EN

7 Trouble shooting

Error
Filtered water cannot
be drawn
Low water flow rate
Aquastop in filter head
leaking while filter
cartridge is removed
Threaded /screw
connection is leaking
Air bubbles

8 Order numbers

Filter cartridge Magnesium Mineralized Water M200
Filter cartridge Magnesium Mineralized Water M300
Filter cartridge Magnesium Mineralized Water M400

9 Table of filter capacities

l.
°dGH
Soft
Medium
Hard
Very Hard
Very, very Hard > 28 °dGH
17
Cause
Water supply in general is
stopped or a valve is closed
Filter cartridge not screwed
properly into the filter head
Filter head fitted incorrectly Check flow direction according to the
System pressure is too low
Particles deposited in
Aquastop
Defective seal
System not completely
purged
Filter capacity in liters (US gal) based on magnesia mineralisation
< 8°dGH
8 - 14 °dGH
15 - 21 °dGH
22 - 28 °dGH
Action
Test all valves and open if necessary
Unscrew filter by ½ rotation and reinsert
as far as possibel
arrow on the filter head and reverse flow
direction if necessary
Check system pressure
Purge/flush filter system with mounted
filter cartridge
Check seal, replace if necessary
Repeat purging/flushing procedure
(Section 5.6)
M200
2000 4.960
(528)
1.140 2.860
(301)
760 1.900
(201)
570
(151)
460
(122)
(Section 5.5)
(Section 5.3)
(Section 4.4)
(Section 5.6)
Order Number
812591
812592
812593
M300
7.440
(1310)
4.280
(756)
2.860
(502)
1.430 2.150
(378)
1.150 1.710
(304)
T1
M400
(1965)
(1131)
(756)
(568)
(452)
