  • Page 1 REV 2021 MINIVID INSTRUCTIONS MANUAL AND SPARE PARTS LIST...
  • Page 2 For the correct use and enjoyment of this equipment, we strongly recommend that the customer read the instructions contained in this manual and use it as a reference for any questions that may arise regarding the operation of your Ovlac equipment. Sincerely yours: Jorge Calvo...
  • Page 3 2.- Description and technical data Maintenance Instructions and Spare Parts for the indicated equipment. This agricultural equipment, called MINIVID, is designed for tilling 3.- NON STOP Security System the soil, applied to a Tractor with lifting gear and universal threepoint linkage.

  • Page 4: Security Rules

    1.- Security Rules 11.- Before starting to work, familiarise yourself with the control devices. Read carefully all the instructions for use of the cultivator. 12.- Pay the utmost attention to hitching and unhitching the equipment. The manufacturer declines all responsibility for any inconvenience caused by NOT observing the Safety and Accident Prevention Regulations described below.
  • Page 5 To be ready in case of an emergency WARNING Keep a first aid kit and fire extinguisher on hand. Write Before starting to work, read the instructions in the manual. down the telephone numbers of doctors, ambulance and fire brigade and keep them near the phone. DANGER Do not handle the equipment when it is suspended, danger Use adequate clothes...

  • Page 6: Welding Repairs

    SPECIFIC INSTRUCTIONS FOR WELDING REPAIRS When repair by welding is authorised by the manufacturer, the 4 Our machines are made of high elastic limit (HEL) steels, which following points shall be taken into account generally. means that special attention must be paid to welding processes In particular cases, appropriate welding instructions shall be and filler materials.

  • Page 7: Description And Technical Data

    2.- Description and Technical Data HEADSTOCK IDENTIFICATION PLATE* BÂTI CYLINDERS SET SLIDING CYLINDERS HYDRAULIC SYSTEM BODIES SET SECURITY SYSTEM ROLLERS SET SIDEPLATES Note: the number of the plough’s manufacture, engraved on the nameplate, must match the number engraved on the headstock’s support.

  • Page 8: Technical Data

    Technical Data MINIVID-10 MINIVID-12 MINIVID-14 MINIVID-16 MINIVID-18 MODELS MINIVID-8 MINIVID-PRO 10 MINIVID-PRO 12 MINIVID-PRO 14 MINIVID-PRO 16 MINIVID-PRO 18 1,05 1,40 1,65 1,90 2,15 2,40 Working width (fix version) Working WIdth (PRO version) 1,40 to 1,70 1,65 to 1,95 1,90 to 2,20...
  • Page 9 OVLAC Minivid are designed to adapt to the 3 universal points of any tractor. This way, every impact caued by uneven terrain will be absorbed by the security system, which protects the elements of the machine, and therefore, also the tractor.
  • Page 10 - Alignment The cultivator must work aligned with the tractor, if not, the plough will tend to abandone the working direction. Must check that the distance A1=A2 (Fig. 4). On the cultivators, for the proper functioning of work levelling, is important to regulate and allign correctly the lifting arms of the tractor with the cultivator and, if having a roller, along the arms, for a good depth control.
  • Page 11 - Other adjustments For the same reason, is necessary for the tractor arms to be found The length of the 3rd point must be adjusted in a way that the at the same height, so the machine works at the same depth in its frame adopts a parallel position to the ground, if not, the rows of whole width (Fig.

  • Page 12: Working Depth

    At the machines with hydraulic adjustment of the disc row's the regulation bolts A (Fig.6). width (Minivid Pro), this will be retracted in order to ease its In no case the working depth will be such that the bushings of transport, leaving the machine on its minimal width.

  • Page 13: Maintenance

    7.- Maintenance Must check how tighten the bolts are after the first 2 hours of labor, specially Watch out for the high pressure leaks the ones on the bodies and shares. Afterwards, check every 100 hours of labor. When finishing the campaign, wash the plough and grease the bodies to avoid Leaking fluids from the system might leak strong enough to tear flesh, causing rust.

