TECNARE ALIS Series Operation Manual
Adaptative loudspeaker
Hide thumbs
Also See for ALIS Series:
- Rigging assembly manual (41 pages) ,
- Operation manual (26 pages)
Related Manuals for TECNARE ALIS Series
Summary of Contents for TECNARE ALIS Series
- Page 1 Operation Manual Version 1.5 ALIS Series ALIS15 Adaptative Loudspeaker Keep these important operating instructions. Check www.tecnare.com for updates.
- Page 3 EXEL ACOUSTICS SL CL Encinar, 282 – Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (Toledo) Spain Phone: (+34) 918 170 110 Fax: e-mail: support@tecnare.com www.tecnare.com...
-
Page 4: Important Safe Instructions
Operation Manual IMPORTANT SAFE INSTRUCTIONS Before using our product, be sure to carefully read the manual and safe Instructions. Keep this document with the device all time. Read these instructions. several enclosures on top of one another, straps secure them against Keep these instructions. - Page 5 Operation Manual SYMBOLS USED OBLIGATION. Important operating Additional This instructions instructions information must be strictly followed Obligation. Cela Pour indequer important Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Betriebsanweisung Informationen. Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung...
-
Page 6: Declaración De Conformidad
Operation Manual DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY EXEL ACOUSTICS SL CL Encinar, 282. Polígono Industrial Monte Boyal. 45950 – Casarrubios del Monte (Toledo), España (Spain). Declara que el producto ALIS15 y sus respectivas opciones, cumple con las Directivas: Declare under our sole responsibility that devices in the ALIS15 range of products, comply with relating Directives: (1) Directiva de Baja Tensión - 2006/95/CE (2) Directiva de Compatibilidad Electromagnética - 2004/108/CE... -
Page 7: Table Of Contents
Table of Contents Table of Contents IMPORTANT SAFE INSTRUCTIONS ..................3 DECLARACIÓN DE CONFORMIDAD ..................5 Introduction ........................7 Welcome to Tecnare ....................7 Overview the ALIS 15 ....................8 Connections ....................... 10 Processing and Amplification ..................11 Loudspeaker Configurations ..................12 Standalone System .................... -
Page 8: Introduction
All Tecnare products are carefully engineered for world-class performance and reliability. ® If you would like further information about this or any other Tecnare product, please contact us. We look forward to helping you in the near future. As part of a continuous evolution of techniques and standards, Exel Acoustics ®... -
Page 9: Overview The Alis 15
In order to cover the requirements for smaller array configurations and shorter throw distances but with the same quality standards as set a line source, led to the design of ALIS Series. ALIS15 loudspeaker is a 2-way full range, "Adaptative Loudspeaker Integrate point Source”... - Page 10 Tecnare ALIS15 is designed as a complete system with the T-Series class D amplifier or DP-4896 DSP controller. Tecnare only recommends using presets developed by Tecnare Sound System.
-
Page 11: Connections
Operation Manual Connections ® ® The ALIS15 loudspeaker utilizes Neutrik SpeakON connectors. There are two NLT4 ® connectors on the rear of each ALIS15. These connectors made with Neutrik NL-4 or NL-4 compatible in-line cable connectors. All four pins of both connectors are wired in parallel to link multiple loudspeakers on a single amplifier output. -
Page 12: Processing And Amplification
In certain specific cases it is possible to slightly under-power the subs or loudspeakers as long as the amplifier will not be driven to its limits. In any case, the Tecnare processors should be deployed in front of the amp to ensure that the amplifiers to not go into clip. -
Page 13: Loudspeaker Configurations
Loudspeaker Configurations ALIS15 is designed to be used as standalone system, as main system in mid-sized to large venues or like a complement with other Tecnare loudspeakers, with the goal of ensuring full harmonic depth and richness to the audial experience. -
Page 14: Line Source And Subwoofer
ALIS15 standalone or line source, then subwoofers can be added to ALIS15 loudspeaker system to increase the low-frequency response and the overall acoustic power. Tecnare SW118M, SW218V or SW218EB can achieve frequency response down to 30 to 45 Hz range, extending the low-end bandwidth. -
Page 15: Power Amplifier Selection For Alis15
Also, Tecnare PA Series two and four channel power amplifiers are recommended for use with ALIS Series together with the DP4896 processors. These amplifiers work well at 4 ohms, making it possible to power two cabinets in parallel from each amplifier channel. -
Page 16: Recommended Speaker Cables
Damping factor is a ratio of rated loudspeaker impedance (ZL) to the source impedance (Zs). In this case our source impedance is (Rcable + Ramplifier). Damping Factor = Z ® The table below indicates the cable valour recommended by Tecnare Recommended maximum length 8 Ω 4 Ω... -
Page 17: Loudspeaker Connection
Tecnare loudspeaker controllers. ® Tecnare only recommends using preset/amplifier developed by Tecnare; otherwise there is a risk of damaging the loudspeaker components. DP Series Loudspeaker Controller, PA Series amplifier and T-Series amplifier are ideal for this purpose. Ensure that the right preset was selected before connecting the loudspeaker with the amplifier. -
Page 18: Connecting Alis15 To Pa5000
Operation Manual Connecting ALIS15 to PA5000 MAXIMUM OF 2 ENCLOSURES PER CHANNEL OF PA5000 2 x ALIS15 can be connected in parallel to each pair of output channels on the PA5000 amplifiers. Impedance load: PASSIVE: 1 Enclosure: 8Ω; 2 Enclosures: 4Ω BI-AMP: 1 Enclosure →... -
Page 19: Connecting Alis15 To T-Series
Operation Manual Connecting ALIS15 to T-Series MAXIMUM NUMBER OF ENCLOSURES PER T-SERIES Max enclosures in parallel Max enclosures by amplifier Enclosure T20- T10- T06- T10- T06- T03- T20- T10- T06- T10- T06- T03- ALIS15 BI-AMP ALIS15P PASSIVE * For bi-amp loudspeaker, the value corresponds to the number of cabinet connected in parallel in the way by output. -
Page 20: Transport And Storage
Operation Manual Transport and storage Because the ALIS15 loudspeaker weighs 42 kg (92.6lbs), when the enclosure is transported or stored, it is very important to ensure that both the finish and front grille are not damaged. The following accessory parts for transport and storage are available from Exel Acoustics: •... -
Page 21: Technical Specifications
Technical Specifications Technical specifications ACOUSTICAL 48/80 (1) Hz – 20kHz±3dB (1 box), measured on axis. Recommended operating frequency range. Operating Frequency Range Response depends on loading conditions and room acoustics Axial Sensitivity 107 dB (1w/1m) Bi-amp: 132 dB continuous/138 Peak Calculated SPL Passive: 131 dB continuous/136 Peak Horizontal: 40º... - Page 22 Operation Manual ALIS15 R2 Dimensions...
- Page 23 Operation Manual TWD-ALIS15 Wooden dolly Dimensions...
- Page 24 Operation Manual...
- Page 25 Exel Acoustics. Tecnare and PCC-Net are trademarks of Exel Acoustics SL. Podware, System Engineer, BvNet, Smaart and all third-party trademarks mentioned herein are the property of their respective trademark holders.
- Page 26 EXEL ACOUSTICS SL CL Encinar, 282 - Pol. Ind. Monte Boyal 45950 Casarrubios del Monte (To) Spain (e) support@tecnare.com www.tecnare.com - www.facebok.com/tecnare (T): +34 918 170 110 - +34 918 171 001 (F): +34 918 183 053 rev.:1.50 2018...
