IMPORTANT SAFE INSTRUCTIONS Before using our product, be sure to carefully read the manual and safe Instructions. Keep this document with the device all time. Read these instructions. TECNARE systems has been made in accordance with applicable local Keep these instructions.
Page 5
Introduction SYMBOLS USED OBLIGATION. Important operating Additional This instructions instructions information must be strictly followed Obligation. Cela Pour indequer important Information doit être Instructions complémentaire strictement instructions Suivi Wichtige Pflicht. Diese Betriebsanweisung Informationen. Anweisungen oder Zusätzliche müssen strikt Gebrauchsanleitung Informationen befolgt sanleitung Obligación.
Introduction DECLARACIÓN DE CONFORMIDAD DECLARATION OF CONFORMITY EXEL ACOUSTICS SL CL Encinar, 282. Polígono Industrial Monte Boyal. 45950 – Casarrubios del Monte (Toledo), España (Spain). Declara que los siguientes productos: ▪ Pickup Plate THV-ALIS12/THV-ALIS15 ▪ Top Grid TTG ALIS12/THV-ALIS15 ▪ Array Frame TAF-ALIS12/TAF-ALIS15 ▪...
Horizontal array with THV-ALIS Series ..............13 The TecB004 Spreader Bar ..................16 Vertical array with TTG-ALIS15 ................. 18 The TAF-ALIS Series for fixed installations ............... 21 SUSPENSION OF VERTICAL ARRAY WITH TTG-ALIS15 ........... 25 Modelling and inspection ................... 25 The TTG-ALIS15 grid ....................
This user manual contains essential information for rigging and deploying ALIS Series loudspeakers to their full capability. Assembly concept for ALIS Series loudspeakers is the same for both ALIS12 and ALIS15 enclosures so we will show you the information in this guide taking as reference ALIS15 enclosure except in those particular accessories in which there are assembly differences between both models.
T-44/48: Advanced System Amplifier ▪ System Engineer: Remote control software for amplifier OTHER ALIS SYSTEM COMPONENTS All the other components of the system are presented in the ALIS Series user manual, document intended to describe the operating modes and the loudspeaker connection.
Page 11
Rigging Assembly Guide THV-ALIS15 THV-ALIS12 TTG-ALIS12 TTG-ALIS15 TA12-SMB TecB004 Main components involved in the rigging system of ALIS Series enclosures...
Operation Manual ARRAY CONFIGURATIONS The ALIS loudspeaker has got a complete collection of rigging, flying, and mounting options. Comprised of rugged, reliable, and easy-to-configure components, lets you deploy ALIS loudspeakers as arrays at fixed angles to take full advantage of their directional design. The top and bottom sides for the ALIS cabinets include threaded metric holes (for M8 screws) for easy connection to rigging and third-party mounting options.
Page 13
Rigging Assembly Guide Remove the front pins of each coupling bar. Fig. 3 Located the ALIS15s next to each other and align the adjacent the rails so they are as close as possible to each other. Fig.4 Fig. 3 Fig. 4 From the rear, slide the coupling bars inwards and re-attaching the front quick-release pins.
Operation Manual Horizontal array with THV-ALIS Series The optional THV-ALIS Series pickup plate allows lifts ALIS horizontal arrays with uptilt or downtilt. A single pickup plate supports 1-4 loudspeakers. Two pickup plates and the accessory TecB004 universal Fly Bar support 5-6 loudspeakers. The pickup plate comes with M8 bolts, and washers for securing the plate to the ALIS cabinet.
Page 15
Rigging Assembly Guide Procedure Place the enclosures carefully to a Attach the THV-ALIS15 pickup vertical position using plate over the enclosure and top/bottom recessed handles, with screw it with the included screws the horn directed upwards or in the same position shown in downwards.
Page 16
Operation Manual The following configurations are allowed: 6x ALIS15 + 2x THVALIS15; 5x ALIS15 + 2x THVALIS15; 4x ALIS15 + 2 x THVALIS15; 4x ALIS15 + 1 x THVALIS15; 3x ALIS15 + 2x THVALIS15; 3x ALIS15 + 1x THVALIS15; 2x ALIS15 + 1x THVALIS15 and ALIS15 + THVALIS15 Fig.12 ALIS15 in horizontal array When an array is suspend with two THV-ALIS15 pickup plates, two pick points for each pickup plate can be using.
Rigging Assembly Guide The TecB004 Spreader Bar The optional TecB004 spreader bar can suspend two THV-ALIS Series pickup plates from a single motor point. Under no circumstances is a bridled suspension chain allowed. Seventeen hanging points are provided at each end of the spreader bar to adjust the spread between the pickup plates.
Page 18
Operation Manual Fig. 13 Six ALIS15s Horizontal Array with two THV-ALIS15s suspended from the TecB004 Spreader Bar CAUTION: Routine maintenance inspections of the shackles should include a check for wear inside the shackle, check the body for distortion and check for the wear on the shackle pin. Never Replace a Shackle pin with a Bolt.
