4. Transponder: Press A B key then change
the current TP.
5. DiSEqc1.0: Press A B key to change the DiSEqC port.
6. DiSEqc1.1: Press A B key to change the DiSEqC port.
7. Motor: Press A B key to change the DiSEqC port.
If we select DiSEqC1.2/USALS, press OK into
the motor interface.
• Transponder: Press OK to change the current
tp.
• Mode: A, Position
A1 Direction: Press AB key to move direction
to west or east.
A2 Position: Set the satellite save position.
A3 Store: Save the satellite position to set of A2.
• Mode: B, Drive to Zero
Move the cursor to GO, then press OK, the motor will go to zero.
• Mode: C, Drive to stored position
Move the cursor to GO, then press OK, the motor will go to position of we
have saved
in mode A Position.
• Mode: D, Drive to Satellite
Move the cursor to GO, then press OK, the motor will go to position of auto
calculate.
• Mode: E, Recalculate
E1 Direction: Press A B key to move direction to west or east.
E2 Recalculate: Recalculate the satellite position.
• Mode: F, Set East Limit or Set west Limit
Limit the motor move to east or to west.
F1 Direction: Press AB key to move direction to
west or east.
F2 Store: Save the satellite position of A2
• Mode: G, Set Limit enable or disable
Set the limit enable or disable.
8. Unicable: Press A B key to select Unicalbe then press OK into the Unicable
setting.
• Transponder: Press A B key to change the current TP.
• IF Channel: Press A B key to change SCR channel.
