GV-RK1352 / R1352 / DFR1352 Card Reader
The content of this installation guide refers to the following readers:
• GV-RK1352 firmware V1.2
• GV-R1352 firmware V1.2
• GV-DFR1352 (Rev. B) firmware V1.2
Introduction
GV-RK1352 / R1352 / DFR1352 are card readers capable of recognizing identification cards.
GV-RK1352 comes with keypad, allowing it to also recognize PIN codes. GV-DFR1352 is
designed to be installed on the door frame.
Featured with the Wiegand and RS-485 outputs, the readers can be connected to any
standard access control panel. The readers are protected by a weather sealed and IP66
compliant housing for outdoor use.
July 14, 2015
1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GeoVision GV-RK1352
Summary of Contents for GeoVision GV-RK1352
- Page 1 • GV-DFR1352 (Rev. B) firmware V1.2 Introduction GV-RK1352 / R1352 / DFR1352 are card readers capable of recognizing identification cards. GV-RK1352 comes with keypad, allowing it to also recognize PIN codes. GV-DFR1352 is designed to be installed on the door frame.
-
Page 2: Packing List
Packing List GV-RK1352 1. GV-RK1352 Card Reader 2. Screw x 2 3. Screw Anchor x 2 4. Front Cover Plate x 2 5. Software CD 6. Warranty Card GV-R1352 1. GV-R1352 Card Reader 2. Screw x 3 3. Screw Anchor x 2 4. -
Page 3: Physical Descriptions
1. Physical Descriptions 1.1 Electric Wire GV-RK1352 Wire Color Function DC 7.5 ~ 12 V Black Yellow Beeper Orange Green LED Light Red Red LED Green Wiegand Data 0 White Wiegand Data 1 Blue RS-485 + Light Blue RS-485 -... - Page 4 GV-DFR1352 Wire Color Function DC 7.5 ~ 12V Black Yellow Beeper Orange Green LED Light Red Red LED Green Wiegand Data 0 White Wiegand Data 1 Blue RS-485 + Light Blue RS-485 - Gray Purple Rear View Brown Install the GV-DFR1352 to the door frame using the supplied screws and screw anchors. Before placing and sticking the front cover plate to the GV-DFR1352, remove the Plastic Cover to prevent scratches to the cover after installed.
- Page 5 1.2 Keypad (GV-RK1352 Only) When accessing an entry using GV-RK1352, you can enter the door’s PIN code on the keypad or present the card and then enter the card’s PIN code on the keypad to be granted access. The access mode is defined on GV-ASManager.
- Page 6 Note: GV-RK1352 / R1352 / DFR1352 is compatible with GV-AS100 / 1010 / 110 / 120 / 210 / 2110 / 410 / 4110 / 810 / 8110. However, to enable the keypad function on GV- RK1352, you can only connect GV-RK1352 to the controllers through the following interfaces.
- Page 7 2.2 Connecting through RS-485 Interface The following diagrams use GV-RK1352 and GV-AS810 Controller as an example. Up to eight readers can be connected together to the RS-485 interface on GV-AS810 Controller. Connecting four or less readers to GV-AS810 Controller: Wire Color Function...
- Page 8 2.2.1 Defining Readers on GV-AS Controller Web Interface Since multiple readers can connect to GV-AS Controller using one RS-485 interface, you need to specify which door each reader controls. This section explains how to define readers on the Web interface of GV-AS Controller. On the Web interface, you can also set the reader to read the GID or UID on GV-AS ID Cards / Key Fobs.
- Page 9 When you click Submit on the Extended Reader page of a GV-AS1010 / 210 / 2110 / 410 / 4110 / 810 / 8110, all readers connected through RS-485 interface will reboot. GID ID format is only supported in GV-RK1352 / GV-R1352 / GV-DFR1352 (Rev. B) V1.2 or later.
- Page 10 PC through GV-COM, GV-Hub or GV-NET/IO Card V3.1. You can install the Config AP from the Software DVD or GeoVision Website. To use a GV- COM, GV-Hub or GV-NET/IO Card V3.1, you also need to install GeoVision USB Device Driver.