  • Page 14: Optional Equipment

    8.- Optional equipment Ovlac MINIVID (fixated or extensible) can be equipped with: Extensible roller (Fig.7) Sideplates (Fig.8) Foldable headstock (Fig.9) Fig. 7 Fig. 8 Fig. 9...

  • Page 15: Spare Parts

    9.- Spare Parts Spare parts orders must always be placed through dealers and will include the next indications: - Type, model and plough's number of manufacturing. This data is indicated on the identification plate of the plough. - Reference of the piece. Indicated on the spareparts catalogue. - Name of the piece and quantity required.
  • Page 17 Index BEAM / FRAME FIX MINIVID ................17 BEAM / FRAME MINIVID PRO ................19 HYDRAULIC SYSTEM LATERAL FRAMES ............. 21 FOLDABLE HEADSTOCK (<2022) ................23 NEW FOLDABLE HEADSTOCK (>2022) ............... 25 HYDRAULIC SYSTEM FOLDABLE HEADSTOCK ........... 27 MINIVID BODY ....................... 29 MCH MINIVID BODY ....................
  • Page 18 BEAM / FRAME FIX MINIVID...
  • Page 19 BEAM / FRAME FIX MINIVID REFERENCIA DESCRIPCIÓN REFERENCIA DESCRIPCIÓN 53000484 TAPON PVC 80x80 77501904 LLANTA UNION TORRETA MINIVID 60000083 TORN.EXAG.DIN-931 16* 90 8.8 77501912 PLACA TORRETA DCH.MINIVID (D/16) 60000096 TORN.EXAG.DIN-933 20* 50 8.8 77501913 PLACA TORRETA IZQD.MINIVID (D/16) 60000102 TORN.EXAG.DIN-931 20* 80 8.8...
  • Page 20 BEAM / FRAME MINIVID PRO...
  • Page 21 BEAM / FRAME MINIVID PRO REFERENCIA DESCRIPCIÓN REFERENCIA DESCRIPCIÓN 60000083 TORN.EXAG.DIN-931 16* 90 8.8 77502902 PAÑO TRAS.IZQD.MINIVID-18 60000096 TORN.EXAG.DIN-933 20* 50 8.8 77502903 PAÑO DEL.DCH.MINIVID-18 60000108 TORN.EXAG.DIN-931 20*110 8.8 ZINC. 77502904 PAÑO DEL.IZQD.MINIVID-18 60000143 TUER.AUTO.DIN-980 16 8.8 ZINC. 77502911 PAÑO TRAS.DCH.MINIVID-14 60000160 TUER.EXAG.DIN-934 16 8.8 ZINC.
  • Page 22 HYDRAULIC SYSTEM LATERAL FRAMES...
  • Page 23 HYDRAULIC SYSTEM LATERAL FRAMES REFERENCIA DESCRIPCIÓN REFERENCIA DESCRIPCIÓN 51000138 CILIND.C/AMARRE ROSC.ALARG.25/40/150 53000125 LATIG.R2-3/8*2290mm.MF-1/2/CTL-3/8 51000139 CILIND.C/AMARRE ROSC.ALARG.30/50/150 53000200 PLACA RFZO.AB.DOBLE 19 GD3D 51000157 CILIND.C/AMARRE ROSC.ALARG.25/40/140 53000236 UNION REDUCCION 1/4-1/2 4371 51000158 CILIND.C/AMARRE ROSC.ALARG.30/50/140 53000277 PROTECTOR E.R.MACHO 1/2" AZUL 5029-4PB 52000001 VALV.BLOQUEO ZINC.12 VBD38 53000323 LATIG.R2-3/8* 500mm.OR-3/8/TL-18 53000001...
  • Page 24 FOLDABLE HEADSTOCK (<2022)
  • Page 25 TORN.EXAG.DIN-931 20*110 8.8 ZINC. 70021930 SOP.LATIG.MINIVID ABATIBLE 60000131 TUER.AUTO.DIN-980 8 8.8 ZINC. 70060903 ARAND.P/BULON PLEG.CH/MCH/DISC 60000142 TUER.AUTO.DIN-980 12 8.8 ZINC. 77511910 PLACA SOP.TORRETA ABATIBLE MINIVID 60000146 TUER.AUTO.DIN-980 20 10.9 ZINC. 77511912 SOP.CIL.TORRETA ABATIBLE MINIVID 60000210 TUER.AUTO.DIN-985 1" SAE 8.8 77511913 BULON D=40*395mm.ABAT.MINIVID 60000303 TORN.EXAG.DIN-931 8* 65 8.8 ZINC.
