set The Reader To Slave

    GV-RK1352 / R1352 / DFR1352 2.5.1 Define the ID and Set the Reader to Slave After the reader is connected to the computer of GV-DVR/NVR, use GV-R/RK/DFR Setup AP to define the ID number of the reader and set the reader to Slave. 1.
  • Page 33 Comm Port and the COM number currently in use. 2. If you are using an older version of the Config AP, you will have to manually type the serial number of the reader. The serial number is on the rear panel of the reader.

  • Page 34: Add The Reader To Gv-Dvr/Nvr

    GV-RK1352 / R1352 / DFR1352 2.5.2 Add the Reader to GV-DVR/NVR 1. In GV-DVR/NVR, click the Configure button, select Accessories, and select GV Wiegand Capture Device Setting. This dialog box appears. 2. Click the New button. This dialog box appears. ◼...

  • Page 35: Control The Beeper And Led

    2.6 Control the Beeper and LED You can configure GV-AS Controller (AS210 / 2110 / 2120 / 410 / 4110 / 810 / 8110) to control the reader's beeper or LED externally. Through the controller's Web interface, you can configure the controller to activate the reader's red LED, green LED, or beeper in response to a specific alert event.
  • Page 36 GV-RK1352 / R1352 / DFR1352 1. Start GV-R/RK/DFR Setup AP and select the COM port that is connected to the reader. Note: For how to install the Config AP, see 2.4 Install GV-R/RK/DFR Setup AP. For how to identify the COM port of the reader, see Note 1, 2.5.1 Define the ID and Set the Reader to Slave.

  • Page 37: Connect The Beeper And Led

    2.6.2 Connect the Beeper and LED Connect the control wires of the beeper, Red LED, or Green LED to any of the outputs on the GV-AS Controller (GV-AS210 / 2110 / 2120 / 410 / 4110 / 810 / 8110). Wiring LED to GV-AS Controller The diagram below shows how to wire Green LED using GV-RK1352 and GV-AS810 as an example.

  • Page 38: Set The Beeper And Led For Each Door/Gate

    GV-RK1352 / R1352 / DFR1352 After wiring the beeper, go to GV-ASManager and select the alarm conditions that will activate it. To configure the alarm conditions in GV-ASManager, right-click the controller in the device list, select Settings, and then the Door / Gate tab. 2.6.3 Set the Beeper and LED for Each Door/Gate After connecting the wires for the beeper or LED, specify the conditions to activate the beeper or LED on the GV-AS210 / 2110 / 2120 / 410 / 4110 / 810 / 8110 Web interface.

  • Page 39: Configure Gid

    2.7 Configure GID The reader reads the UID (Unique Identifier) on access control cards or key fobs by default. Using GV-R/RK/DFR Setup AP, you can set the reader to read GID (GeoVision Identifier) on GV-AS ID Cards / Key Fobs instead.
  • Page 40 GV-RK1352 / R1352 / DFR1352 4. Click Setup to apply the setting. The serial number and firmware version of the reader is automatically detected. To use GID, make sure that your card / fob has two sets of digits as shown below. If your card / fob has only one set of digits, GID is not supported.

  • Page 41: Firmware Upgrade

    2.8 Firmware Upgrade GeoVision periodically releases updated firmware on its website. The new firmware can be simply loaded into the reader by using Update Utility included in the Software CD. Important Notes before You Start Before you start updating the firmware, please read these important notes: 1.

  • Page 42: Specifications

    Ingress Protection IP66 Certification CE, FCC, RoHS, UL 294, CUL For the number of readers supported by a variety of GeoVision controllers, see the compatibility table. Note: GID ID format is only supported by GV-RK1352 / GV-R1352 / GV-DFR1352 (Rev. B)

  • Page 43: Accessory (Gv-Rk1352 And Gv-R1352 Only)

    2.10 Accessory (GV-RK1352 and GV-R1352 Only) Optional accessories can expand the capabilities and versatilities of your GV-RK1352 and GV-R1352. Consult our sales representative for more information. GV-MountA900 is a mounting plate that allows you to attach GV-RK1352 and GV-R1352 to a US single gang power box. GV-MountA900 •...

