4. TECHNICAL SPECIFICATION

TRANSMISSION STANDARDS
DVB-S2/S, DVBT/T2, DVB-C
SATELLITE INPUT/DEMODULATION
Connector Type
Input Frequency
Signal Input Level
Band Switch Control
LNB Supply
Demodulation Type
Symbol Rate
DVB-T/T2/C INPUT/DEMODULATION
Connector Type
Input Frequency
Signal Input Level
ANT Supply
Demodulation Type
LCD FEATURES
LCD Type
Number of Dots
Active area (WxH)
AV output interface
Connector Type
Video Output
Audio Output
HD output connecter
Format
AV input interface
Connector Type
Video Input
Audio Input
AUDIO/VIDEO PROCESSING
Video decompression
22
F Type
950 to 2150 MHz
- 65 to -25 dBm
22KHz
13V/18V, IMax 400mA
QPSK,8PSK,16APSK
2<Rs<45Mband(SCPC/MCPC)
Female Type
48 to 862 MHz
-79.5dBm (MAX)
5V, 12V/24V Imax 100mA
QPSK,16QAM.64QAM,256QAM
TFT Transmissive
800 x 3(RGB) x 480
154.08 x 85.92 mm
3.5 mm jack
CVBS
Stereo Audio L/R output
HD 1.3a
3.5 mm jack
CVBS
Stereo Audio L/R input
h.265 HVEC, MPEG-2 MP@HL, MPEG-1
Decoding, MPEG 4 ASP@L5 HD
resolution, h.264 MP&HP@L4, HW JPEG
decoding