  • Page 26 NEW FOLDABLE HEADSTOCK (>2022)
  • Page 27 PLACA RFZO.AB.DOBLE 19 GD3D 70021930 SOP.LATIG.MINIVID ABATIBLE 60000096 TORN.EXAG.DIN-933 20* 50 8.8 70060903 ARAND.P/BULON PLEG.CH/MCH/DISC 60000131 TUER.AUTO.DIN-980 8 8.8 ZINC. 77511910 PLACA SOP.TORRETA ABATIBLE MINIVID 60000142 TUER.AUTO.DIN-980 12 8.8 ZINC. 77511912 SOP.CIL.TORRETA ABATIBLE MINIVID 60000146 TUER.AUTO.DIN-980 20 10.9 ZINC. 77511913 BULON D=40*395mm.ABAT.MINIVID 60000210 TUER.AUTO.DIN-985 1"...
  • Page 28 HYDRAULIC SYSTEM FOLDABLE HEADSTOCK...
  • Page 29 HYDRAULIC SYSTEM FOLDABLE HEADSTOCK REFERENCIA DESCRIPCIÓN 51000005 CILIND.D.E.40-80-250 ROTULAS 53000001 TORNILLO SIMPLE 3/8 4022 53000006 JUNTA METAL/GOMA 1/2" 11603 53000007 JUNTA METAL/GOMA 3/8" 11602 53000015 UNION MACHO 3/8 4062 53000021 PROTECTOR E.R.MACHO 1/2" ROJO 5029-4PR 53000061 ESFERICO 3/8" TUBO 12mm.LG=205 4002E-205 53000124 LATIG.R2-3/8*2250mm.MF-1/2/OR-3/8 53000125...
  • Page 30 MINIVID BODY...
  • Page 31 CONJ.BRAZO IZQD.MINIVID (D/16) 63000239 TUERCA FIJACION KMA 5 77105954 CONJ.BRAZO DCH.MINIVID (D/16) 64000275 DISCO CONCAVO MUESC.MINIDISC 1968-20" 6mm.(D/12) 77105955 CONJ.BRAZO CENTRAL IZQD.MINIVID (D/16) 64000709 DISCO CONCAVO MUESCADO GRADA RAP/VIÑA 20" 6mm. 77105956 CONJ.BRAZO CENTRAL DCH.MINIVID (D/16) 77100002 SUSPENSION ELASTICA D=40*200mm. 77615911 TORNILLERIA CONJ.CUERPO MINIDISC (D/16)
  • Page 32 MCH MINIVID BODY...
  • Page 33 MCH MINIVID BODY REFERENCIA DESCRIPCIÓN 60000143 TUER.AUTO.DIN-980 16 8.8 ZINC. 60000223 TUER.AUTO.DIN-980 14 8.8 ZINC. 60000316 TORN.ARADO DIN-608/934 12*55 8.8 60000357 TORN.EXAG.DIN-931 16* 70 8.8 60000444 TORN.ARADO DIN-603/934 12*50 10.9 ZINC. 60000498 TUER.ABARCON DIN-6330B 12 10.9 ZINC. 61000060 ARAND.DIN-125 300HV 12 ZINC.
  • Page 34 DISC SUPPLEMENT MINIVID BODY...
  • Page 35 CASQUILLO TUERCA CONJ.MINIDISC (D/16) 63000031 ANILLO ELASTICO DIN-472 62 77104910 TAPA BUJE DISCOS MINIDISC (D/07) 63000103 ANILLO ELASTICO DIN-472 72 77105951 CONJ. BRAZO LAT. IZQD. MINIVID (D/16) 63000155 RETEN AP6 45*75*12,5 77105952 CONJ.BRAZO LAT.DCH.MINIVID (D/16) 63000238 CARTUCHO GRADA 20" 77105953 CONJ.BRAZO IZQD.MINIVID (D/16)
  • Page 36 MINIVID MODULE...
  • Page 37 MINIVID MODULE REFERENCIA DESCRIPCIÓN 60000061 TORN.EXAG.DIN-933 12* 40 8.8 ZINC. 60000142 TUER.AUTO.DIN-980 12 8.8 ZINC. 77502950 PAÑO DISCOS MODULO MINIVID...
  • Page 38 METALLIC DEFLECTORS ASSEMBLY...
  • Page 39 METALLIC DEFLECTORS ASSEMBLY REFERENCIA DESCRIPCIÓN 60000061 TORN.EXAG.DIN-933 12* 40 8.8 ZINC. 60000142 TUER.AUTO.DIN-980 12 8.8 ZINC. 61000008 ARAND.DIN-125 12 ZINC. 77503950 PLACA SOP.FALDON REPTILL 77503951 FALDON METALICO IZQDO.REPTILL 77503952 FALDON METALICO DCHO.REPTILL...

