This handbook describes the use, maintenance instructions and spare parts supplied for the indicated plough. The farming implement known as “plough“ is designed to work the soil, linked to a tractor with lift and universal 3-point coupling. 1. Safety provisions ..........3 Regular and satisfactory operation together with economic 2.
SAFETY PROVISIONS 12.- Take the utmost care during the plough coupling and release 1.- Comply with the instructions given by the danger signals exposed phases. in this handbook (Fig.1) and affixed to the plough itself. 13.- Never ever leave the driving seat whilst the tractor is moving. 2.- Operations and adjustments to the implement must always be carried out when the engine is off and the tractor braked.
Page 4
Be prepared in case of emergency (Fig.1) WARNING Have near a first aid kit and an extinguisher. Write down the telephone Thoroughly read the manual before starting to work numbers of doctors, ambulances and firemen and keep them near the telephone.
2. DESCRIPTION 1. HEADSTOCK 2. FRAME 3. IDENTIFICATION PLATE 4. SET MAXIDISC 5. HYDRAULIC SYSTEM 6. BODIES 7. ARM 8. SECURITY SYSTEM 9. ROLLER 10. SIDE PLATES REMARK: The construction number that is engraved in the identification plate must be coincident with the number engraved on the headstock support.
The different auto-reset protection systems (leafspring / rubber dampers) work automatically. When finding any obstacle, the system Ovlac equipment are designed to fit the universal 3-point linkage of alllows the tine to trip up and overcome it then returning to its working any tractor position without stopping the tractor.
Check that lengths A1=A2 (Fig. 2) Crabbing is corrected automatically in OVLAC ploughs thanks to their oscillating cross shaft. In ploughs with fix coupling, act on the drifting-correction turnbuckle (hydraulic in option).
4.3 – OTHERS ADJUSTMENTS IMPORTANT: Care should be taken not to take curves at work, The length of the third point should be adjusted so that the frame especially with very wide tools, because the effort lever can cause works in a parallel position with respect to the field since, if not, the first serious damage to the structure of the machine.
WORKING DEPTH TRANSPORT The depth of work is regulated by the roller, by means of bolts of In foldable machines, the side frames must be folded in hydraulically for transport in order to carry the machine in its regulation A (Fig 7). In any case the working depth is such that minimum width.
7. MAINTENANCE Take care of the leaks of high pressure The fluids that escape of the system can have as much force that Retighten all bolts and nuts after the first 8 hours of work, specially they can penetrate the skin, causing serious injuries. Therefore, it is the ones of mouldboards, shares and points.
FRAME ......................13 - Code number of the required spare part. This will be found in the FIXED MINIVID FRAME .................. 15 attached spare parts list. FOLDING HEADSTOCK ................... 17 - Description of the part and required quantity.
