- Page 1 Operation Manual V 1.0 IBZA Series IBZA6HZ Ultra-Compact Multipurpose Loudspeaker Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 EXEL ACOUSTICS SL CL Encinar, 282 – Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (Toledo) Spain Phone: (+34) 918 170 110 Fax: e-mail: support@tecnare.com www.tecnare.com IBZA Series | rev.
-
Page 4: Important Safe Instructions
Use the rigging accessories described in the rigging manual a follow the associated procedures. CAUTION: Rigging should only be done by experience professionals. This speaker enclosure is capable of creating a strong magnetic field. Please use IBZA Series | rev. -
Page 5: Declaración De Conformidad
(1) Directiva de Baja Tensión - 2006/95/CE (2) Directiva de Compatibilidad Electromagnética - 2004/108/CE (3) Directiva RoHS - 2011/65/UE (4) Directiva RAEE - 2012/19/UE (1) Low Voltage Directive 2006/95/CE (2) EMC 2004/108/CE (3) RoHS Directive 2011/65/UE (4) WEEE Directive 2012/19/UE IBZA Series | rev. -
Page 6: Symbols Used
Pour indequer important Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Betriebsanweisung Informationen. Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung Obligación. Estas instrucciones Importantes Información deben ser instrucciones operativas complementaria estrictamente seguidas IBZA Series | rev. -
Page 7: Table Of Contents
Connection to PA4.1500 .................... 15 Connection to PA3000 ....................16 Connection to T-44/48 Series ..................16 Integrating IBZA6HZ Using Subwoofers ..............17 Integrating IBZA6HZ Loudspeakers Systems with Tecnare Subwoofers ....17 Signal Delay ....................... 17 Technical specifications ....................18 IBZA Series | rev. -
Page 8: Introduction
All Tecnare products are carefully engineered for world-class performance and reliability. ® If you would like further information about this or any other Tecnare product, please contact us. We look forward to helping you in the near future. As part of a continuous evolution of techniques and standards, Exel Acoustics ®... -
Page 9: Ibza Series
IBZA Series constitutes a broad range of point source, full range loudspeakers that providing high SPL, different directivities patterns and a good sonic performance off-axis. The IBZA Series is suited to various sound reinforcement applications as a main or complementary system. -
Page 10: The Ibza6Hz Compact Loudspeaker
T-Series amplifiers are available to operate the IBZA6HZ in full-range mode or combined with Tecnare® subwoofers. In full-range mode with or without processor the IBZA6HZ is perfect for speech and vocal applications such as conferencing, TV studios, shopping centre, etc. With a processor, it offers highly accurate music reproduction. -
Page 11: The Ibza6Hz Technology
In Tecnare we have developed a third option, which has substantial benefits. Thanks to its special medium impedance design (40ohm), the Tecnare IBZA6HZ offers, for distributed systems, a high-quality solution, where up to 16 loudspeakers (using 2-ohm amplifiers) could be connected in parallel. -
Page 12: Connections
The IBZA6HZ uses the pin assignment 1+/1+. Using one as the input, the second connector allows for direct connection to a second cabinet in parallel. Internal pinout for IBZA6Plus enclosures ® IN speakON point Connection LF + LF - IBZA Series | rev. -
Page 13: Processing And Amplification
In certain specific cases it is possible to slightly under-power the subs or loudspeakers as long as the amplifier will not be driven to its limits. In any case, the Tecnare processors should be deployed in front of the amp to ensure that the amplifiers to not go into clip. -
Page 14: Loudspeaker Configuration
If your IBZA6HZ loudspeakers and subwoofers are separated by a greater distance - or delay must be used between them - a measurement system such as SMAART should be used to determine the correct delay and polarity. IBZA Series | rev. - Page 15 Operation Manual Frequency Range (+/- 6dB) 40- 20KHz Recommended ratio 1xSW-118M: 4~8 xIBZA6HZ IBZA6HZ + SW-118M IBZA Series | rev.
-
Page 16: Configuration
Tecnare loudspeaker controllers. ® Tecnare only recommends using preset/amplifier developed by Tecnare; otherwise there is a risk of damaging the loudspeaker components. DP Series Loudspeaker Controller, PA Series amplifier and T-Series amplifier are ideal for this purpose. Ensure that the right preset was selected before connecting the loudspeaker with the amplifier. -
Page 17: Connection To Pa3000
Therefore, a single T-44 amplifier controller can drive up to 64 enclosures. A single T-48 amplifier controller can drive 128 enclosures Impedance load: 40Ω for 1 enclosure, 5Ω for 8 enclosures, 2,5Ω for 16 enclosures. T-44 Series Amplifier IBZA Series | rev. -
Page 18: Integrating Ibza6Hz Using Subwoofers
Integrating IBZA6HZ Loudspeakers Systems with Tecnare Subwoofers An IBZA6HZ loudspeaker system can be deployed in combination with Tecnare's subwoofers likes a SW-12, SW115, and SW118M. These subwoofers can achieve very low frequency response extending system response appreciably and increasing the overall acoustic power of a system in the lowest frequencies. -
Page 19: Technical Specifications
As part of the ongoing development program Exel Acoustics SL tries to maintain the highest degree of product compatibility. Applied RMS voltage is set to 2.85V for 40ohm nominal impedance Power of Continuous Program is defined as 3dB greater than the AES rating IBZA Series | rev. - Page 20 Operation Manual IBZA6HZ Dimensions IBZA Series | rev.
- Page 21 Operation Manual IBZA Series | rev.
- Page 22 Exel Acoustics. Tecnare and PCC-Net are trademarks of Exel Acoustics SL. Podware, System Engineer, BvNet, Smaart and all third-party trademarks mentioned herein are the property of their respective trademark holders.
- Page 23 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain (e) support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:1.0 2018...
