3.4 SPECTRUM

• SATELLITE-SPECTRUM
• TERRESTRIAL-SPECTRUM
• CABLE-SPECTRUM
3.4.1 SATELLITE-SPECTRUM
Press A B key to change Frequency;
Press red key to change bandwidth;
Press green key to change vertical or
horizontal of polarization;
Press orange key to switch 22K on or off;
Press blue key to change mode Show IF
or RF.
3.4.2 TERRESTRIAL-SPECTRUM
When we enter into this interface, we can
press A B key to scan some information
about spectrum in different frequency point.
• Full/Ch: Press red key to make all the frequency points we can see on the
window or to make some frequency points on it.
• Zoom: Press green key to enlarge showing the point you current select, and
press again
it will be back.
• Locked: Press orange key to lock all the current frequency points, and
remain unchanged unless you press again.
• Scan : When the frequency points have been locked, you can press blue key
to receive signal on a point.
