Page 1
SERIE S/L (SF-SB-SH-LF-LB-LH) REV. 2023 INSTRUCTIONS AND SPARE PARTS MANUAL...
Page 2
For the correct use and enjoyment of this equipment, we strongly recommend that the customer read the instructions contained in this manual and use it as a reference for any questions that may arise regarding the operation of your OVLAC equipment. Sincerely yours: Jorge Calvo...
Page 3
CONSIDERATIONS INDEX 1.- Safety Rules 2.- Description and technical data This instruction manual describes the Operating and Maintenance Instructions and Spare Parts for the indicated equipment. 3.- Security System This agricultural equipment is designed for tilling the soil, applied to 4.- Adaptation to the tractor a Tractor with lifting gear and universal threepoint linkage.
1.- Security Rules 11.- Before starting to work, familiarise yourself with the control devices. Read carefully all the instructions for use of the cultivator. 12.- Pay the utmost attention to hitching and unhitching the equipment. The manufacturer declines all responsibility for any inconvenience caused by NOT observing the Safety and Accident Prevention Regulations described below.
Page 5
WARNING To be ready in case of an emergency Before starting to work, read the instructions in the Keep a first aid kit and fire extinguisher on hand. Write manual. down the telephone numbers of doctors, ambulance and fire brigade and keep them near the phone. DANGER Use adequate clothes Do not handle the equipment when it is suspended, danger...
SPECIFIC INSTRUCTIONS FOR WELDING REPAIRS When repair by welding is authorised by the manufacturer, the 4 Our machines are made of high elastic limit (HEL) steels, which following points shall be taken into account generally. means that special attention must be paid to welding processes In particular cases, appropriate welding instructions shall be and filler materials.
2.- Description and Technical Data HEADSTOCK IDENTIFICATION PLATE* TURNING CYLINDER OSCILLATIN SHAFT SKIMMER SKIMMER SUPLEMENT SHARE POINT SHARE FRAME CONTROL WHEEL Note: the number of the plough’s manufacture, engraved on the nameplate, must match the number engraved on the headstock’s support. *2.
Technical Data L MODELS Interbody distance 85/95 cm (standard or choose) and 105 cm (optional) > 105 cm unavailable in some models (see more below) Underbeam clearance 72 cm or 78 cm (standard or choose) 90 in option for LF 120/130 and 150 Working width 14, 16, 18 and 20”...
3.- Security Systems Shearbolt security systems warantee protections through its shearing bolts. When the tip faces an obstacle, the bolt breaks, allowing the leg to turn on its hosting. In order to continue the labor you need to place the leg again and find a new replacement for the bolt B.
Page 10
Once the pressure is adjusted, close the keys A and C. Fig. 4 NOTE: The OVLAC Non-Stop security systems are regulated in-factory at an optimum pressure for medium-hardness terrains. Always work with apressure in between 120 and 135 bars. Maximum working pressure is 140 bars.
Page 11
4.- Turn Up - Link to the tractor - Working bodies OVLAC ploughs are designed to be adapted to the three universal linking Eliminate the layer of paint that protects the bodies before points of any tractor. working, in order to avoid sticky soil in your bodies.
Page 12
The plough must work aligned with the tractor, if not, the plough will tend to abandone the working direction. Must check that the distance A1=A2 (Fig. 7, pág. 10). In the OVLAC ploughs, the drifting effect is auto-corrected thanks to the oscillating shaft.
- Working depth The working depth is regulated through the lifting pull of the tractor. Nontheless, in order to obtain an even working width in order to save power, all ploughs must be equipped with a depth-limiting wheel (Fig. 12) which height is regulated through the threaded tops A, as the Fig.
- Other adjustments The length of the third point must be adjusted in a way that the frame is parallel to the ground, otherwise the first bodies would work at uneven depth compared to the last bodies, resulting in uneven labor (Fig. 14). Fig.
Page 15
5.- Turn up - Turning and memory The turning point of the plough is done from the tractor·s cabin, acting in a programmed way over the corresponding hydraulic controller up to the end of the turn - This is made by turning always to the same side. Ploughs with 5 or more bodies standardly incorporate an hydraulic memory that aligns the plough automatically, turnit y and give it back to the working position prior to the turning maneuver when acting continously over the corresponding hydraulic controller.
Page 16
- Varilabor In the OVLAC Series L models the working width can be adjusted up to the needs of the farmer, in 4 different positions divided by steps of 2" (5 cm). The positions 1 and 4 answer to the minimum and maximum positions, respectively (Fig. 16). After changing the working width of the plough, you must regulate the landslide extension of the plough through the memory cylinder C by adjusting the working measure as the sticker X indicates (Fig.
Page 17
- 1st Furrow width The first furrow width is adjusted acting over the tensor T that displays the headstock (Fig. 19) in a way that verifies the observations described in the Fig. 21. The plough counts with regulation possibilities conceived for a width between wheels of 110 to 150 cm.
Page 18
- Perpendicularity of the plough working For the same reason, you must check (while laboring) that the anchors adopt a perpendicular position to the ground (Fig. 22). For that, we need the tines of the tractor to be at the same height AND ACT OVER THE TURNING TOPS A FOUND AT BOTH SIDES OF THE HEADSTOCK (Fig.
Page 19
6.- Wastes burial For an optimal burial of harvesting leftovers and weeds we can equip the plough with trashboards (Fig. 24) or the bodies (Fig. 25). The trashboards can be regulated according to the working depth, scrolling it over the holder's slider. The skimmers must adapt to the working depth acting over the bolts that supports them.
Page 20
7.- Transport and parking In order to ease the transport, the plough must be retracted to its minimum width, acting over the cut control system. Ploughs with great lenghts (5 and 6 bodies) can be optionally given with polyvalent wheels of control/transport. To transport the plough over the control/transport wheel, place the hole C in the position B of the bolt C (Fig.
8.- Maintenance Must check how tighten the bolts are after the first 2 hours of labor, specially the Watch out for the high pressure leaks ones on the bodies and shares. Afterwards, check every 100 hours of labor. When Leaking fluids from the system might leak strong enough to tear flesh, finishing the campaign, wash the plough and grease the bodies to avoid rust.
Page 22
9.- Optional Gear L and S OVLAC ploughs can be equipped with: Trashboard (Fig. 31) Landslide extension (Fig. 32) Transport wheel (Fig. 33) Discs (Fig. 34) Advanced wheel (Fig. 35) 1st body hydraulic width (Fig. 36) Fig. 36 Fig. 31 Advanced Transport wheel (Fig.37)
10.- Spare parts Spare parts orders must always be placed through dealers and will include the next indications: - Type, model and plough's number of manufacturing. This data is indicated on the identification plate of the plough. - Reference of the piece. Indicated on the spareparts catalogue. - Name of the piece and quantity required.
Page 25
Index HEADSTOCK 120 ....................25 SLATTED BODY “OV” ....................79 HEADSTOCK 130 ..................... 27 TRASHBOARDS ....................... 81 HEADSTOCK 150 ....................29 SHEARBOLT SKIMMERS ..................83 HYDRAULIC TURNOVER SYSTEM 120 ..............31 NON-STOP SKIMMERS ..................85 HYDRAULIC TURNOVER SYSTEM 130-150-180...........33 LANDSLIDE EXTENSION ..................87 SUPPORT FRAME 120-130 ..................
