Step 3: Connect the cables of the COSEC ARGO FACE200T unit
and lead the cables through the Flush Mounting plate into the
electrical box recessed in the wall.
Figure 10
Mounting
Slots
Cable
Connectors
Mounting
Screw hole
17
Keep the cables parallel to the side of the COSEC ARGO
•
FACE200T body in such a way that it should not cover the
back portion of the unit as illustrated in the figure below.
Radially curve the cables and lead it through the duct to fit
•
the flush mounting plate easily with COSEC ARGO
FACE200T.
Figure 11
18