  • Page 44: Chapter 3 Gv-Rkd1352

    Chapter 3 GV-RKD1352 GV-RKD1352 is a card reader with keypad, designed to read PIN codes and access cards. Featured with Wiegand and RS-485 interfaces, GV-RKD1352 can be connected to any standard access control systems. GV-RKD1352 comes with IP65 rated ingress protection suitable for indoor and outdoor applications.

  • Page 45: Physical Descriptions

    3.3 Physical Descriptions ⚫ DIP Switch: To define the reader’s ID for a daisy chain connection, set up the first 5 DIP switches as listed below. DIP (6) is for card format settings.
  • Page 46 GV-RKD1352 DESFire / GID (GeoVision Identifier) Support The reader supports Mifare cards. To only support DESFire or GID (GeoVision Identifier) formatted cards, turn ON for the DIP (6). Note: GV-DESFire cards contain two types of ID: UID and DES ID. When only DES ID is required, turn on the DIP (6).

  • Page 47: Installation

    3.4 Installation Before the hardware installation, refer to Physical Descriptions for the Node ID settings. Mount the backplate onto the wall or back box (US standard 120 type). Note DO NOT overtighten the backplate screws during installation to prevent distortion. Connect the wires in accordance with the Wiring Note below.

  • Page 48: Keypad

    GV-RKD1352 If the reader is installed in an open area or highly humid environment, it is recommended to protect the reader with an external shielding cover. RS-485 communication baud rate is 9600. 3.5 Keypad When using the reader, you can enter the door's Common Password or the card’s PIN code on the keypad to gain access.

  • Page 49: Firmware Upgrade

    3.7 Firmware Upgrade GeoVision periodically updates its website with the latest firmware. Using the provided tool, the new firmware can be easily installed on the reader. First, prepare a RS-485 / USB converter, and connect the reader to a PC as illustrated below.

  • Page 50: Specifications

    F. Set the Baud rate to 9600 in the ISP New Tool. G. Click Initialize Device after ISP, and then OK to start initialization. 3.8 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 51: Chapter 4 Gv-R1355

    GV-R1355 Chapter 4 GV-R1355 The card reader GV-R1355, which has Wiegand and RS-485 interfaces, can be integrated into any standard access control system. GV-R1355 has IP66 ingress protection, making it suitable for both indoor and outdoor applications. 4.1 Packing List 1.

  • Page 52: Physical Descriptions

    GV-R1355 4.3 Physical Descriptions ⚫ DIP Switch: To define the reader’s ID for a daisy chain connection, set up the first 5 DIP switches as listed below. DIP (6) is for card format settings.
  • Page 53 DESFire / GID (GeoVision Identifier) Support The reader supports Mifare cards. To only support DESFire or GID (GeoVision Identifier) formatted cards, turn ON for the DIP (6). Note: GV-DESFire cards contain two types of ID: UID and DES ID. When only DES ID is required, turn on the DIP (6).
  • Page 54 GV-R1355 4.4 Installation Before the hardware installation, refer to Physical Descriptions for the Node ID settings. Mount the backplate onto the wall or back box (US standard 120 type). Note DO NOT overtighten the backplate screws during installation to prevent distortion. Connect the wires in accordance with the wiring notes below.

  • Page 55: Led Status And Beeper

    For how to upgrade the firmware, see 3.7 Firmware Upgrade. 4.7 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 56: Chapter 5 Gv-Rkr1355

    Chapter 5 GV-RKR1355 GV-RKR1355 is a scramble keypad reader with numeric keys displayed in random order after cards are swiped or PINs are entered. Featured with Wiegand and RS-485 interfaces, GV-RKR1355 can be integrated to any standard access control systems. 5.1 Packing List GV-RKR1355 Screw x 4...