- Page 11 GV-System or GV-R1352 GV-NET/IO Card Note: GV-RK1352 / R1352 / DFR1352 is not compatible with GV-NET Card and GV- NET/IO Card of versions earlier than V3. 4.1 Defining the ID Number and Setting the Reader to Slave After the reader is connected to the computer of the GV-System, use the GV-R/RK/DFR Config AP to define the ID number of the reader and set the reader to Slave.
- Page 12 2. Select the COM port that is connected to the reader and click Open COM. The serial number and firmware version of the reader will be automatically detected. The red square next to the COM port box should change to blue to indicate the COM port is correct. 3.
- Page 13 4.2 Adding the Reader to GV-System 1. In GV-System, click the Configure button, select Accessories, and select GV Wiegand Capture Device Setting. This dialog box appears. 2. Click the New button. This dialog box appears. Type: Select GV-Wiegand Capture. Device: Type a number and name to help you identify the reader. COM: Select the COM port connected to the reader.
- Page 14 5. Changing the Default Settings of Beeper and LED You can change the default settings of the LED and the beeper by enabling a GV-AS210 / 2110 / 410 / 4110 / 810 / 8110 to externally control the LED and Beeper. Through the Web interface, you can set the controller to trigger the red LED, green LED or beeper when the specified alarm events occur.
- Page 15 2. Click Open COM. The serial number and the firmware version of the reader will be automatically detected. 3. To enable external control of Beeper or LED, select Beeper, Green LED or Red LED. 4. Select Master from the Master / Slave drop-down list. 5.
- Page 16 Beeper, Red LED or Green LED to any of the outputs on GV-AS Controller. Wiring LED to GV-AS Controller The diagram below shows the connection for wiring Green LED using GV-RK1352 and GV- AS810 as an example. For Red LED, use the light red wire instead. Wire Color Function...
- Page 17 After wiring, you also need to go to GV-ASManager to select the alarm conditions that will set off the reader’s beeper. In GV-ASManager, right-click the GV-AS Controller in the device list, click Settings, and click the Door / Gate tab to select the alarm conditions. 5.3 Configuring the Beeper and LED Settings for Each Door/Gate After connecting the wires for beeper or LED, specify the conditions to trigger the beeper and LED on the GV-AS210 / 2110 / 410 / 4110 / 810 / 8110 Web interface.
- Page 18 By default, the readers read the UID (unique identifier) on ID cards or key fobs. Using GV- R/RK/DFR Config AP, you can set the GV-RK1352 / R1352 / DFR1352 to read GID (GeoVision ID) on GV-AS ID Cards / Key Fobs instead.
- Page 19 4. Click Setup to apply the setting. To use GID, make sure there are two numbers on your GV-AS ID Cards / Key Fobs as shown below. If there is only one number on your GV-AS ID Cards / Key Fobs, GID is not supported and you must select Unique Identification (UID).
-
Page 20: Firmware Upgrade
7. Firmware Upgrade GeoVision will periodically release the updated firmware on the website. The new firmware can be simply loaded into the reader by using Update Utility included in the Software CD. Important Notes before You Start Before you start updating the firmware, please read these important notes: 1. -
Page 21: Specifications
260 g / 0.57 lb 120 g / 0.26 lb 80 g / 0.17 lb Ingress Protection IP66 Certification CE, FCC, RoHS Note: GID ID format is only supported in GV-RK1352 / GV-R1352 / GV-DFR1352 (Rev. B) V1.2 or later. July 14, 2015... - Page 22 8.1 The Number of Readers Supported by GV-AS Controllers Number of RK1352 / R1352 / DFR1352 Supported GV-AS Controller Model Wiegand RS-485 GV-AS100 GV-AS1010 Not supported GV-AS110 / 120 Not supported GV-AS100 / 110 / 120 with GV-ASBox GV-AS100 / 110 / 120 with GV-ASNet Not supported GV-AS210 / 2110 GV-AS410 / 4110...
- Page 23 9. Accessory (GV-RK1352 Only) Optional accessories can expand the capabilities and versatilities of your GV-RK1352 Card Reader. Consult your sales representative for more information. GV-MountA900 is a mounting plate that allows you to attach GV-RK1352 to a US single gang power box.