  • Page 40: Roller Assembly

    ROLLER ASSEMBLY...
  • Page 41 62000003 PASADOR ANILLA 6 ZINC. 62000004 PASADOR ANILLA 10 ZINC. 63000296 RODAMIENTO C/BRIDA REDONDO (D/20) 72004902 EJE RODILLO CIERRE ESFERICO 72004963 RODAMIENTO C/BRIDA CUADRADO (D/18) 72004999 CALZO BUJE RODILLO 72535913 BRAZO SOP.ROD.MINIVID 75037002 PLACA AMARRE RODILLO 77009903 BULON D=16*235mm.REG.RODILLO MCH...

  • Page 42: Tine Assembly

    TINE ASSEMBLY...
  • Page 43 TINE ASSEMBLY REFERENCIA DESCRIPCIÓN 55014900 BULON D=25*110mm.BLOQUEO/BRAZO RODILLO 60000142 TUER.AUTO.DIN-980 12 8.8 ZINC. 60000146 TUER.AUTO.DIN-980 20 10.9 ZINC. 60000157 TUER.EXAG.DIN-934 12 8.8 ZINC 60000296 TORN.EXAG.DIN-931 20* 90 8.8 ZINC. 60000337 TORN.EXAG.DIN-931 12* 80 8.8 ZINC. 61000009 ARAND.DIN-9021 12 ZINC. 62000003 PASADOR ANILLA 6 ZINC.
  • Page 44 TINE AND ROLLER ASSEMBLY...
  • Page 45 SOP.REGUL.BAST.RASTRA MCHV 77009903 BULON REG.RODILLO MCH REFERENCIA DESCRIPCIÓN 70210780 BAST.RASTRA MCHV 2,15 (D/09) 70210781 BAST.RASTRA MCHV 1,60 (D/09) 70210782 BAST.RASTRA MCHV 1,30 (D/09) 70210783 BAST.RASTRA MCHV 1,60-IC (D/09) 70210784 BAST.RASTRA MCHV 1,30-IC (D/09) 70210785 BAST.RASTRA MINIVID 2,95 70210786 BAST.RASTRA MINIVID 2,45...
  • Page 46 ASSEMBLY MINIVID 12-25 FIX...
  • Page 47 ASSEMBLY MINIVID 12-25 (+ARM)
  • Page 48 ASSEMBLY MINIVID 12-25 (+DISC)
  • Page 49 ASSEMBLY MINIVID 14-25 FIX...
  • Page 50 ASSEMBLY MINIVID 16-25 (+ARM)
  • Page 51 ASSEMBLY MINIVID 16-25 (+DISC)
  • Page 52 ASSEMBLY MINIVID 18-25 FIX...
  • Page 53 ASSEMBLY MINIVID 18-25 (+ARM)
  • Page 54 ASSEMBLY MINIVID 18-25 (+DISC)