  • Page 57: Physical Descriptions

    5.3 Physical Descriptions ⚫ DIP Switch: To define the reader’s ID for a daisy chain connection, set up the first 5 DIP switches as listed below. DIP (6) is for card format settings.
  • Page 58 GV-RKR1355 DESFire / GID (GeoVision Identifier) Support By default, the reader supports Mifare cards. To only support DESFire or GID (GeoVision Identifier) formatted cards, turn ON for the DIP (6). Note: GV-DESFire cards contain two types of ID: UID and DES ID. When only DES ID is required, turn on the DIP (6).

  • Page 59: Installation

    5.4 Installation Before the hardware installation, refer to Physical Descriptions for the Node ID settings. Mount the backplate onto the wall or back box (US standard 120 type). Note DO NOT overtighten the backplate screws during installation to prevent distortion. Connect the wires in accordance with the Wiring Note below.

  • Page 60: Keypad

    GV-RKR1355 5.5 Keypad When using the reader, you can enter the door's Common Password or the card’s PIN code on the keypad to gain access. The access mode is set in GV-ASManager (software). ⚫ 0~9 Number Keys: Press the number keys to enter a PIN code or password. ⚫...

  • Page 61: Firmware Upgrade

    For how to upgrade the firmware, see 3.7 Firmware Upgrade. 5.8 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 62: Chapter 6 Gv-Rkv1355

    Chapter 6 GV-RKV1355 GV-RKV1355 is a vandal-resistant keypad reader capable of reading PIN codes and access cards. To successfully resist vandalism, the reader’s case is made of zina alloy, making it suited for high-security locations such as banks and prisons. Featured with Wiegand and RS- 485 interfaces, GV-RKV1355 can be integrated to any standard access control systems.

  • Page 63: Physical Descriptions

    6.3 Physical Descriptions ⚫ DIP Switch: To define the reader’s ID for a daisy chain connection, set up the first 5 DIP switches as listed below. DIP (6) is for card format settings.
  • Page 64 GV-RKV1355 DESFire / GID (GeoVision Identifier) Support The reader supports Mifare cards. To only support DESFire or GID (GeoVision Identifier) formatted cards, turn ON for the DIP (6). Note: GV-DESFire cards contain two types of ID: UID and DES ID. When only DES ID is required, turn on the DIP (6).

  • Page 65: Installation

    6.4 Installation Before the hardware installation, refer to Physical Descriptions for the Node ID settings. Mount the backplate onto the wall or back box (US standard 120 type). Note DO NOT overtighten the backplate screws during installation to prevent distortion. Connect the wires in accordance with the Writing Note below.

  • Page 66: Keypad

    For how to upgrade the firmware, see 3.7 Firmware Upgrade. 6.8 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 67: Chapter 7 Gv-R1354

    GV-R1354 Chapter 7 GV-R1354 The mini card reader GV-R1354, with only 8 cm tall, can be integrated into any standard access control systems through its Wiegand and RS-485 interfaces. Mini but complete, GV- R1354 has weather-sealed and IP56-compliant housing, perfect for both indoor and outdoor applications.

  • Page 68: Physical Descriptions

    GV-R1354 7.3 Physical Descriptions ⚫ DIP Switch: Used to set up card formats and communication signals. By default, the switch No. 1 is set to OFF for reading UID, and the switch No. 2 is set to ON for sending RS-485 and Wiegand signals simultaneously.

  • Page 69: Installation

    ⚫ Data Cable: Connect the reader to GV-AS Controller based on the following pin definitions: Wire Color Description Black DC Power 0 V (GND) DC Power 12V Purple Beeper Input (Low Sound) Brown Green LED Yellow Red LED White Green Wiegand Data 0 Blue Wiegand Data 1...
  • Page 70 GV-R1354 After downloading and installing the QR1352/ DES1352/R1354 Setup AP on a PC, first connect the reader to the PC using a RS-485 to USB converter, as illustrated below. Note: The ID setting is only required for the reader to be connected to a controller through RS-485.