Rigging Assembly Guide Vertical array with TTG-ALIS15 The ALIS15 loudspeaker array can be suspends vertically using the optional TTG-ALIS15. Before starting to assemble the array, you must define the orientation of the HF section of the cabinets. The ALIS15 cabinets have an asymmetric design. To enable a symmetrical setup for stereo systems, one’s cabinet orientation may be reversed.
Page 20
Operation Manual To assemble more enclosures, take the group of two enclosures joined before and follow the steps described on the point 1 and 2. (Figure 17 and 18). The optional TTG- ALIS15 vertical grid was designed to suspend up to six units. Fig.
Page 21
Rigging Assembly Guide If you will suspend the system with two motor points two TTG-ALIS15 grid are needed and should be assembled as shown in the next figure. Fig. 21 Three ALIS15s Vertical Array with two TTG-ALIS15s to be suspended by two motor points CAUTION: For array pull-back configuration, use a second TTG-ALIS15 grid.
Operation Manual The TAF-ALIS Series for fixed installations In a fixed installation and for get better control and stability TAF-ALIS12 / TAF-ALIS15 array frame are recommended to use. The array frame TAF-ALIS will be used to interconnect and fixing two ALISs enclosures.
Page 23
Rigging Assembly Guide Fig. 24 Three ALIS15 enclosure assembled Fig. 24 Four ALIS15 enclosure assembled Fig. 24 Five ALIS15 enclosure assembled...
Page 24
Operation Manual Procedure in Vertical Array Place the cabinets one above the other, on a flat surface with the correctly orientation of HF section previously defined. See Figure 25. Use the TALBX15 bar to join the enclosures. Remove the correspondent screws and attach the respective TAF-ALIS15s plates and tighten it with the included screws.
Page 25
Rigging Assembly Guide Fig. 28 Fig. 29 Two TAF-ALIS15 plate by side with three ALIS15s Fig. 31 ALIS15 Vertical Array with TAF-ALIS15 Fig. 30 Assemble of TTG-ALIS15 frame to fixing, 4-deep...
Operation Manual SUSPENSION OF VERTICAL ARRAY WITH TTG-ALIS15 CAUTION: Before TTG-ALIS15's suspension check the shackle is properly fitted to the Rigging point and secured against loosening. Modelling and inspection Before installing the systems it is a good idea to be sure about: ▪...
Page 27
Rigging Assembly Guide The suspension of the TTG-ALIS15 is carried out using one or two TTG-ALIS15 bar fitted with a 2t shackle, depending on the chosen type of suspension (Single or Dual hanging point). Procedure to Single hanging point suspension In "Single hanging point"...
Is recommended use a laser /inclinometer device for this operation. Refer to our Tecnare support team if you have got any question about how to do it.
Page 29
Rigging Assembly Guide Procedure 1. Before attaching the safety device ensure the two 2t shackles are properly fitted to the grid and secured against loosening with a locked ring cotter - Fig. 36 Fig. 36 Safety bolt to secure the 2t shackle 2.
Page 30
Operation Manual These secondary safety points also enable to get more pickup configurations with two motors. The TTG-ALIS15 grid support the following pickup configurations with two motors Fig. 38 (a) Two motors 3 Pickup points, Rear Bridle; (b) Two Motors 3 Pickup points, Front Bridle Fig.
Rigging Assembly Guide TA12-SMB SOCKET MONTAIN The optional TA12-SMB pole mount socket allow to one ALIS12 cabinet to be pole mounted. Fig.40 Optional TA12-SMB Socket Mounting Bracket Procedure Place the enclosure side where the Remove the pin from the angle optional TA12- socket bracket will be hole.
Page 32
Operation Manual Fig. 45 TA12-SMB socket bracket with a ALIS12 enclosure CAUTION: Installation and setup should only be carried out by qualified and authorized personnel observing the valid national Rules for the Prevention of Accidents (RPA). It is the responsibility of the person installing the assembly to ensure that the fixing points are suitable for the intended use.
Rigging Assembly Guide Possible angles on ALIS12 using TA12-SMB The angles available on ALIS12 using the optional TA12-SMB are those shown in the previous picture.
Operation Manual FC-ALIS SERIES The optional dedicated flight-cases are capable to fit 1 x ALIS12/15 or 2 x ALIS12/15 enclosures in vertical position. Both the tray and cap should feature a foam insert cut according to the shape on the enclosure.
7 Service, Inspection & Maintenance General Service If all components in the Tecnare® system are used as it is described in this manual they will remain fully operational over the enclosures’ life. These has been designed to withstand the most rigorous and demanding environments. However, through regular operation it may still be necessary to replace acoustical, electronic and mechanical components.
Page 40
Exel Acoustics. Tecnare and PCC-Net are trademarks of Exel Acoustics SL. Podware, System Engineer, BvNet, Smaart and all third-party trademarks mentioned herein are the property of their respective trademark holders.
