3. THE MENU OSD INSTRUCTION

If you have installed and connected the cables to the receiver, pressing MENU
to display the Main Menu.

• DVB-S2

• DVB-T2
• DVB-C
• Spectrum
• Loop Search
• Optical Power
• Others
• System Setting
Press the keys of YZA B to move the cursor up or down in the menu
interface, then use OK to confirm a selection.
3.1 DVB-S2
Select DVB-S2, then press OK into the Satellite Find.
3.1.1 SATELLITE
Press A B key into the satellite list. Use
YZ key to move the cursor, then press
OK to select the satellite you want.
6