  • Page 71: Firmware Upgrade

    One beep upon access denied (default)→ Flashing green LED upon access denied 7.6 Firmware Upgrade GeoVision periodically updates its website with the latest firmware. Using the provided tool, the new firmware can be easily installed on the reader. First of all, prepare a RS-485 / USB converter, and connect the reader to a PC as illustrated in 7.5 Configure the ID, Beeper or LED.

  • Page 72: Specifications

    6. Select the COM port that is connected to the reader, and select Open COM. 7. Select Initialize. When the initialization is complete, a Success message will be displayed. 7.7 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 73: Chapter 8 Gv-Dfk1355

    Chapter 8 GV-DFK1355 GV-DFK1355 is a keypad reader capable of reading PIN codes and access cards. It features a slim profile design, making it suitable for installation on a narrow door frame or in tight spaces. Thanks to its Wiegand and RS-485 interfaces, GV-DFK1355 can be connected to a variety of access control systems.

  • Page 74: Physical Descriptions

    GV-DFK1355 8.3 Physical Descriptions ⚫ Cable Connector: Connect the reader to the controller based on the following pin definitions: Wire Color Wiegand RS-485 DC 12V DC 12V Black Ground Ground Yellow RS-485+ Blue RS-485- Gray Input 2 (Exit Button; NO) Pink Relay + Orange &...
  • Page 75 ⚫ Built-in Relay The relay is set to NO (Normal Open) by default. When Electric Bold Lock is used, connect wires to COM (Relay -) and NC (Relay +) contacts. When Electric Strikes is used, connect wires to COM (Relay -) and NO (Relay +) contacts. Note: By default, Input 1 (Door Sensor) is set to NC (Normal Closed) and Input 2 (Exit Button) is set to NO (Normal Open), and neither of these settings cannot be changed.

  • Page 76: Installation

    GV-DFK1355 8.4 Installation Mount the backplate onto the wall or back box (US standard 120 type). Note DO NOT overtighten the backplate screws during installation to prevent distortion. Connect the wires in accordance with the Writing Note below. Make sure the backplate and the upper cover guide of the reader are aligned. Install the upper cover of the reader to the backplate.

  • Page 77: Keypad

    8.5 Keypad When using the reader, you can enter the door's Common Password or the card's PIN code on the keypad to gain access. The access mode is set in GV-ASManager (software) or GV- Cloud Access Control (cloud-based software). ⚫ 0~9 Number Keys: Press the number keys to enter a PIN code or password. ⚫...
  • Page 78 GV-DFK1355 The reader reads the UID (Unique Identifier) on access control cards or key fobs by default. You can set the reader to read GID (GeoVision Identifier) or DESFire ID on GeoVision ID cards / Key Fobs instead. After downloading and installing the DFK1355 Setup AP on a PC, first connect the reader to the PC using a RS-485 to USB converter, as illustrated below.

  • Page 79: Gv-Cloud Access Control Integration

    8.8 GV-Cloud Access Control Integration The GV-DFK1355 reader, which has two inputs (Exit Button and Door Sensor) and one output (Door Lock), can control a single door when combined with the GV-AS Bridge controller and the cloud-based software GV-Cloud Access Control. Note: GV-AS Bridge and GV-Cloud Access Control are coming soon.
  • Page 80 GV-DFK1355 ⚫ The default values for Held Open Time and Lock Reset Time are 5 and 10 seconds respectively. You can alter the duration using GV-Cloud Access Control. Lockdown ⚫ When the door is forcibly locked down by GV-Cloud Access Control, you can open it by pressing the Exit button.

  • Page 81: Firmware Upgrade

    For how to upgrade the firmware, see 3.7 Firmware Upgrade. 8.10 Specifications For details, please see the datasheet. For the number of readers supported by a variety of GeoVision controllers, see the compatibility table.

  • Page 82: Appendix

    Appendix What to do if RS-485 connection fails? When a reader successfully connects to GV-AS Controller via RS-485, the Controller's Web interface should show a green tick under Connection Status, and the reader's LED should switch off from a continuous red. If the reader's LED remains red and there is no successful connection status on the Web interface, try adding a 180 Ohms terminal resistor on the RS-485 terminal block of the reader to extend the range of data communication.
