Installation Of Meter - Jolly line multi spectrum Instruction Manual

NO Description
23 F3
24 F4
25 Red & TTXT
26 Green & SUBT
27 Orange &TV/R
28 BLUE &AUDIO
29 NEVIGATION KEY
30 MENU
31 EXIT
32 INFO
33 MUTE
34 0-9
35 LCD
36
37 Battery
Note1: When the battery charged sufficient, the charge indicator is going out. When
the battery is insufficient, indicator flashing.

1.4 INSTALLATION OF METER

4
Auxiliary function key
Auxiliary function key
Red KEY &Teletext interface
Green key & Subtitle interface
Orange key & TV and radio switch
Blue key & Audio interface
Volume Control or move cursor, channel or change,
confirm etc
Show the main menu on the screen or jump back to
previous menu in sub-menu setting conditions
Escape from present menu and save the settings
INFO key
MUTE
Number key to select channels or enter programming
TFT LCD Screen
When power on the meter ,displays the battery level
Removable Battery
FUNCTION
