Jolly line multi spectrum Instruction Manual page 35

3.1.10 DISEQC TYPE & INPUT
If we select diseqc1.0/1.1, we can press AB
key to set the port number. If select Unicable,
we can press AB to select IF Channel, and
use number key to input Center Frequency.
3.1.11 QUICK SEARCH
In the Satellite Find interface, you can press
OK to enter the quick search. If you have set
the Longitude and Latitude under the system
setting, the angle of LNB, the orientation and
elevation of antenna all will be displayed on
the screen.
• TP Scan: Press the red key to search the
current TP.
• Auto Scan: Press the green key to auto blind
search the current satellite.
8
