- Page 1 Operation Manual Version 1.6 ALIS Series ALIS12 Adaptative Loudspeaker Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 EXEL ACOUSTICS SL CL Encinar, 282 – Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (Toledo) Spain Phone: (+34) 918 170 110 Fax: e-mail: support@tecnare.com www.tecnare.com...
-
Page 4: Important Safe Instructions
Operation Manual IMPORTANT SAFE INSTRUCTIONS Before using our product, be sure to carefully read the manual and safe Instructions. Keep this document with the device all time. Read these instructions. several enclosures on top of one another, straps secure them against Keep these instructions. - Page 5 Operation Manual SYMBOLS USED OBLIGATION. Important operating Additional This instructions instructions information must be strictly followed Obligation. Cela Pour indequer important Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Betriebsanweisung Informationen. Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung...
-
Page 6: Declaración De Conformidad
Operation Manual DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY EXEL ACOUSTICS SL CL Encinar, 282. Polígono Industrial Monte Boyal. 45950 – Casarrubios del Monte (Toledo), España (Spain). Declara que el producto ALIS12 y sus respectivas opciones, cumple con las Directivas: Declare under our sole responsibility that devices in the ALIS12 range of products, comply with relating Directives: (1) Directiva de Baja Tensión - 2006/95/CE (2) Directiva de Compatibilidad Electromagnética - 2004/108/CE... -
Page 7: Table Of Contents
Table of Contents Table of Contents IMPORTANT SAFE INSTRUCTIONS ..................3 DECLARACIÓN DE CONFORMIDAD ..................5 Introduction ........................7 Welcome to Tecnare ....................7 Overview the ALIS 12 ....................8 Connections ....................... 10 Processing and Amplification ..................11 Loudspeaker Configurations ..................12 Standalone System .................... -
Page 8: Introduction
All Tecnare products are carefully engineered for world-class performance and reliability. ® If you would like further information about this or any other Tecnare product, please contact us. We look forward to helping you in the near future. As part of a continuous evolution of techniques and standards, Exel Acoustics ®... -
Page 9: Overview The Alis 12
These coverage characteristics reduce its ability to be used as individual units. In order to cover the requirements for smaller array configurations and shorter throw distances but with the same quality standards as set a line source, led to the design of ALIS Series. ALIS12 loudspeaker Hi-Q "Adaptative... - Page 10 Tecnare ALIS12 is designed as a complete system with the T-Series class D amplifier or DP-4896 DSP controller. Tecnare only recommends using presets developed by Tecnare Sound System.
-
Page 11: Connections
Operation Manual Connections ® ® The ALIS12 loudspeaker utilizes Neutrik SpeakON connectors. There are two NLT4 ® connectors on the rear of each ALIS12. These connectors made with Neutrik NL-4 or NL-4 compatible in-line cable connectors. All four pins of both connectors are wired in parallel to link multiple loudspeakers on a single amplifier output. -
Page 12: Processing And Amplification
The TSeries amplifiers are the ideal companion for maximum performance of ALIS Series loudspeakers. These Advanced System Amplifiers Controlled with DSP offer a complete solution of both preset and protection for any application. The ALIS Series can be driven by T10-48, T06-48, and T20-44 and T10-44 amplifier. -
Page 13: Loudspeaker Configurations
ALIS12 is designed to be used as standalone system, as main system in small to mid- sized venues or like a complement with other Tecnare loudspeakers, with the goal of ensuring full harmonic depth and richness to the audial experience. -
Page 14: Line Source And Subwoofer
ALIS12 standalone or line source, then subwoofers can be added to ALIS12 loudspeaker system to increase the low-frequency response and the overall acoustic power. Tecnare SW118M, SW218V or SW218EB can achieve frequency response down to 30 to 45 Hz range, extending the low-end bandwidth. -
Page 15: Power Amplifier Selection For Alis12
Also, Tecnare PA Series two and four channel power amplifiers are recommended for use with ALIS Series together with the DP4896 processors. These amplifiers work well at 4 ohms, making it possible to power two cabinets in parallel from each amplifier channel. -
Page 16: Recommended Speaker Cables
Damping factor is a ratio of rated loudspeaker impedance (ZL) to the source impedance (Zs). In this case our source impedance is (Rcable + Ramplifier). Damping Factor = Z ® The table below indicates the cable valour recommended by Tecnare Recommended maximum length 8 Ω 4 Ω... -
Page 17: Loudspeaker Connection
Tecnare loudspeaker controllers. ® Tecnare only recommends using preset/amplifier developed by Tecnare; otherwise there is a risk of damaging the loudspeaker components. DP Series Loudspeaker Controller, PA Series amplifier and T-Series amplifier are ideal for this purpose. Ensure that the right preset was selected before connecting the loudspeaker with the amplifier. -
Page 18: Connecting Alis12 To Pa4.1500
Operation Manual Connecting ALIS12 to PA4.1500 MAXIMUM OF 2 ENCLOSURES PER PA4.1500 2 x V14CX can be connected in parallel to each pair of output channels on the PA4.1500 amplifier. Impedance load: PASSIVE: 1 Enclosure: 8Ω; 2 Enclosures: 4Ω BI-AMP: 1 Enclosure → LF: 8Ω; HF: 16Ω; 2 Enclosures → LF: 4Ω; HF: 8Ω Connecting Bi-amp enclosure Connecting Passive enclosure... -
Page 19: Connecting Alis12 To T-Series
Operation Manual Connecting ALIS12 to T-Series MAXIMUM NUMBER OF ENCLOSURES PER T-SERIES Max enclosures in parallel Max enclosures by amplifier Enclosure T20- T10- T06- T10- T06- T03- T20- T10- T06- T10- T06- T03- ALIS12 BI-AMP ALIS12P PASSIVE * For bi-amp loudspeaker, the value corresponds to the number of cabinet connected in parallel in the way by output. -
Page 20: Transport And Storage
Operation Manual Transport and storage Because the ALIS12 loudspeaker weighs 33’5 kg (73.85lbs), when the enclosure is transported or stored, it is very important to ensure that both the finish and front grille are not damaged. The following accessory parts for transport and storage are available from Exel Acoustics: •... -
Page 21: Technical Specifications
Technical Specifications Technical specifications ACOUSTICAL 55/80 (1) Hz – 20kHz±3dB (1 box), measured on axis. Recommended operating frequency range. Operating Frequency Range Response depends on loading conditions and room acoustics Axial Sensitivity 104 dB (1w/1m) Bi-amp: 131 dB continuous/137 Peak Calculated SPL Passive: 129 dB continuous/135 Peak Horizontal: 20º... - Page 22 Operation Manual ALIS12 R2 Dimensions...
- Page 23 Operation Manual TWD-ALIS12 Wooden dolly Dimensions...
- Page 24 Operation Manual...
- Page 25 Exel Acoustics. Tecnare and PCC-Net are trademarks of Exel Acoustics SL. Podware, System Engineer, BvNet, Smaart and all third-party trademarks mentioned herein are the property of their respective trademark holders.
- Page 26 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain (e) support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:1.60 2018...
